Overview of the ExtremeSwitching 210 Series Switches

The ExtremeSwitching 210 series switches are 12-, 24, or 48-port switches that provide 1-gigabit
Ethernet connectivity using fixed 10/100/1000BASE-T RJ45 ports and installable SFP optical modules.
The ExtremeSwitching 210 series base models are described in the following sections:
•
ExtremeSwitching 210-12t-GE2 Switch Ports and Slots
•
ExtremeSwitching 210-12p-GE2 Switch Ports and Slots
•
ExtremeSwitching 210-24t-GE2 Switch Ports and Slots
•
ExtremeSwitching 210-24p-GE2 Switch Ports and Slots
•
ExtremeSwitching 210-48t-GE4 Switch Ports and Slots
•
ExtremeSwitching 210-48p-GE4 Switch Ports and Slots
Using a serial console port on the front panel of the switch, you can connect a terminal and perform
local management. An Ethernet management port can be used to connect the system to a parallel
management network for administration. Alternatively, you can use an Ethernet cable to connect this
port directly to a laptop to view and locally manage the switch configuration. The Ethernet
management port supports 10/100 Mbps speeds.
The 12-port switches have a small form factor that allows you to install two switches side-by-side in a
standard equipment rack.
Switch cooling is provided by one, two, or three non-replaceable fan modules with side-to-side airflow.
AC power is supplied by a built-in power supply unit that is not user-replaceable.
ExtremeSwitching 210-12t-GE2 Switch Ports and Slots
The ExtremeSwitching 210-12t-GE2 switch ports and slots include:
•
12 10/100/1000BASE-T ports (ports 1–12) that provide 1 GbE connectivity
•
Two dedicated 1 GbE SFP ports (ports 13–14)
•
Ethernet management port (10/100BASE-T)
•
Serial console port used to connect a terminal and perform local management
•
LEDs to indicate switch operating conditions
For a description of the LEDs and their operation, see
LEDs on page 23.
