Supermicro 6027TR-H70QRF User Manual

page of 134

/ 134
Contents
Table of Contents
Bookmarks

Table of Contents

Quick Links

Download this manual

UPER

SUPERSERVER

6027TR-H70QRF

6027TR-H70FRF

6027TR-H70RF

USER'S MANUAL

Revision 1.0a

Table of Contents

Summary of Contents for Supermicro 6027TR-H70QRF

Page 1 UPER ® SUPERSERVER 6027TR-H70QRF 6027TR-H70FRF 6027TR-H70RF USER'S MANUAL Revision 1.0a...
Page 2 This product, including software and documentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.
Page 3: About This Manual
Chapter 2: Server Installation This chapter describes the steps necessary to install the SuperServer 6027TR-H70QRF/H70FRF/H70RF into a rack and check out the server conﬁ guration prior to powering up the system. If your server was ordered without processor and memory components, this chapter will refer you to the appropriate sections of the manual for their installation.
Page 4 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Chapter 4: System Safety You should thoroughly familiarize yourself with this chapter for a general overview of safety precautions that should be followed when installing and servicing the SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF. Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X9DRT-HIBQF/HIBFF/HF serverboard, including the locations and functions of connections, headers and jumpers.
Page 5 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Notes...
Page 6: Table Of Contents
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 SAS ......................... 1-2 PCI Expansion Slots ..................1-2 Onboard Controllers/Ports ................1-3 Graphics Controller ..................1-3 Inﬁ niBand ......................1-3 Other Features ....................
Page 7 Table of Contents Rack Mounting Considerations ............... 2-3 Ambient Operating Temperature ..............2-3 Reduced Airﬂ ow ..................2-3 Mechanical Loading ................... 2-3 Circuit Overloading ..................2-3 Reliable Ground ..................2-4 Installing the System into a Rack ..............2-4 Separating the Sections of the Rack Rails ............. 2-5 Installing the Inner Rail Extension ..............
Page 8 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Chapter 5 Advanced Motherboard Setup Handling the Motherboard ................5-1 Precautions ..................... 5-1 Unpacking ....................... 5-1 Connecting Cables ..................5-2 Connecting Data Cables ................. 5-2 Rear I/O Ports ....................5-3 Processor and Heatsink Installation..............5-4 Installing a Passive CPU Heatsink ..............5-8 Removing the Heatsink ...................
Page 9 Table of Contents Installing the Motherboard ................6-11 I/O Shield .......................6-11 Permanent and Optional Standoffs ..............6-11 Adapter Card Replacement................6-13 Add-on Card/Expansion Slot Setup .............. 6-14 6-10 Drive Bay Installation/Removal ..............6-15 Accessing the Drive Bays ................6-15 6-11 Power Supply ....................6-19 Power Supply Replacement ................
Page 10 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Notes...
Page 11: Chapter 1 Introduction
Chapter 1 Introduction Overview The SuperServer 6027TR-H70QRF/H70FRF/H70RF is a high-end server comprised of two main subsystems: the SC827HQ-R1620B 2U server chassis and the X9DRT-HIBQF/HIBFF/HF dual processor serverboard in four hot-swap nodes. Please refer to our web site for information on operating systems that have been certiﬁ...
Page 12: Serverboard Features
Processors The X9DRT-HIBQF/HIBFF/HF supports single or dual Intel® Xeon® E5-2600 series processors (Socket R LGA 2011). Please refer to the serverboard description pages on our web site for a complete listing of supported processors (www.supermicro. com). Memory The X9DRT-HIBQF/HIBFF/HF has eight (8) DIMM slots supporting up to 256 GB of DDR3-1600/1333/1066/800 MHz speed registered ECC SDRAM in up to 512 MB, 1 GB, 2 GB, 4 GB, 8 GB, 16 GB or 32 GB sizes at 1.35V or 1.5V...
