SAEx 07.2 SAEx 16.2 / SAREx 07.2
1.4.

References and symbols

Information
< >
SAREx 16.2
Safety alert symbol
The signal word (here: DANGER) indicates the level of hazard.
The following references and symbols are used in these instructions:
The term Information preceding the text indicates important notes and information.
Symbol for CLOSED (valve closed)
Symbol for OPEN (valve open)
Important information before the next step. This symbol indicates what is required
for the next step or what has to be prepared or observed.
Reference to other sections
Terms in brackets shown above refer to other sections of the document which provide
further information on this topic. These terms are either listed in the index, a heading
or in the table of contents and may quickly be found.
warns of a potential personal injury hazard.
Safety instructions
7
