Technical data and limit values

7.4.4 Incremental counter inputs

Number of inputs:
Input type:
Sensor supply:
Voltage:
Current:
Differential inputs:
Common mode range:
Input sensitivity:
Input hysteresis:
Max. input frequency:
Input impedance:
"Open Circuit Fail Safe
Receiver Design":
ESD protection:
TTL inputs:
24 V inputs:
Nominal voltage:
Max. input frequency:
Input impedance:
Logic input levels:

7.4.5 PWM

Number of outputs:
Output type:
Nominal voltage:
Max. input frequency:

7.4.6 Digital inputs

Number of inputs:
Overvoltage protection:
Optical isolation:
Nominal voltage:
Input voltage:
Input frequency (max.):
Input impedance:
Logic input levels:
www.addi-data.com
4 (with A, B, C and D signals each)
differential or TTL (MSX-E1701)
24 V (MSX-E1701-24V)
5 V or 24 V (can be selected via jumper)
500 mA max. (for each female connector)
comply with EIA standards RS422A
+12 V to -7 V
±200 mV
50 mV typ.
5 MHz
12 kΩ min.
"1" = inputs open
up to ±15 kV
see Chapter 3.4
version for the connection of 24 V encoders or
24 V signals
24 VDC
1 MHz (at nominal voltage)
1 MΩ typ.
UH : 30 V
max
UH : 19 V
min
UL : 14 V
max
UL : 0 V
min
4 (with A, B, C and D signals each)
RS422
3.3 V
5 MHz (depending on the function)
16 (2 per female connector / common GND
according to IEC 1131-2)
30 V
1000 V (via opto-couplers)
24 VDC
0-30 V
1 MHz (at nominal voltage)
> 1 MΩ
UH : 30 V
max
UH : 19 V
min
UL : 14 V
max
UL : 0 V
min
34
MSX-E1701
