TECHNICAL DESCRIPTION MSX-E1516 Ethernet digital I/O system Edition: 02.02-03/2015 DIN EN ISO 9001:2008 certified...
Page 2
The content of this manual and the technical product data may be changed without prior notice. ADDI-DATA GmbH reserves the right to make changes to the technical data and the materials included herein.
If the instructions are ignored, the Ethernet system, the PC and/or peripherals may be destroyed. WARNING! Designates a possibly dangerous situation. If the instructions are ignored, the Ethernet system, the PC and/or peripherals may be destroyed and persons may be endangered. www.addi-data.com...
Chapter overview MSX-E1516 Chapter overview In this manual, you will find the following information: Chapter Content Important information on the application, the user and on handling the MSX-E system as well as safety precautions Brief description of the MSX-E system (functions, features, block diagram)
1.1 Definition of application 1.1.1 Intended use The Ethernet system MSX-E1516 for digital input or output is intended for the connection to a network, which is used as electrical equipment for measurement, control and laboratory pursuant to the norm EN 61010-1 (IEC 61010-1).
Definition of application, user, handling MSX-E1516 If you are not sure, please contact us: Phone: +49 7229 1847-0 E-mail: info@addi-data.com 1.2.3 Cables The cables must be installed safely against mechanical load. 1.2.4 Housing The housing must not be opened. It may only be opened by persons who have been authorised by ADDI-DATA.
Phone: +49 7229 1847-0. Manual and software download from the Internet The latest versions of the technical manual and the standard software for the Ethernet system MSX-E1516 can be downloaded for free at: www.addi-data.com NOTICE! Before using the Ethernet system and in case of malfunction during operation, check if there is an update (manual, driver, firmware) available.
2 Brief description 2.1 Functions and features The intelligent Ethernet system MSX-E1516 has eight times two digital 24 V lines, which can be configured as pairs of inputs or outputs. The system provides an event logic for the inputs and outputs. Thus, an event datagram can be generated when their status changes.
MSX-E1516 3 Function description: Digital inputs/outputs The Ethernet system MSX-E1516 has 16 digital inputs or outputs for sensors or actuators. 3.1 Pin assignment To each M12 female connector, up to two sensors or actuators can be connected. In addition, a 24 V supply is available.
Function description: Digital inputs/outputs MSX-E1516 3.2 LED display Table 3-2: LED display: Digital I/O Direction Status Meaning Output inactive No display - No output active - No voltage applied Output active Lights red - Output is active - No voltage applied...
Fig. 3-2: Connection example: Digital outputs (24 V) 3.4 Digital outputs By default, the digital channels of the MSX-E1516 are configured as inputs. A port, i.e. a pair of channels can be configured as an output via the web interface of the MSX-E system (see Chapter 4.1.1) or via the SOAP or Modbus function “DigitalIOInitPortConfiguration”.
MSX-E1516 3.5 Watchdog The Ethernet system MSX-E1516 has a 16-bit watchdog, which is programmable in three time units (μs, ms, s). The watchdog is used to reset the digital outputs to 0 V after a specific time. Operation of the watchdog 1.
Since the digital inputs are set to 0 during the whole filter time, a “false” event is thus detected. However, if you set an output directly via the SOAP function (e.g. sample in the CD directory “MSX-E1516\SOAP\Samples \Windows\C#.NET_2005\ReadWrite”), no “false” events will occur. www.addi-data.com...
Function description: Digital inputs/outputs MSX-E1516 3.7 Data format Table 3-3: Data format: Digital I/O tv_sec tv_usec Source event mask I/O status bitmap 4 bytes 4 bytes 4 bytes 4 bytes Time stamp Time stamp Mask of the event source: Status of the channels (in s) low (in μs) high...
4 Web interface: Quick access to the MSX-E system 4.1 “I/O Configuration” In this manual, the function-specific pages of the MSX-E1516 web interface, which are located under the menu item “I/O Configuration”, are described. For further information on the MSX-E web interface, please refer to the general manual of the MSX-E systems (see PDF link).
Web interface: Quick access to the MSX-E system MSX-E1516 Fig. 4-4: Digital I/O: Digital Input/Output events In this section, you can select for which channel and for which respective edge type an event datagram should be generated. In addition, a time stamp can be set for each event. The event logic is stopped via the corresponding button.
Web interface: Quick access to the MSX-E system MSX-E1516 4.1.2 Menu item “I/O Watchdog” Fig. 4-6: I/O Watchdog: Current state On this page, the current status of the watchdog for the digital inputs and outputs is displayed. Fig. 4-7: I/O Watchdog: Configuration You can configure the watchdog by defining the time unit and the watchdog time.
5 Technical data and limit values 5.1 Electromagnetic compatibility (EMC) The Ethernet system MSX-E1516 complies with the European EMC directive. The tests were carried out by a certified EMC laboratory in accordance with the norm from the EN 61326 series (IEC 61326).
MSX-E1516 NOTICE! The connection lines must be installed in such a way that they are protected against mechanical loads. 5.3 Version The Ethernet system MSX-E1516 is available in the following versions: Table 5-1: MSX-E1516: Versions Version Features MSX-E1516 16 digital inputs/outputs, 24 V...
Technical data and limit values MSX-E1516 5.4.1 Ethernet Number of ports: Optical isolation: 1000 V Cable length: 150 m (max. for CAT5E UTP) Bandwidth: 10 Mbps (auto-negotiation) 100 Mbps (auto-negotiation) Protocol: 10 Base-T according to IEEE 802.3 100 Base-TX according to IEEE 802.3...
Technical data and limit values MSX-E1516 5.4.4 Digital inputs Number of inputs: 16 (2 per female connector / common GND according to IEC 1131-2) Overvoltage protection: 30 V Optical isolation: 1000 V (via opto-couplers) Nominal voltage: 24 VDC Input voltage: 0-30 V Max.
Appendix MSX-E1516 6 Appendix 6.1 Glossary Cascading After making even very tough real-time Cascading means connecting multiple similar requirements possible and adapting the device elements together to enhance their individual technology (bus cables, patch fields, junction effect. The individual elements must be such...
Page 26
Appendix MSX-E1516 Input level MAC address The input level is the logarithmic ratio between MAC = Media Access Control two electrical values of the same type (voltage, This is the hardware address of network current or power) at the signal input of any components used to identify them uniquely receiving unit.
Page 27
Appendix MSX-E1516 Switch-off time The switch-off time is the time between the control current being switched off and the output voltage falling to 10% of its original value. TCP/IP = Transmission Control Protocol/Internet Protocol TCP/IP is a family of network protocols and therefore often just referred to as Internet protocol.
Contact and support MSX-E1516 7 Contact and support Do you have any questions? Write or phone us: Address: ADDI-DATA GmbH Airpark Business Center Airport Boulevard B210 77836 Rheinmünster Germany Phone: +49 7229 1847-0 Fax: +49 7229 1847-222 E-mail: info@addi-data.com Manual and software download from the Internet: www.addi-data.com...
