Supermicro SUPERSERVER 6027R-CDNRT+ User Manual

Supermicro SUPERSERVER 6027R-CDNRT+ User Manual

2u rackmount server
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
S
UPER
®
S
S
UPER
ERVER
®
6027R-CDNRT+
USER'S MANUAL
1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUPERSERVER 6027R-CDNRT+ and is the answer not in the manual?

Questions and answers

Related Manuals for Supermicro SUPERSERVER 6027R-CDNRT+

Summary of Contents for Supermicro SUPERSERVER 6027R-CDNRT+

  • Page 1 UPER ® UPER ERVER ® 6027R-CDNRT+ USER’S MANUAL...
  • Page 2 This product, including software and docu- mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.

  • Page 3: About This Manual

    Preface Preface About This Manual This manual is written for professional system integrators and PC technicians. It pro- vides information for the installation and use of the SuperServer 6027R-CDNRT+. Installation and maintainance should be performed by experienced technicians only. The SuperServer 6027R-CDNRT+ is a 2U rackmount server based on the SC- 826BAC4-R920WB chassis and the X9DRD-CNT+ serverboard.
  • Page 4 UPER ERVER 6027R-CDNRT+ User's Manual Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X9DRD-CNT+ serverboard, includ- ing the locations and functions of connections, headers and jumpers. Refer to this chapter when adding or removing processors or main memory and when reconfig- uring the serverboard.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    Server Chassis Features ................1-3 System Power ....................1-3 Hard Drive Subsystem ..................1-3 Front Control Panel ..................1-3 Cooling System ....................1-3 Contacting Supermicro ..................1-5 Chapter 2 Server Installation Overview ......................2-1 Unpacking the System ..................2-1 Preparing for Setup ..................2-1 Choosing a Setup Location ................
  • Page 7 Table of Contents Control Panel Buttons ..................3-1 Reset ....................... 3-1 Power ......................3-1 Control Panel LEDs ..................3-2 Power Fail ....................... 3-2 Universal Information LED ................3-2 NIC1 ........................ 3-2 NIC2 ........................ 3-3 HDD ......................... 3-3 Power ......................3-3 Drive Carrier LEDs ..................
  • Page 8 UPER ERVER 6027R-CDNRT+ User's Manual Connecting Power Cables ................5-6 Connecting the Control Panel ................. 5-6 I/O Ports ......................5-7 Installing Memory .................... 5-8 Memory Support ....................5-8 Adding PCI Expansion Cards ................5-11 Serverboard Details ..................5-12 X9DRD-CNT+ Quick Reference ..............5-13 Connector Definitions ..................
  • Page 9 Table of Contents Advanced Setup Configurations..............7-4 Event Logs ....................7-26 IPMI ....................... 7-28 Boot ....................... 7-30 Security ......................7-31 Save & Exit ....................7-32 Appendix A BIOS Error Beep Codes Appendix B System Specifications...
  • Page 10 UPER ERVER 6027R-CDNRT+ User's Manual Notes...

  • Page 11: Chapter 1 Introduction

    SC826BAC4-R920WB chassis and the X9DRD-CNT+ serverboard. Please refer to our website for information on operating systems that have been certified for use with the system (www.supermicro.com). In addition to the serverboard and chassis, various hardware components have been included with the 6027R-CDNRT+, as listed below: •...

  • Page 12: Serverboard Features

    The X9DRD-CNT+ supports single or dual Intel® Xeon E5-2600 (v2) series proces- sors in R3-LGA2011 sockets. Please refer to our website for a complete listing of supported processors (www.supermicro.com). Memory The X9DRD-CNT+ has 24 DIMM sockets that can support up to 1.5 TB of ECC LRDIMM, 768 GB of ECC RDIMM or 384 GB of ECC/non-ECC UDIMM DDR3- 2133/1866/1600 memory.

  • Page 13: Pci Expansion

    Chapter 1: Introduction PCI Expansion Two riser cards have been pre-installed in the system to support PCI expansion cards. The RSC-R2UW-2E8E16+ can support two full-height, half-length PCI-E 3.0 x8 cards and one full-height, half-lenght PCI-E 3.0 x16 card. The RSC-R2UW-E8R- UP can support one low-profile PCI-E 3.0 x8 card.

  • Page 14: System Block Diagram

    UPER ERVER 6027R-CDNRT+ User's Manual Figure 1-1. Intel C602 Chipset: System Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. JNVME4 JNVME3 JNVME2 JNVME1 3108 CPU REAR U7C1 Socket 01 PROCESSOR#2 U7C1 U6H1 CPU FRONT U6H1 Socket 00 PROCESSOR#1...

