Overview; Specifications; Installation Instructions - Altronix HubWayEXP Installation Manual

Altronix HubWayEXP UTP Power Injector supplies power combined with pass-through video and data for up
to 16 cameras from Altronix HubWay Active UTP Transceiver Hubs. Unit allows for video transmission of
up to 16 cameras over four CAT-5 or higher structured cables from HubWay Active Transceiver Hubs. The
HubWayEXP units are designed for installation at the IDF (Intermediate Distribution Frame) or MDF (Main
Distribution Frame).
Input:
• 115VAC 60Hz, 2.5A or 230VAC 50Hz, 1.5A.
Power:
• Unit provides up to 1A max. per channel, not to
exceed a total of 16 amp maximum current.
• Individually selectable 24VAC or 28VAC power
outputs with OFF position.
• Individual electronically isolated PTC outputs.
• PTCs are rated @ 1A per channel.
• Surge suppression.
WARNING: To reduce the risk of fire or electric shock do not expose the unit to rain or moisture.
This installation should be made by qualified service personnel and should conform to all local codes.
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local codes
and authorities having jurisdiction. Wiring should be UL Listed and/or Recognized wire suitable for the application.
1. Attach mounting brackets to HubWayEXP unit for rack or wall mount installation (Figs. 7-8, pg. 8). Affix
rubber pads to HubWayEXP for shelf installation (Fig. 9, pg. 8).
2. Secure the unit in a rack, mount unit to a wall or place unit on a shelf as desired (unit should be spaced at
least 3" from any video monitors).
3. Set illuminated master power disconnect circuit breaker to the (OFF) position (Fig. 6, pg. 7).
4. Plug the grounded AC line cord into the IEC 320 connector of the HubWayEXP . For US & Canada the
plug end is a 3 prong type B plug used for standard 115VAC receptacles, as provided with unit (Fig. 1f, pg. 4).
For non North American 230VAC applications use the appropriate 3 prong plug that matches the local
standard receptacle.
5. Set voltage output selector switch of each camera channel for 24VAC or 28VAC (Fig. 3c, pg. 4).
6. For video transmission:
a. HubWayEXP interface to HubWayEX16S unit - Connect a CAT-5 cable to the RJ45 jack marked
[CH 1-4, CH 5-8, CH 9-12, CH 13-16] (Fig. 3d, pg. 4). Connect the opposite end of this CAT-5 cable
into the corresponding RJ45 jack marked [CH 1-4, CH 5-8, CH 9-12, CH 13-16] of HubWayEX16S
(Fig. 4, pg. 5).
b. HubWayEXP interface to HubWayEX16 or HubWayEX32 unit - Connect a CAT-5 cable to the RJ45
jack marked [CH 1-4, CH 5-8, CH 9-12, CH 13-16] (Fig. 3d, pg. 4). Connect the opposite end of this
CAT-5 cable into the corresponding RJ45 jack marked [CH 1-4, CH 5-8, CH 9-12, CH 13-16] of
HubWayEX16 or HubWayEX32 unit (Fig. 5, pg. 6).
7. For data (PTZ) connections (When using fixed cameras disregard this step):
a. HubWayEXP interface to HubWayEX16S unit - Connect an additional CAT-5 cable to the RJ45 jack
marked [DATA] on the rear of HubWayEXP (Fig. 3e, pg. 4). Connect the opposite end of this CAT-5
cable into any unused RJ45 jack marked [1-16] of HubWayEX16S unit (Fig. 4, pg. 6).
b. HubWayEXP interface to HubWayEX16 or HubWayEX32 unit - Connect an additional CAT-5 cable
to the RJ45 jack marked [DATA] on the rear of HubWayEXP (Fig. 3e, pg. 4). Connect the opposite
end of this CAT-5 cable into the RJ45 jack marked [DATA] of HubWayEX16 or HubWayEX32 unit
(Fig. 5, pg. 6)
8. Connect a CAT-5 cable to the RJ45 jack marked [1] (Fig. 3a, pg. 4). Connect the opposite end of this
CAT-5 cable into the Video Balun/Combiner to be installed at camera 1 (repeat this step for cameras 2-16).
• For 24VAC cameras use Altronix model HubWayAv Video Balun/Combiner (Figs. 1a, 1b, pg. 3).
• For 12VDC cameras use Altronix model HubWayDv Video Balun/Combiner (Figs. 1c, 1d, pg. 3).
The total cable distance must not exceed 5000 ft. for video transmission between the HubWayEXP and
HubWayEX16S, HubWayEX16 OR HubWayEX32 and each camera.
- 2 -

Overview:

Specifica tions:
Visual Indicators:
• Individual power LED indicators.
Features:
• Illuminated master power disconnect circuit breaker
• IEC 320 - 3-wire receptacle.
• Unit can be rack, wall or shelf mounted.
• 1U rack mount chassis for use in standard

Installation Instructions:

with manual reset.
EIA 19" rack.
HubWayEXP
