Figure 24: ExtremeSwitching 220-48p-10GE4 Switch Rear Panel
1 = Redundant power input
2 = Grounding point

ExtremeSwitching 210 and 220 Series Switch LEDs

The following table describes the meanings of the LEDs on the ExtremeSwitching 210 and 220 series
switches.
Table 3: Front Panel LEDs
Label or Type
MGT (Management)
FAN
PW
(Power Supply)
RPS
(Remote Power Supply)
220 Series 24- and 48-port
models only

Pluggable Interfaces for ExtremeSwitching Switches

Some 210 and 220 series switches include ports that are compatible with a variety of optical modules,
including SFP and SFP+ modules. Extreme Networks optical modules are tested to work in all
supported Extreme Networks devices. We recommend that all customers use Extreme Networks optical
modules in their Extreme Networks devices.
Extreme Networks assumes no liability for third-party optical modules. Although Extreme Networks
does not block third-party optical modules, we cannot ensure that all third-party optical modules
ExtremeSwitching 210 and 220 Series Switches: Hardware Installation Guide
3 = AC power input connector
Color/State
Slowly blinking green
Blinking green
Off
Steady green
Blinking amber
Off
Steady green
Off
Steady green
Blinking amber
Off
ExtremeSwitching 210 and 220 Series Switches
Meaning
Power-on self test (POST) has finished. This is
normal operation.
POST in progress.
No power.
Normal operation.
Failure.
No power.
Normal operation.
No power.
RPS working properly.
RPS failure.
No RPS.
23