  • Page 15: Contacting Supermicro

    Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...
  • Page 16 UPER ERVER 6027R-CDNRT+ User's Manual Notes...

  • Page 17: Chapter 2 Server Installation

    Chapter 2: Server Installation Chapter 2 Server Installation Overview This chapter provides a quick setup checklist to get your 6027R-CDNRT+ up and running. Following these steps in the order given should enable you to have the system operational within a minimum amount of time. This quick setup assumes that your system has come to you with the processors and memory preinstalled.

  • Page 18: Warnings And Precautions

    UPER ERVER 6027R-CDNRT+ User's Manual • This product is for installation only in a Restricted Access Location (dedicated equipment rooms, service closets and the like). • This product is not suitable for use with visual display work place devices acccording to §2 of the the German Ordinance for Work with Visual Display Units. Warnings and Precautions Rack Precautions •...

  • Page 19: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (Tmra).

  • Page 20: Installing The System Into A Rack

    UPER ERVER 6027R-CDNRT+ User's Manual Installing the System into a Rack This section provides information on installing the SC826 chassis into a rack unit with the quick-release rails provided. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly. You should also refer to the installation instructions that came with the rack unit you are using.
  • Page 21 Chapter 2: Server Installation Figure 2-1. Separating the Rack Rails Separating the Inner and Outer Rails Rail Assembly SCREW 1. Locate the rail assembly in the chassis packaging. Extending the Rails 2. Extend the rail assembly by pulling it outward. 3.

  • Page 22: Outer Rack Rails

    UPER ERVER 6027R-CDNRT+ User's Manual SCREW screw the handles the outer rails for secure purpose if necessary Figure 2-2. Assembling the Outer Rails Outer Rack Rails Outer rails attach to the rack and hold the chassis in place. The outer rails for the SC826 chassis extend between 30 inches and 33 inches.
  • Page 23 Chapter 2: Server Installation SCREW Figure 2-3. Installing the Rack Rails Installing the Chassis into a Rack 1. Extend the outer rails as illustrated above. 2. Align the inner rails of the chassis with the outer rails on the rack. 3.
  • Page 24 UPER ERVER 6027R-CDNRT+ User's Manual Notes...

  • Page 25: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel as well as others on the drive carri- ers to keep you constantly informed of the overall status of the system as well as the activity and health of specific components.

  • Page 26: Control Panel Leds

    UPER ERVER 6027R-CDNRT+ User's Manual Control Panel LEDs The control panel located on the front of the chassis has several LEDs. These LEDs provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective action you may need to take.

  • Page 27: Nic2

    Chapter 3: System Interface NIC2 Indicates network activity on the LAN2 port when flashing. On the 6027R-CDNRT+, this LED indicates hard drive activity when flashing. Power Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating. Drive Carrier LEDs The chassis includes externally accessible SAS/SATA/NVMe drives.

  • Page 28: Nvme

    UPER ERVER 6027R-CDNRT+ User's Manual NVMe The NVM Express ports provide high-speed, low-latency connections directly from the CPU to NVMe Solid State drives (SSDs). This greatly increases SSD throughput and significantly reduces storage device latency by simplifying driver and software requirements resulting from the direct PCI-E interface between the CPU and the NVMe SSD drives.

  • Page 29: About Standardized Warning Statements

    Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our web site at http://www.supermicro.com/ about/policies/safety_information.cfm. Warning Definition Warning! This warning symbol means danger.
  • Page 30 UPER ERVER 6027R-CDNRT+ User's Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 31 Warning Statements for AC Systems ‫جسذٌة‬ ‫اصابة‬ ً‫تتسبب ف‬ ‫حالة ٌوكي أى‬ ً‫اًك ف‬ ‫خطز‬ ًٌ‫ٌع‬ ‫هذا الزهز‬ !‫تحذٌز‬ ‫الذوائز‬ ‫بالوخاطز الٌاجوة عي‬ ‫ي على علن‬ ، ‫ك‬ ‫هعذات‬ ‫تعول على أي‬ ‫قبل أى‬ ‫الكهزبائٍة‬ ‫حىادث‬ ‫أي‬ ‫وقىع‬ ‫وٌع‬ ‫ل‬ ‫الىقائٍة‬...

  • Page 32: Installation Instructions

    UPER ERVER 6027R-CDNRT+ User's Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 33: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A.. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、...

  • Page 34: Power Disconnection Warning

    UPER ERVER 6027R-CDNRT+ User's Manual 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지 않도록 해야 합니다. Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A.
  • Page 35 Chapter 4: Warning Statements for AC Systems ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema. Attention Le système doit être débranché...

