Addi-Data MSX-E1701 Technical Description

Ethernet multifunction counter system
Hide thumbs Also See for MSX-E1701:
Table of Contents

Advertisement

Quick Links

Download this manual
TECHNICAL
DESCRIPTION
MSX-E1701
Ethernet multifunction counter system
Edition: 02.02-08/2012
DIN EN ISO 9001:2008 certified

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MSX-E1701 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Addi-Data MSX-E1701

Summary of Contents for Addi-Data MSX-E1701

  • Page 1 TECHNICAL DESCRIPTION MSX-E1701 Ethernet multifunction counter system Edition: 02.02-08/2012 DIN EN ISO 9001:2008 certified...
  • Page 2 The content of this manual and the technical product data may be changed without prior notice. ADDI-DATA GmbH reserves the right to make changes to the technical data and the materials included herein.

  • Page 3: Warning

    If the instructions are ignored, the Ethernet system, the PC and/or peripherals may be destroyed. WARNING! Designates a possibly dangerous situation. If the instructions are ignored, the Ethernet system, the PC and/or peripherals may be destroyed and persons may be endangered. www.addi-data.com...

  • Page 4: Table Of Contents

    Contents MSX-E1701 Contents Warning.............................3 Chapter overview..........................6 Definition of application, user, handling ................7 Definition of application........................7 1.1.1 Intended use............................7 1.1.2 Usage restrictions..........................7 1.1.3 Limits of use ............................7 Safety precautions ..........................7 1.2.1 Current sources .............................7 1.2.2 Degrees of protection ..........................7 1.2.3 Cables..............................8 1.2.4...
  • Page 5 MSX-E1701: View from above......................31 Tables Table 3-1: Pin assignment: Incremental counter inputs ................12 Table 3-2: Pin assignment: Incremental counter inputs (MSX-E1701-24V) ..........13 Table 3-3: Incremental counter: Acquisition modes ..................16 Table 4-1: Pin assignment: Digital inputs/outputs ..................21 Table 4-2: LED display: Digital I/O .........................22 Table 5-1: Pin assignment: PWM outputs .....................26...

  • Page 6: Chapter Overview

    Chapter overview MSX-E1701 Chapter overview In this manual, you will find the following information: Chapter Content Important information on the application, the user and on handling the MSX-E system as well as safety precautions Brief description of the MSX-E system (functions, features, block diagram)

  • Page 7: Definition Of Application, User, Handling

    The Ethernet system MSX-E1701 must not be used for safety-related functions. The Ethernet system MSX-E1701 must not be used in potentially explosive atmospheres. The Ethernet system MSX-E1701 must not be used as electrical equipment according to the Low Voltage Directive 2006/95/EC.

  • Page 8: Cables

    Definition of application, user, handling MSX-E1701 If you are not sure, please contact us: Phone: +49 7229 1847-0 E-mail: info@addi-data.com 1.2.3 Cables The cables must be installed safely against mechanical load. 1.2.4 Housing The housing must not be opened. It may only be opened by persons who have been authorised by ADDI-DATA.

  • Page 9: Handling Of The Ethernet System

    Phone: +49 7229 1847-0. Manual and software download from the Internet The latest versions of the technical manual and the standard software for the Ethernet system MSX-E1701 can be downloaded for free at: www.addi-data.com IMPORTANT! Before using the Ethernet system or in case of malfunction during operation, check if there is an update (manual, driver, firmware) available on our website or contact us directly.

  • Page 10: Brief Description

    Brief description MSX-E1701 2 Brief description In this chapter, the functions and features of the Ethernet system MSX-E1701 are described in brief. Furthermore, you will find a general block diagram of the MSX-E system. 2.1 Functions and features The intelligent Ethernet system MSX-E1701 has four incremental counter inputs or four PWM outputs as well as 16 digital inputs and outputs, which can be configured as pairs of inputs or outputs.

  • Page 11: Block Diagram

    Brief description MSX-E1701 2.2 Block diagram Fig. 2-1: MSX-E1701: Block diagram www.addi-data.com...

  • Page 12: Function Description: Incremental Counter Inputs

    Function description: Incremental counter inputs MSX-E1701 3 Function description: Incremental counter inputs The Ethernet system MSX-E1701 is equipped with four incremental counter inputs. 3.1 Pin assignment To each M23 female connector, one rotary encoder can be connected. Table 3-1: Pin assignment: Incremental counter inputs Female connector, Pin No.