Page 13: Onboard Controllers/Ports
The X9DRT-HIBQF/HIBFF/HF features an integrated Matrox G200eW Video Controller. Inﬁ niBand The 6027TR-H70QRF server include a QDR (quad data rate) speed Inﬁ niBand QSFP connector. The 6027TR-H70FRF server includes a FDR (fourteen data rate) speed Inﬁ niBand QSFP connector. Inﬁ niBand is a scalable serial communications link intended for connecting processors with high-speed peripherals.
Page 14: Server Chassis Features
SC827HQ-R1620B chassis includes four front panels on the handles of the chassis which control each of the systems. Each control panel on the SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF provides you with system monitoring and control for one server node. LEDs indicate system power, HDD activity, network activity, system overheat and power supply failure.
Page 15: Air Shrouds
Chapter 1: Introduction Air Shrouds The SC827 chassis includes four plastic air shrouds that direct the airﬂ ow where cooling is needed on each serverboard. Always use the air shroud included with your chassis on each serverboard. Mounting Rails The SC827 includes a set of quick-release rails, and can be placed in a rack for secure storage and use.
Page 16: System Block Diagram
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Figure 1-1. AMD C602 Chipset: System Block Diagram Note: This is a general block diagram and may not exactly repre- sent the features on your motherboard. See the previous pages for the actual speciﬁ cations of your motherboard. This block diagram is intended for your reference only.
Page 17: Contacting Supermicro
Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...
Page 18: Twin 2 : System Notes
SAS/SATA Backplane/Drives As a system, the SuperServer 6027TR-H70QRF/H70FRF/H70RF supports the use of twelve SAS/SATA drives. A single SAS/SATA backplane works to apply system- based control for power and fan speed functions, yet at the same time logically connects a set of three SAS/SATA drives to each serverboard.
Page 19: Chapter 2 Server Installation
ﬁ le a damage claim with the carrier who delivered it. Decide on a suitable location for the rack unit that will hold the SuperServer 6027TR-H70QRF/H70FRF/H70RF. It should be situated in a clean, dust-free area that is well ventilated. Avoid areas where heat, electrical noise and electromagnetic ﬁ...
Page 20: Cautions
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Cautions! Choosing a Setup Location • Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches) and approximately 30 inches of clearance in the back of the rack to allow for sufﬁ cient airﬂ ow and ease in servicing.
Page 21: Rack Mounting Considerations
Chapter 2: Server Installation Rack Mounting Considerations Warning! To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to ensure that the system remains stable. The following guidelines are provided to ensure your safety: •...
Page 22: Reliable Ground
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Reliable Ground A reliable ground must be maintained at all times. To ensure this, the rack itself should be grounded. Particular attention should be given to power supply connections other than the direct connections to the branch circuit (i.e. the use of power strips, etc.).
Page 23: Separating The Sections Of The Rack Rails
Chapter 2: Server Installation Separating the Sections of the Rack Rails The chassis package includes two rail assemblies in the rack mounting kit. Each assembly consists of two sections: an inner ﬁ xed chassis rail that secures directly to the server chassis and an outer ﬁ xed rack rail that secures directly to the rack itself (Figure 2-1).
Page 24: Installing The Inner Rail Extension
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Installing the Inner Rail Extension The SC827 chassis includes a set of inner rails in two sections: inner rails and inner rail extensions. The inner rails are pre-attached to the chassis, and do not interfere with normal use of the chassis if you decide not to use a server rack. The inner rail extension is attached to the inner rail to mount the chassis in the rack.