  • Page 36: Equipment Installation

    UPER ERVER 6027R-CDNRT+ User's Manual Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden.

  • Page 37: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalificeerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 38: Battery Handling

    UPER ERVER 6027R-CDNRT+ User's Manual ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .)'‫כלי אבטחה בלבד (מפתח, מנעול וכד‬ ‫محظورة‬ ‫مناطق‬ ٍ‫نتركُبها ف‬ ‫هذه انىحذة‬ ‫تخصيص‬ ‫تم‬ ،‫أداة خاصت‬ ‫من خالل استخذاو‬ ‫فقط‬...
  • Page 39 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 40: Redundant Power Supplies

    UPER ERVER 6027R-CDNRT+ User's Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 41: Backplane Voltage

    Chapter 4: Warning Statements for AC Systems ‫امداد الطاقة‬ ‫بوحدات‬ ‫عدة اتصاالت‬ ‫جهاز‬ ‫ال‬ ‫يكون لهذا‬ ‫قد‬ ‫الكهرباء‬ ‫عن‬ ‫وحدة‬ ‫ال‬ ‫لعسل‬ ‫كافة االتصاالت‬ ‫يجب إزالة‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 42: Comply With Local And National Electrical Codes

    UPER ERVER 6027R-CDNRT+ User's Manual ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬ ‫اللىحة‬ ‫أوالطاقة المىجىدة على‬ ‫التيار الكهزبائي‬ ‫مه‬ ‫خطز‬ ‫هناك‬ ‫هذا الجهاس‬ ‫خدمة‬ ‫كه حذرا عند‬ ‫يعمل‬ ‫النظام‬ ‫عندما يكىن‬ 경고! 시스템이...

  • Page 43: Product Disposal

    Chapter 4: Warning Statements for AC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬ ‫المتعلقة‬ ‫المحلية والىطىية‬ ‫قىاويه‬ ‫يجب أن يمتثل لل‬ ‫الكهربائية‬...

  • Page 44: Hot Swap Fan Warning

    UPER ERVER 6027R-CDNRT+ User's Manual ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent.
  • Page 45 Chapter 4: Warning Statements for AC Systems 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 46: Power Cable And Ac Adapter

    Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certified cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only. 電源コードとACアダプター 製品を設置する場合、 提供または指定された接続ケーブル、 電源コードとACアダプター...
  • Page 47 Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifiés qui ont UL ou CSA indiqué sur le code pour tous les autres appareils électriques que les produits désignés par Supermicro seulement.
  • Page 48 UPER ERVER 6027R-CDNRT+ User's Manual Notes 4-20...

  • Page 49: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to install processors and heatsinks to the X9DRD-CNT+ serverboard, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are described and a layout and quick reference chart are included in this chapter.

  • Page 50: Processor And Heatsink Installation

    CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. • Refer to the Supermicro website for updates on CPU support. Installing a Processor Press down on the lever labeled 'Close 1st' 1.
  • Page 51 Chapter 5: Advanced Serverboard Setup 3. With the lever labeled 'Close 1st' fully retracted, gently push down on the 'Open 1st' lever to open the load plate. Lift the load plate to open it completely. Gently push 4. Using your thumb and the index down to pop the load plate finger, remove the 'WARNING'...
  • Page 52 UPER ERVER 6027R-CDNRT+ User's Manual Warning: You can only install the CPU to the socket in one direction. Make sure that the CPU is properly inserted into the socket before closing the load plate. If it doesn't close properly, do not force it as it may damage your CPU. Instead, open the load plate again and double-check that the CPU is aligned properly.

  • Page 53: Installing A Cpu Heatsink

    Chapter 5: Advanced Serverboard Setup Installing a CPU Heatsink 1. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the retention mechanism. 2. Screw in two diagonal screws (i.e. the #1 and the #2 screws) until just snug (do not over-tighten the screws, which may damage the CPU.) 3.

  • Page 54: Connecting Cables

    UPER ERVER 6027R-CDNRT+ User's Manual Connecting Cables Now that the processors are installed, the next step is to connect the cables to the serverboard. These include the data (ribbon) cables for the peripherals and control panel and the power cables. Connecting Data Cables The cables used to transfer data from the peripheral devices have been carefully routed in preconfigured systems to prevent them from blocking the flow of cooling...

  • Page 55: I/O Ports

    Chapter 5: Advanced Serverboard Setup Figure 5-1. Front Control Panel Header Pins (JF1) Ground P3V3-LED FP PWRLED ID_UID_SW/3/3V Stby HDD LED NIC1 Link NIC1 Activity NIC2 Activity NIC2 Link Blue+ (OH/Fan Fail/ Red+ (Blue LED Cathode) PWR FaiL/UID LED) Power Fail LED P3V3-LED Reset Reset Button...

