Technical data and limit values

7.4.7 Digital outputs

Number of outputs:
Optical isolation:
Output type:
Nominal voltage:
Supply voltage:
Current:
Output current per output:
Short-circuit current per output:
R
ON resistance:
DS
Switch-on time:
Switch-off time:
Overtemperature (shut-down):
Temperature hysteresis:
Diagnosis:

7.4.8 Watchdog

Number:
Watchdog depth:
Programmability:
Time base:
5 Group 1: Digital outputs 0 to 3, 8 to 11 and the respective 24 V output
Group 2: Digital outputs 4 to 7, 12 to 15 and the respective 24 V output
www.addi-data.com
16 (2 per female connector)
1000 V (via opto-couplers)
high-side (load to ground according to
IEC 1131-2)
24 V
18-30 V
1.85 A max. (for each group
500 mA max.
1.7 A max.
shut-down logic at 24 V, R
280 mΩ max.
100 μs (max. R
= 48 Ω of 80 % V
L
150 μs (max. R
= 48 Ω of 10 % V
L
135 °C max. (output driver)
15 °C typ. (output driver)
common diagnostic bit for all 16 channels at
overtemperature of one channel
1
16-bit
1 μs to 65535 s
μs, ms, s (programmable)
35
MSX-E1701
5
) via PTC
= 10 mΩ
Load
)
out
)
out
