TECHNICAL
DESCRIPTION
MSX-Exxxx
Intelligent Ethernet system
Edition: 02.05-07/2014
DIN EN ISO 9001:2008 certified

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MSX-E Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Addi-Data MSX-E Series

  • Page 1 TECHNICAL DESCRIPTION MSX-Exxxx Intelligent Ethernet system Edition: 02.05-07/2014 DIN EN ISO 9001:2008 certified...
  • Page 2 The content of this manual and the technical product data may be changed without prior notice. ADDI-DATA GmbH reserves the right to make changes to the technical data and the materials included herein.
  • Page 3: Warning

    If the instructions are ignored, the Ethernet system, the PC and/or peripherals may be destroyed. WARNING! Designates a possibly dangerous situation. If the instructions are ignored, the Ethernet system, the PC and/or peripherals may be destroyed and persons may be endangered. www.addi-data.com...
  • Page 4: Table Of Contents

    Menu item “Reboot” or “Shutdown”....................41 „Network“............................42 4.4.1 Menu item “Configuration” ......................42 „I/O Configuration“ ..........................43 4.5.1 Menu item “Synchro timer”.......................43 4.5.2 Menu item “Hardware trigger”......................43 4.5.3 “Configuration management” ......................43 4.5.4 “Autostart” (Automatic configuration start) ...................44 „Development Mode“ ........................44 “Data server” ............................45 www.addi-data.com...
  • Page 5 Data server ............................52 Event server ............................52 5.5.1 Packet format............................52 5.5.2 Time stamp format ..........................53 Returning or disposing .......................54 Returning.............................54 Disposal of ADDI-DATA devices ......................55 Appendix ..........................56 Glossary..............................56 Index ..............................58 Contact and support ......................59 Figures Fig. 1-1: Commissioning (overview) ......................8 Fig. 1-2: Type label ............................9...
  • Page 6 Table 1-5: LED display ............................20 Table 1-6: “Status” LED..........................21 Table 3-1: Temperature monitoring: MSX-Exxxx ..................30 Table 3-2: Temperature monitoring: MSX-E3700 and MSX-E3701 .............30 Table 3-3: Customer key ..........................30 Table 5-1: MSX-E servers ..........................50 Table 5-2: Event server: Packet format ......................52 www.addi-data.com...
  • Page 7: Chapter Overview

    Description of the web interface of the MSX-E system for fast access to the system without programming Software description: Access over SOAP/web service or Open Modbus (for PLC) Procedure for returning (repairing, etc.) or disposing of the MSX-E system Appendix with glossary and index Contact and support address www.addi-data.com...
  • Page 8: Mounting And Connection

    Ethernet system may cause property damage and injury. Discharge any static by touching an earth wire. Remove the Ethernet system from its protective packaging. Check the type label on the bottom side of the Ethernet system to know if the system corresponds to your requested version. www.addi-data.com...
  • Page 9: Fig. 1-2: Type Label

    Ethernet system. In case of queries, these details always have to be kept at hand! For more information on the disposal label, see Chapter 6.2. Information on cables and other accessories can be found in the accessories list of the MSX-E systems. www.addi-data.com...
  • Page 10: Fixing The Ethernet System

    (see the following figure). Fig. 1-3: Fastening clips Push the Ethernet system as much as possible up and then backwards until the top of the fastening clips engages with the DIN rail. 1 Please specify when ordering the Ethernet system! www.addi-data.com...
  • Page 11: Angle Bracket Mounting

    If the Ethernet system cannot be positioned in this way, the respective housing part has to be pushed towards the inside of the system during the whole mounting process so that the housing remains closed (see the following figure). www.addi-data.com...
  • Page 12: Fig. 1-6: Angle Bracket Mounting

    Fig. 1-7: Mounting set: Seal and screw (short) The original screw from the MSX-E system and the long seals or screws from the mounting set must not be used any longer. Fig. 1-8: Mounting set: Original screw, seal and screw (long) www.addi-data.com...
  • Page 13: Pin Assignment

    Once you have mounted the brackets on the Ethernet system, you can attach the system directly to other devices or machines by using other screws. 1.3 Pin assignment In this chapter, you will find the pin assignments of the connectors for Ethernet, trigger/synchro and the voltage supply of the Ethernet system MSX-Exxxx. Fig. 1-9: Connectors www.addi-data.com...
  • Page 14: Ethernet Ports

    Table 1-1: Pin assignment: Ethernet ports 0 and 1 Ethernet Port 0 Ethernet Port 1 Cable (green) Female connector, Female connector, Pin No. Lead colour D-coded, M12 D-coded, M12 TD0+ TD1+ yellow RD0+ RD1+ white TD0- TD1- orange RD0- RD1- blue www.addi-data.com...
  • Page 15: Trigger/Synchro

    Male connector, 5-pin / female connector, 5-pin 1.5 m CMX-51 Male connector, 5-pin / female connector, 5-pin CMX-52 Male connector, 5-pin / female connector, 5-pin CMX-59 Male connector, 5-pin / female connector, 5-pin on request CMX-59_0,3 Male connector, 5-pin / female connector, 5-pin 0.3 m www.addi-data.com...
  • Page 16: Voltage Supply

    Power Supply In Power Supply Out (black) Connector, Female connector, Pin No. Lead colour 5-pin, M12 5-pin, M12 24 V 24 V brown 24 V 24 V white Ground Ground blue Ground Ground black not connected not connected grey www.addi-data.com...
  • Page 17: Connecting Peripherals

    Plug the Ethernet cable into Ethernet Port 0 Fig. 1-10: Connect peripherals Ethernet Port 0 Trig/Sync In Current supply input Current supply output (24 VDC In) (24 VDC Out) 2 If you want to connect several Ethernet systems, please read Chapter 1.5. www.addi-data.com...
  • Page 18: Trigger And Synchro Signals

    Information concerning the type of sensor or actuator, the corresponding pin assignment as well as connection examples can be found in the respective system-specific MSX-E manual. Fig. 1-11: MSX-Exxxx: Connect sensors or actuators (example) 3 If you want to connect several Ethernet systems, please read Chapter 1.5. www.addi-data.com...
  • Page 19: Connecting Several Ethernet Systems (Cascading)

    You have the possibility to connect several Ethernet systems to the MSX-Exxxx. In order to do so, proceed as follows: Connect the first Ethernet system (see description at the beginning of this chapter). Connect the components according to the following figure. Fig. 1-12: Connect several Ethernet systems www.addi-data.com...
  • Page 20: Led Display

    Mounting and connection MSX-Exxxx 1.6 LED display 1.6.1 Overview The LEDs give you the following information: Table 1-5: LED display Display Meaning ADDI-DATA logo Lights white The system is ready for operation. No display The system is in energy- saving mode. ADDI-DATA ®...