  • Page 56: Installing Memory

    Twenty-four DIMM sockets support up to 1.5 TB of ECC LRDIMM, 768 GB of ECC RDIMM or 384 GB of ECC/non-ECC UDIMM DDR3-2133/1866/1600 memory. Note: Check the Supermicro website for the latest memory support information. Processors and their Corresponding Memory Modules...
  • Page 57 1333 1333 DRx8 1066, 1066, 1066 1066, 1066 1066, 1066, 1066, 1333 1333 1333 1333, 1333 1333 Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm.
  • Page 58 800, 1066 1066 Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm. Intel E5-2600 Series Processor RDIMM Memory Support Ranks Memory Capacity Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and DIMM Per Channel...

  • Page 59: Adding Pci Expansion Cards

    1066 1066 (QDP) Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm. Intel E5-2600 Series Processor LRDIMM Memory Support Ranks Memory Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and DIMM Per...

  • Page 60: Serverboard Details

    UPER ERVER 6027R-CDNRT+ User's Manual Serverboard Details Figure 5-4. SUPER X9DRD-CNT+ Layout JVGA1 JCOM1 JLAN2 JLAN1 JUSBKM JUSBRJ45 COM1 LAN CTRL USB2/3 USB0/1 KB/MOUSE IPMI_LAN Battery CPU2 CLOSE 1st OPEN 1st X9DRD-iT+/C(N)T+ Rev. 1.00 JBT1 SAN MAC MAC CODE IPMI CODE JSMB_HP_P1 JNVME4 BIOS...

  • Page 61: X9Drd-Cnt+ Quick Reference

    Chapter 5: Advanced Serverboard Setup X9DRD-CNT+ Quick Reference Jumper Description Default Setting JBT1 Clear CMOS See Section 5-9 C1/JI SMB to PCI-E Slots Pins 2-3 (Disabled) JPB1 BMC Enable/Disable Pins 1-2 (Enabled) JBR1 BIOS Recovery Enable/Disable Pins 1-2 (Normal) JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPL1...
  • Page 62 UPER ERVER 6027R-CDNRT+ User's Manual SW1 (UID) UID (Unit Identification) Switch T-SGPIO-S Serial Link General Purpose I/O Headers for S-SATA0-3 Ports T-SGPIO1/2 Serial Link General Purpose I/O Headers for I-SATA0-5 (T-SGPIO1: I-SATA0-3, T-SGPIO2: I-SATA4/5) Description State Status PWR LED Green: On MB PWR On UID LED Blue: On...

  • Page 63: Connector Definitions

    Chapter 5: Advanced Serverboard Setup Connector Definitions ATX Power 24-pin Connector Pin Definitions ATX Power Connector Pin# Definition Pin # Definition +3.3V +3.3V The 24-pin main power connector -12V +3.3V (JPW1) is used to provide power to the serverboard. Two 8-pin power PS_ON connectors (JPW2/3) are also re- quired for processor power (below).
  • Page 64 UPER ERVER 6027R-CDNRT+ User's Manual NIC1/NIC2 LED Indicators NIC1/2 LED The NIC (Network Interface Control- Pin Definitions (JF1) ler) LED connections for LAN ports 1 Pin# Definition and 2 are located on pins 11 and 12 NIC2 Activity LED and 9 and 10 of JF1, respectively. At- NIC2 Link LED tach NIC LED cables here to display NIC1 Activity LED...
  • Page 65 Chapter 5: Advanced Serverboard Setup Power Button The Power Button connection is located on pins 1 and 2 of JF1. Mo- Power Button Pin Definitions (JF1) mentarily contacting both pins will Pin# Definition power on/off the system. To turn off Signal the power when set to suspend mode, Ground...

  • Page 66: Chassis Intrusion

    UPER ERVER 6027R-CDNRT+ User's Manual Internal Speaker Internal Buzzer Pin Definition The Internal Speaker (SP1) can be Pin# Definitions used to provide audible indications for Pin 1 Pos. (+) P5V_SPK various beep codes. See the table on Pin 2 Neg. (-) SPKR_IN the right for pin definitions.
  • Page 67 Fan Fail SuperDOM Connector SuperDOM Connector A powered SATADOM (Device-on- Pin Definitions Module) connector at JSD1 may be Pin# Definition used with Supermciro SuperDOMs to provide backward-compatible power Ground support to non-Supermicro SATA- Ground DOMs that require external power. 5-19...
  • Page 68 Color/State Status installed in a rack. Blue: On Unit Identified Note: UID can also be triggered via IPMI on the serverboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website at http://www.supermicro. com. 5-20...

