Technical data, mains supply 1 x 220 - 240 V / 3 x 200-240V

According to . international stan-
dards
Output current
(3 x 200-240V)
Output power (230 V)
Typical shaft output
Typical shaft output
Max. cable cross
section, motor
Input current
(1 x 220-240 V)
Input current
(3 x 200-240 V)
Max. cable cross
section, power
Max. pre-fuses
3)
Efficiency
Power loss at 100%
load
Weight
4
Enclosure
1. American Wire Gauge. Max. cable cross sec-
tion is the largest cable cross section that can be
attached to the terminals. Always observe national
and local regulations.
2. Type gG pre-fuses must be used. If you want to
maintain UL/cUL you must use pre-fuses of the
type Bussmann KTN-R 200 V, KTS-R 500 V or
Ferraz Shawmut, type ATMR (max. 30A). The
fuses must be placed for protection in a circuit that
is capable of supplying a maximum of 100,000
amps RMS (symmetrical), 500 V maximum.
3. Measured using a 25 m screened/armoured mo-
tor cable with a rated load and rated frequency.
4. IP20 is standard for VLT 2805-2875, whereas
NEMA 1 is an option.
MG.28.A5.02 - VLT is a registered Danfoss trade mark
VLT
Type 2803 2805
I [A] 2.2 3.2
INV.
I (60s) [A] 3.5 5.1
MAX
S [KVA] 0.9 1.3
INV.
P [kW] 0.37 0.55
M,N
P [HP] 0.5 0.75
M,N
2 1)
[mm /AWG] 4/10 4/10
I [A] 5.9 8.3
L,N
I (60s) [A] 9.4 13.3
L,MAX
I [A] 2.9 4.0
L,N
I (60s) [A] 4.6 6.4
L,MAX
2 1)
[mm /AWG] 4/10 4/10
2)
[A]/UL [A] 20/20 20/20
[%] 95 95
[W] 24 35
[kg] 2.0 2.0
type IP 20 IP 20
®
2800 Series
2807 2811 2815
4.2 6.0 6.8
6.7 9.6 10.8
1.7 2.4 2.7
0.75 1.1 1.5
1.0 1.5 2.0
4/10 4/10 4/10
10.6 14.5 15.2
16.7 23.2 24.3
5.1 7.0 7.6
8.2 11.2 12.2
4/10 4/10 4/10
20/20 20/20 20/20
95 95 95
48 69 94
2.0 2.0 2.0
IP 20 IP 20 IP 20
2822 2840
9.6 16
15.3 25.6
3.8 6.4
2.2 3.7
3.0 5.0
4/10 4/10
- -
- -
8.8 14.7
14.1 23.5
4/10 4/10
20/20 25/25
95 95
125 231
3,7 6.0
IP 20 IP 20
