Definition of application, user, handling

1 Definition of application, user, handling

1.1 Definition of application

1.1.1 Intended use

The Ethernet system MSX-E1701 for the acquisition, processing and transferring of rotary encoder
signals as well as for digital input or output is intended for the connection to a network, which is used
as electrical equipment for measurement, control and laboratory pursuant to the norm EN 61010-1
(IEC 61010-1).

1.1.2 Usage restrictions

The Ethernet system MSX-E1701 must not be used as safety-related part (SRP).
The Ethernet system MSX-E1701 must not be used for safety-related functions.
The Ethernet system MSX-E1701 must not be used in potentially explosive atmospheres.
The Ethernet system MSX-E1701 must not be used as electrical equipment according to the Low
Voltage Directive 2006/95/EC.

1.1.3 Limits of use

All safety information and the instructions in the manuals must be followed to ensure proper intended
use.
Uses of the Ethernet system beyond these specifications are considered as improper use.
The manufacturer is not liable for damages resulting from improper use.
The Ethernet system must remain in its anti-static packaging until it is installed.
Please do not delete the identification numbers of the Ethernet system or the warranty claim will be
invalid.

1.2 Safety precautions

1.2.1 Current sources

All connected devices must be supplied from current sources that comply with SELV according to
IEC 60950 or EN 60950; or PELV according to IEC 60204-1 or EN 60204-1.

1.2.2 Degrees of protection

IMPORTANT!
i
The protection according to the defined degree of protection
(see Chapter 7.4) is only given if the openings are protected with
adequate protection caps or connectors.
www.addi-data.com
7
MSX-E1701
