Function description: Incremental counter inputs

Table 3-2: Pin assignment: Incremental counter inputs (MSX-E1701-24V)

Female connector,
Pin No.
2, 12
10, 11
5
6
8
1
3
4
9
7
2 see Chapter 3.2
www.addi-data.com
12-pin, M23
Voltage supply
2
24 V or 5 V
condition upon delivery: 24 V
GND
A+
A-
B+
B-
C+
C-
D+
D-
Polarity
Output 5 V / 24 V
(can be set via jumper),
GND
Input 24 V
not connected
Input 24 V
not connected
Input 24 V
not connected
Input 24 V
not connected
13
MSX-E1701
Function
Supply for
incremental encoder
Trace A
Incremental signal
Trace B
Incremental signal
Trace C
Index
Reference signal for
reference point logic