  • Page 69: Jumper Settings

    Chapter 5: Advanced Serverboard Setup Jumper Settings Explanation of Jumpers To modify the operation of the serverboard, jumpers can be used Connector to choose between optional settings. Pins Jumpers create shorts between two pins to change the function of the Jumper connector.
  • Page 70 UPER ERVER 6027R-CDNRT+ User's Manual LAN1/2 Enable/Disable LAN Enable/Disable Change the setting of jumper JPL1 to Jumper Settings enable or disable the onboard Ether- Jumper Setting Definition net (RJ45) ports LAN1 and LAN2. See Pins 1-2 Enabled the table on the right for jumper set- Pins 2-3 Disabled tings.
  • Page 71 Chapter 5: Advanced Serverboard Setup Manufacture Mode Select Close pin 2 and pin 3 of jumper ME Mode Select JPME2 to bypass SPI flash security Jumper Settings and force the system to operate in Jumper Setting Definition the Manufacture Mode, allowing the Pins 1-2 Normal user to flash the system firmware...

  • Page 72: 5-10 Onboard Indicators

    UPER ERVER 6027R-CDNRT+ User's Manual 5-10 Onboard Indicators LAN Port LEDs The two 10 Gb Ethernet ports (located LAN LED each have two LEDs. One LED indi- Connection Speed Indicator cates activity when blinking while the LED Color Definition other LED may be green, amber or off No connection, 10 Mb/s, 100 Mb/s to indicate the speed of the connec- Green...
  • Page 73 Chapter 5: Advanced Serverboard Setup SAS Heartbeat LED SAS Heartbeat LED A SAS Heartbeat LED is located at States LEDS2. When LEDS2 is blinking, Color/State Definition SAS is functioning normally. See the Green: SAS Normal table on the right for more informa- Blinking tion.

  • Page 74: 5-11 Sata Ports

    S-SATA ports (S-SATA0-3) are provided, which are supported by Intel SCU. Notes: For more information on SATA HostRAID configuration, please refer to the Intel SATA HostRAID User's Guide posted on our website at www.supermicro.com. 5-12 NVMe Ports Four NVMe Express ports are provided on the serverboard. These NVMe ports provide PCI-Exp.

  • Page 75: 5-13 Installing Software

    Chapter 5: Advanced Serverboard Setup 5-13 Installing Software The Supermicro ftp site contains drivers and utilities for your system at ftp://ftp. supermicro.com. Some of these must be installed, such as the chipset driver. After accessing the ftp site, go into the CDR_Images directory and locate the ISO file for your serverboard.

  • Page 76: Superdoctor® 5

    ERVER 6027R-CDNRT+ User's Manual SuperDoctor® 5 The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface in Windows and Linux operating systems. The program moni- tors system health information such as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 77: 5-14 Onboard Battery

    Chapter 5: Advanced Serverboard Setup 5-14 Onboard Battery Care must be taken to assure that the chassis cover is in place when the system is operating to assure proper cooling. Out of warranty damage to the system can occur if this practice is not strictly followed. Figure 5-7.
  • Page 78 UPER ERVER 6027R-CDNRT+ User's Manual Notes 5-30...

  • Page 79: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform mainte- nance on the SC826BAC4-R920WB chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the step that follows.

  • Page 80: Control Panel

    UPER ERVER 6027R-CDNRT+ User's Manual Figure 6-1. Front and Rear Chassis Views Control Panel SATA/NVMe Hard Drives (12) Note: NVMe drive bays are outlined above (four total). Power Supplies PCI Expansion Slots I/O Ports Control Panel The control panel (located on the front of the chassis) must be connected to the JF1 connector on the serverboard to provide you with system status indications.

  • Page 81: System Fans

    Chapter 6: Advanced Chassis Setup Figure 6-2. Removing the Chassis Cover System Fans Three 8-cm hot-swap fans provide the cooling for the system. It is very important that the chassis top cover is properly installed and making a good seal in order for the cooling air to circulate properly through the chassis and cool the components.

  • Page 82: Replacing System Fans

    UPER ERVER 6027R-CDNRT+ User's Manual Replacing System Fans 1. If necessary, open the chassis while the power is running to determine which fan requires changing. (Never run the server for an extended period of time with the chassis open.) 2. Press the fan release tab to lift the failed fan from the chassis and pull it completely from the chassis.

  • Page 83: Drive Bay Installation/Removal

    2. Secure the drive to the carrier with four screws, as shown in Figure 6-4. Caution: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro...
  • Page 84 UPER ERVER 6027R-CDNRT+ User's Manual Figure 6-4. Removing a Hard Drive Carrier Caution: Regardless of how many hard drives are installed, all drive carriers must remain in the drive bays to maintain proper airflow.