  • Page 13: Table 3-2: Pin Assignment: Incremental Counter Inputs (Msx-E1701-24V)

    Function description: Incremental counter inputs MSX-E1701 Table 3-2: Pin assignment: Incremental counter inputs (MSX-E1701-24V) Female connector, Pin No. Polarity Function 12-pin, M23 Output 5 V / 24 V Voltage supply Supply for 2, 12 (can be set via jumper), incremental encoder...

  • Page 14: Selecting The Supply Voltage

    • When the housing is opened, neither solid nor liquid foreign bodies (dirt, moisture, etc.) may enter the inside of the housing! Fig. 3-1: MSX-E1701: Right-hand side of the housing Fig. 3-2: 24 V supply: Jumper at positions 1 and 2...

  • Page 15: Connection Example

    Function description: Incremental counter inputs MSX-E1701 Fig. 3-3: 5 V supply: Jumper at positions 2 and 3 3.3 Connection example Fig. 3-4: Connection example: Incremental encoder www.addi-data.com...

  • Page 16: Ttl Signal To Rs422 Input

    3.4 TTL signal to RS422 input IMPORTANT! This option does not apply to the system MSX-E1701-24V. A TTL signal may also be connected to a differential RS422 input using a reference voltage of approx. 1.4 V. The reference voltage is switched on through software and output at pin D- of the M23 female connector.

  • Page 17: Fig. 3-5: Incremental Counter: Single Mode

    Function description: Incremental counter inputs MSX-E1701 a) Single mode In single mode, if trace A of the incremental encoder signal is on “high”, the system counts with each rising edge of trace B. Fig. 3-5: Incremental counter: Single mode b) Double mode In double mode, the system counts with each rising and falling edge of trace B.

  • Page 18: Options

    Function description: Incremental counter inputs MSX-E1701 3.5.1 Options 1) Hysteresis function The hysteresis function can be used in single, double and quadruple mode. Fig. 3-9: Quadruple mode: Hysteresis “on” With hysteresis “on”, the first counting pulse after a change of rotational direction is not evaluated.

  • Page 19: Index And Reference Point Logic

    Function description: Incremental counter inputs MSX-E1701 b) Modulo mode In Modulo mode, a reference value is indicated as well. When the counter value corresponds to the reference value or a multiple of it, a trigger or synchro trigger is released.

  • Page 20: Digital Filter For The Incremental Counter Inputs

    Function description: Incremental counter inputs MSX-E1701 In order to suppress interfering signals, a software-programmable digital filter can be used for the trigger input. The filter time may be in the range between 250 ns and 16.38 ms. When the filter is activated, every positive or negative pulse lasting shorter than the defined filter time is suppressed.

  • Page 21: Function Description: Digital Inputs/Outputs

    MSX-E1701 4 Function description: Digital inputs/outputs The Ethernet system MSX-E1701 has 16 digital inputs or outputs for sensors or actuators. 4.1 Pin assignment To each M12 female connector, up to two sensors or actuators can be connected. In addition, a 24 V supply is available.

  • Page 22: Led Display

    Function description: Digital inputs/outputs MSX-E1701 4.2 LED display Table 4-2: LED display: Digital I/O Direction Status Meaning black - No output active Output inactive - No voltage applied Lights red - Output is active Output active - No voltage applied...

  • Page 23: Connection Examples

    Function description: Digital inputs/outputs MSX-E1701 4.3 Connection examples 4.3.1 Digital inputs (24 V) Fig. 4-1: Connection example: Digital inputs (24 V) www.addi-data.com...

  • Page 24: Digital Outputs (24 V)

    Fig. 4-2: Connection example: Digital outputs (24 V) 4.4 Digital outputs By default, the digital channels of the MSX-E1701 are configured as inputs. In order to convert a port, i. e. a pair of channels into an output, the configuration has to be changed on the web interface of the MSX-E system (see Chapter 6.1.1) or by the SOAP function...

  • Page 25: Watchdog

    MSX-E1701 4.5 Watchdog The Ethernet system MSX-E1701 has a 16-bit watchdog, which is programmable in three time units (μs, ms, s). The watchdog is used to reset the digital outputs to 0 V after a specific time. Operation of the watchdog 1.

  • Page 26: Function Description: Pwm Outputs

    Function description: PWM outputs MSX-E1701 5 Function description: PWM outputs The Ethernet system MSX-E1701 is designed to use four PWM outputs. 5.1 Pin assignment To each M23 female connector, one PWM actuator can be connected. Table 5-1: Pin assignment: PWM outputs Female connector, Pin No.

  • Page 27: Web Interface: Quick Access To The Msx-E System

    6 Web interface: Quick access to the MSX-E system 6.1 “I/O Configuration” In this manual, the function-specific pages of the MSX-E1701 web interface, which are located under the menu item “I/O Configuration”, are described. For further information on the MSX-E web interface, please refer to the general manual of the MSX-E systems (see PDF link).

