1.- INTRODUCTION.

The C-80 analyzer is a programmable, measuring instrument that measures,
calculates and records in the memory the main electrical parameters in single phase or
balanced three phase with neutral, industrial systems. It is a small, portable and light
instrument that measures in true RMS.
The equipment has been manufactured with the latest technology and is the most
advanced means of measuring and recording electrical parameters on the market.
The C-80 analyzer allows automatic recording with a programmed time, and also,
instantly (or simultaneously) records data in the internal memory at regular time intervals.
This manual assists in the installation and use of C-80 type measuring instruments
and helps to obtain the best service from it. Carefully read this manual before connecting
the equipment to avoid incorrect use which may cause irrevocable damage.
installing it or handling it follow the usual safety procedures as well as
manufacturer, the equipment's protection may be compromised.
For the safe use of the C-80 it is vital that those persons
the individual warnings in this instruction manual, as well as the
different warnings it contains.
If the equipment is used in a way not specified by the