  • Page 85: Hard Drive Backplane

    Chapter 6: Advanced Chassis Setup Figure 6-5. Mounting a Drive in a Carrier Hard Drive Backplane The hard drives plug into a backplane (p/n BPN-SAS3-826A-N4) that provides power, drive ID and bus termination. The supplied RAID controller provides hot-swap capability with drive state indication. The backplane is already preconfigured, so no jumper or switch configurations are required.

  • Page 86: Power Supply

    The Power Fail LED on the front control panel will illuminate and remain on until the failed unit has been replaced. Replacement units can be ordered directly from Supermicro. The power supply units have a hot-swap capability, meaning you can replace the failed unit without powering down the system.
  • Page 87 Chapter 6: Advanced Chassis Setup Figure 6-7. Removing the Power Supply Release Tab Handle...
  • Page 88 UPER ERVER 6027R-CDNRT+ User's Manual Notes 6-10...

  • Page 89: Chapter 7 Bios

    Chapter 7: BIOS Chapter 7 BIOS Introduction This chapter describes the AMI BIOS setup utility for the X9DRD-iT+/CT+/CNT+. It also provides the instructions on how to navigate the AMI BIOS setup utility screens. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated. Starting BIOS Setup Utility To enter the AMI BIOS setup utility screens, press the <Del>...

  • Page 90: Starting The Setup Utility

    UPER ERVER 6027R-CDNRT+ User's Manual Note: For AMI UEFI BIOS Recovery, please refer to the UEFI BIOS Recov- ery User Guide posted @ http://www.supermicro.com/support/manuals/. Starting the Setup Utility Normally, the only visible Power-On Self-Test (POST) routine is the memory test.
  • Page 91 This item displays the system date in Day MM/DD/YY format (e.g. Wed 05/28/2014). System Time This item displays the system time in HH:MM:SS format (e.g. 15:32:52). Supermicro X9DRD-iT+/CT+/CNT+ Version This item displays the SMC version of the BIOS ROM used in this system.

  • Page 92: Advanced Setup Configurations

    UPER ERVER 6027R-CDNRT+ User's Manual Advanced Setup Configurations Use the arrow keys to select Advanced setupand press <Enter> to access the fol- lowing submenu items. Boot Features Quiet Boot This feature allows the user to select bootup screen display between POST mes- sages and the OEM logo.

  • Page 93: Power Configuration

    Chapter 7: BIOS Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Enabled, the ROM BIOS of the host adaptors will "capture" Interrupt 19 at bootup and allow the drives that are attached to these host adaptors to function as bootable disks.
  • Page 94 UPER ERVER 6027R-CDNRT+ User's Manual Socket 1 CPU Information/Socket 2 CPU Information  This submenu displays the following information regarding the CPUs installed in Socket 1/ Socket 2. • Type of CPU • CPU Signature • Microcode Patch • CPU Stepping •...
  • Page 95 Chapter 7: BIOS RTID (Record Types IDs) This feature displays the total number of Record Type IDs for local and remote pools. The options are Optimal and Alternate. Hyper-threading Select Enabled to support Intel Hyper-threading Technology to enhance CPU per- formance.

  • Page 96: Cpu Power Management Configuration

    UPER ERVER 6027R-CDNRT+ User's Manual DCU Streamer Prefetcher (Available when supported by the CPU) Select Enabled to support Data Cache Unit (DCU) prefetch of L1 data to speed up data accessing and processing in the DCU to enhance CPU performance. The options are Disabled and Enabled.
  • Page 97 Chapter 7: BIOS Turbo Mode (Available when Power Technology is set to Custom) Select Enabled to use the Turbo Mode to boost system performance. The options are Enabled and Disabled. C1E Support (Available when Power Technology is set to Custom) Select Enabled to enable Enhanced C1 Power State to boost system per- formance.

  • Page 98: Chipset Configuration

    UPER ERVER 6027R-CDNRT+ User's Manual Long Duration Maintained This item displays the period of time during which long duration power is main- tained. Recommended Short Duration Power This item displays the short duration power settings recommended by the manufacturer. Short Duration Power Limit This item displays the time period during which short duration power is main- tained.

  • Page 99: Qpi Configuration

    Chapter 7: BIOS MMCFG Base Use this setting to set the default PCI MMIO base address. The default setting is 0x90000000. Left Riser Card/Right Riser Card When detected by the BIOS, these items display riser card information. IIO 1 PCIe Port Bifurcation Control This submenu configures the following IO PCIe Port Bifurcation Control settings for IIO 1 PCIe ports to determine how the available PCI-Express lanes to be distributed between the PCI-Exp.