  • Page 28: Menu Item "Incremental Counter

    Web interface: Quick access to the MSX-E system MSX-E1701 Fig. 6-4: I/O Watchdog: Configuration You can configure the watchdog by defining the time unit and the watchdog time. 6.1.3 Menu item “Incremental counter” Fig. 6-5: Incremental counter: Configuration In this section, you can select the acquisition mode of the incremental encoder signal and the corresponding options.

  • Page 29: Menu Item "Pwm

    Web interface: Quick access to the MSX-E system MSX-E1701 6.1.4 Menu item “PWM” Fig. 6-6: PWM: Configuration This menu item is only available in the system version containing PWM outputs. In the area “PWM signal configuration”, you can set the following parameters: time base, level times, start level, external gate and filter value of input C.

  • Page 30: Data Format

    Web interface: Quick access to the MSX-E system MSX-E1701 6.1.5 Data format Below, the data format of incremental counter values is described. The data server is not used for the digital I/Os and the watchdog. Table 6-1: Incremental counter: Data format Time stamp (μs)

  • Page 31: Technical Data And Limit Values

    7 Technical data and limit values 7.1 Electromagnetic compatibility (EMC) The Ethernet system MSX-E1701 complies with the European EMC directive. The tests were carried out by a certified EMC laboratory in accordance with the norm from the EN 61326 series (IEC 61326).

  • Page 32: Versions

    Technical data and limit values MSX-E1701 7.3 Versions The Ethernet system MSX-E1701 is available in the following versions: Table 7-1: MSX-E1701: Versions Version Features RS422 or 5 V inputs (incremental counter) MSX-E1701 or RS422 outputs (PWM) MSX-E1701-24V 24 V inputs (incremental counter) The specific version name can be found on the type label of your Ethernet system (see also Chapter 1.1...

  • Page 33: Ethernet

    Technical data and limit values MSX-E1701 7.4.1 Ethernet Number of ports: Optical isolation: 1000 V Cable length: 150 m (max. for CAT5E UTP) Bandwidth: 10 Mbps (auto-negotiation) 100 Mbps (auto-negotiation) Protocol: 10 Base-T according to IEEE 802.3 100 Base-TX according to IEEE 802.3...

  • Page 34: Incremental Counter Inputs

    MSX-E1701 7.4.4 Incremental counter inputs Number of inputs: 4 (with A, B, C and D signals each) Input type: differential or TTL (MSX-E1701) 24 V (MSX-E1701-24V) Sensor supply: Voltage: 5 V or 24 V (can be selected via jumper) Current: 500 mA max.

  • Page 35: Digital Outputs

    Technical data and limit values MSX-E1701 7.4.7 Digital outputs Number of outputs: 16 (2 per female connector) Optical isolation: 1000 V (via opto-couplers) Output type: high-side (load to ground according to IEC 1131-2) Nominal voltage: 24 V Supply voltage: 18-30 V Current: 1.85 A max.

  • Page 36: Appendix

    Appendix MSX-E1701 8 Appendix 8.1 Glossary Cascading Cascading means connecting multiple similar = Electrostatic Discharge elements together to enhance their individual On non-conductive surfaces, an electric charge effect. The individual elements must be such is conducted away very slowly. If the dielectric...
  • Page 37 Appendix MSX-E1701 Hysteresis Level Hysteresis is the difference between the start- Logic levels are defined for processing and up and shut-down voltage. In TTL circuits, it is displaying information. typically 0.8 V; in CMOS circuits, it depends on In binary switches, voltages are used for digital the supply voltage.
  • Page 38 Appendix MSX-E1701 SOAP Watchdog = Simple Object Process Protocol A watchdog is an electronic delay switch used to monitor key components or devices. It is SOAP is a simple extensible protocol for activated periodically and triggers an alarm exchanging information in distributed after a specified time.

  • Page 39: Index

    Appendix MSX-E1701 8.2 Index Acquisition modes 16 LED display Digital I/O 22 Block diagram 11 Limit values 32 Brief description 10 Pin assignment Compare logic 18 Digital I/O 21 Connection example Incremental counter inputs 12 Incremental counter inputs 15 PWM outputs 26...

  • Page 40: Contact And Support

    Contact and support MSX-E1701 9 Contact and support Do you have any questions? Write or phone us: Address: ADDI-DATA GmbH Airpark Business Center Airport Boulevard B210 77836 Rheinmünster Germany Phone: +49 7229 1847-0 Fax: +49 7229 1847-222 E-mail: info@addi-data.com Manual and software download from the Internet: www.addi-data.com...