  • Page 100: Dimm Configuration

    UPER ERVER 6027R-CDNRT+ User's Manual QPI (Quick Path Interconnect) Link Speed Mode Use this feature to select data transfer speed for QPI Link connections. The options are Fast and Slow. QPI Link Frequency Select Use this feature to select the desired QPI frequency. The options are Auto, 6.4 GT/s, 7.2 GT/s, and 8.0 GT/s.
  • Page 101 Chapter 7: BIOS DDR Speed Use this feature to force a DDR3 memory module to run at a frequency other than what is specified in the specification. The options are Auto, Force DDR3 800, Force DDR3 1066, Force DDR3 1333, Force DDR3 1600, Force DDR3 1866, and Force SPD.

  • Page 102: South Bridge Configuration

    UPER ERVER 6027R-CDNRT+ User's Manual Thermal Throttling Throttling improves reliability and reduces power consumption in the proces- sor via automatic voltage control during processor idle states. The options are Disabled and CLTT (Closed Loop Thermal Throttling). Double Refresh Select Enabled for Double Refresh support which will achieve memory stability when the memory temperature is high.

  • Page 103: Sata Configuration

    Chapter 7: BIOS EHCI Hand-Off This item is for operating systems that do not support Enhanced Host Controller Interface (EHCI) hand-off. When enabled, EHCI ownership change will be claimed by the EHCI driver. The options are Disabled and Enabled. SATA Configuration When this submenu is selected, the AMI BIOS automatically detects the presence of IDE or SATA devices and displays the following items.
  • Page 104 UPER ERVER 6027R-CDNRT+ User's Manual Staggered Spin-Up Select Enabled to enable Staggered Spin-up support to prevent excessive power consumption caused by multiple HDDs spinning-up simultaneously. The options are Enabled and Disabled. RAID Mode The following items are displayed when RAID Mode is selected: SATA RAID Option ROM/UEFI Driver Select Enabled to support onboard SATA RAID Option ROM which will allow the user to bootup the system using a SATA RAID device.
  • Page 105 Chapter 7: BIOS PERR# Generation Select Enabled to allow a PCI device to generate a PERR (PCI/PCIE Parity Error) number for a PCI Bus Signal Error Event. The options are Enabled and Disabled. SERR# Generation Select Enabled to allow a PCI device to generate an SERR (System Error) number for a PCI Bus Signal Error Event.

  • Page 106: Super Io Configuration

    UPER ERVER 6027R-CDNRT+ User's Manual VGA Priority This feature allows the user to select the graphics adapter to be used as the primary boot device. The options are Onboard, and Offboard. Network Stack Select Enabled enable PXE (Preboot Execution Environment) or UEFI (Unified Extensible Firmware Interface) for network stack support.
  • Page 107 Chapter 7: BIOS Change Settings This option specifies the base I/O port address and the Interrupt Request address of COM Port 2. The options are Auto, IO=3F8h; IRQ=4; IO=3F8h; IRQ=3; IO=2F8h; IRQ=3; IO=3E8h; IRQ=5; IO=2E8h; IRQ=7; IO=3F8h; IRQ=3, 4, 5, 6, 7, 10, 11, 12; IO=2F8h;...
  • Page 108 UPER ERVER 6027R-CDNRT+ User's Manual Terminal Type Use this feature to select the target terminal emulation type for Console Redirec- tion. Select VT100 to use the ASCII Character set. Select VT100+ to add color and function key support. Select ANSI to use the Extended ASCII Character Set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters into one or more bytes.
  • Page 109 Chapter 7: BIOS Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages to a remote server. The options are Disabled and Enabled. Resolution 100x31 Select Enabled for extended-terminal resolution support. The options are Dis- abled and Enabled.

  • Page 110: Acpi Settings

    UPER ERVER 6027R-CDNRT+ User's Manual Console Redirection Settings (for EMS)  Use this feature to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user. Out-of-Band Management Port The feature selects a serial port used by the Microsoft Windows Emergency Management Services (EMS) to communicate with a remote server.

  • Page 111: Tpm Enable Status

    Chapter 7: BIOS (such as RAMs) to maintain the most critical functions of the system. The options are S1 (CPU_Stop_Clock), Suspend and Disabled. NUMA (NON-Uniform Memory Access) Select Enabled to enable the Non-Uniform Memory Access ACPI support. The op- tions are Enabled and Disabled. High Precision Event Timer Select Enabled to activate the High Precision Event Timer (HPET) that produces periodic interrupts at a much higher frequency than a Real-time Clock (RTC) does...
  • Page 112 UPER ERVER 6027R-CDNRT+ User's Manual TPM Owner Status This item displays the status of TPM Ownership. ME (Management Engine) Subsystem Configuration This feature displays the following Intel ME Subsystem Configuration settings. • ME BIOS Interface Version • ME Version Intel RSTe SCU (Storage Controller Unit) Controller (Available on the X9DRD-CNT+ Only) This submenu is used to configure the SCU settings.
  • Page 113 Chapter 7: BIOS Status: Bootable Port 0  The following information will be displayed: Physical Disk Information Disk Actions Reset to Non-RAID  Select Yes to reset the RAID drive installed in a SuperDOM device specified by the user to non-RAID. All RAID configuration settings will be removed from this disk drive.

  • Page 114: Event Logs

    UPER ERVER 6027R-CDNRT+ User's Manual Event Logs Use this feature to configure Event Log settings. Change SMBIOS Event Log Settings  This feature allows the user to configure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.
  • Page 115 Chapter 7: BIOS Erasing Settings Erase Event Log Select Enabled to erase the SMBIOS (System Management BIOS) Event Log, which is completed before a event logging is initialized upon system reboot. The options are No, Yes, Next reset, and Yes, Every reset. When Log is Full Select Erase Immediately to immediately erase SMBIOS error event logs that ex- ceed the limit when the SMBIOS event log is full.

  • Page 116: Ipmi

    UPER ERVER 6027R-CDNRT+ User's Manual IPMI Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. The following IPMI information will be displayed: IPMI Firmware Revision IPMI Status System Event Log  Enabling/Disabling Options SEL Components Select Enabled for all system event logging at bootup. The options are Enabled and Disabled.

  • Page 117: Bmc Network Configuration

    Chapter 7: BIOS Customize EFI Logging Options Log EFI Status Codes Select Enabled to log EFI (Extensible Firmware Interface) Status Codes, Error Codes or Progress Codes. The options are Enabled and Disabled. Note: After making changes on a setting, be sure to reboot the system for the changes to take effect.

  • Page 118: Boot

    UPER ERVER 6027R-CDNRT+ User's Manual Boot This submenu allows the user to configure the following boot settings for the system. Set Boot Priority This option prioritizes the order of bootable devices that the system to boot from. Press <Enter> on each entry from top to bottom to select devices. 1st Boot Device ~ 6th Boot Device ...

  • Page 119: Security

    Chapter 7: BIOS Security This menu allows the user to configure the following security settings for the system. Password Check Select Setup for the system to prompt for a password at Setup. Select Always for the system to prompt for a password at bootup and upon entering the BIOS setup utility.

  • Page 120: Save & Exit

    UPER ERVER 6027R-CDNRT+ User's Manual Save & Exit This submenu allows the user to configure the Save and Exit settings for the system. Discard Changes and Exit Select this option to quit the BIOS setup without making any permanent changes to the system configuration, and reboot the computer.
  • Page 121 Chapter 7: BIOS Discard Changes Select this feature and press <Enter> to discard all the changes and return to the BIOS setup. When the dialog box appears, asking you if you want to load previ- ous values, click Yes to load the values previous saved, or click No to keep the changes you've made so far.
  • Page 122 UPER ERVER 6027R-CDNRT+ User's Manual Notes 7-34...

  • Page 123: Appendix A Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed at each system boot, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue to boot.
  • Page 124 UPER ERVER 6027R-CDNRT+ User's Manual Notes...

  • Page 125: Appendix B System Specifications

    Appendix B: System Specifications Appendix B System Specifications Processors Dual Intel® Xeon E5-2600 v2 series processors in an R3-LGA2011 sockets Note: Please refer to our web site for a complete listing of supported processors. Chipset Intel C602 chipset BIOS 128 Mb Award® SPI Flash ROM Memory Capacity Twenty-four DIMM sockets that support up to 1.5 TB of ECC LRDIMM, 768 GB of ECC RDIMM or 384 GB of ECC/non-ECC UDIMM DDR3-2133/1866/1600...

  • Page 126: System Cooling

    UPER ERVER 6027R-CDNRT+ User's Manual Serverboard X9DRD-CNT+ Dimensions: 13.68" x 13.4" in (347.5x 340.4 mm) Chassis SC826BAC4-R920WB (2U rackmount) Dimensions: (WxHxD) 17.2 x 3.5 x 25.5 in. (437 x 89 x 648 mm) Weight Gross Weight: 64 lbs. (29 kg.) System Cooling Three 8-cm system cooling fans System Input Requirements...