Page 25: Outer Rack Rails
Chapter 2: Server Installation Outer Rack Rails Outer rails attach to the rack and hold the chassis in place. The outer rails for the SC827 chassis extend between 30 inches and 33 inches. Installing the Outer Rails to the Rack (Figure 2-3) 1.
Page 26 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Installing the Chassis into a Rack (Figure 2-4) 1. Extend the outer rails as illustrated above. 2. Align the inner rails of the chassis with the outer rails on the rack. 3. Slide the inner rails into the outer rails, keeping the pressure even on both sides.
Page 27: Checking The Serverboard Setup
Chapter 2: Server Installation Checking the Serverboard Setup After you install the SuperServer 6027TR-H70QRF/H70FRF/H70RF in the rack, you will need to open the unit to make sure the serverboard is properly installed and all the connections have been made. Accessing the inside of the System Before operating the server for the ﬁ...
Page 28: Checking The Drive Bay Setup
Each processor needs its own heat sink. See Chapter 5 for instructions on processor and heat sink installation. 2. Your SuperServer 6027TR-H70QRF/H70FRF/H70RF server system may have come with system memory already installed. Make sure all DIMMs are fully seated in their slots. For details on adding system memory, refer to Chapter 3.
Page 29: Chapter 3 System Interface
Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel and on the drive carriers to keep you constantly informed of the overall status of the system. SC827 models include four front panels on the handles of the chassis which control each of the systems. This chapter explains the meanings of all LED indicators and the appropriate response you may need to take.
Page 30: Information Led
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF SUPERSERVER Control Panel Button Power The main power button on each of the four control panels is used to apply or remove power from the power supply to each of the four systems in the chassis. Turning off system power with this button removes the main power, but keeps standby power supplied to the system.
Page 31: Drive Carrier Leds
Chapter 3: System Interface Drive Carrier LEDs Each drive carrier has two LEDs: SATA Drives • Green: When illuminated, the green LED on the SATA drive carrier indicates drive activity. A connection to the SATA backplane enables this LED to blink on and off when that particular drive is being accessed.
Page 32 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF SUPERSERVER Notes...
Page 33: Chapter 4Standardized Warning Statements For Ac Systems
Only certiﬁ ed technicians should attempt to install or conﬁ gure components. Read this appendix in its entirety before installing or conﬁ guring components in the Supermicro chassis. These warnings may also be found on our web site at http://www.supermicro.com/ about/policies/safety_information.cfm. Warning Deﬁ nition Warning! This warning symbol means danger.
Page 34 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie beﬁ nden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
Page 35 Warning Statements for AC Systems ‫ﺟﺴﺪﻳﺔ‬ ‫ﺍﺻﺎﺑﺔ‬ ‫ﺗﺘﺴﺒﺐ ﻓﻲ‬ ‫ﺣﺎﻟﺔ ﻳﻤﻜﻦ ﺃﻥ‬ ‫ﺍﻧﻚ ﻓﻲ‬ ‫ﺧﻄﺮ‬ ‫ﻳﻌﻨﻲ‬ ‫ﻫﺬﺍ ﺍﻟﺮﻣﺰ‬ !‫ﺗﺤﺬﻳﺮ‬ ‫ﺍﻟﺪﻭﺍﺋﺮ‬ ‫ﺑﺎﻟﻤﺨﺎﻁﺮ ﺍﻟﻨﺎﺟﻤﺔ ﻋﻦ‬ ‫ﻦ ﻋﻠﻰ ﻋﻠﻢ‬ ، ‫ﻛ‬ ‫ﻣﻌﺪﺍﺕ‬ ‫ﺗﻌﻤﻞ ﻋﻠﻰ ﺃﻱ‬ ‫ﻗﺒﻞ ﺃﻥ‬ ‫ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬ ‫ﺣﻮﺍﺩﺙ‬ ‫ﺃﻱ‬ ‫ﻭﻗﻮﻉ‬ ‫ﻤﻨﻊ‬ ‫ﻟ‬ ‫ﺍﻟﻮﻗﺎﺋﻴﺔ‬...
Page 36: Installation Instructions
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 警告将此系统连接电源前,请先阅读安装说明。警告將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.
Page 37: Circuit Breaker
Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. 警告此产品的短路(过载电流)保护由建筑物的供电系统提供,确保短路保护设备的额定电流不大于250V,20A。警告此產品的短路(過載電流)保護由建築物的供電系統提供,確保短路保護設備的額定電流不大於250V,20A。...
Page 38: Power Disconnection Warning
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL ‫ﻓﻲ‬ ‫ﺍﻟﺘﻲ ﺗﻢ ﺗﺜﺒﻴﺘﻬﺎ‬ ‫ﻣﻦ ﺍﻟﺪﻭﺍﺋﺮﺍﻟﻘﺼﻴﺮﺓ‬ ‫ﺍﻟﺤﻤﺎﻳﺔ‬ ‫ﻣﻌﺪﺍﺕ‬ ‫ﻳﻌﺘﻤﺪ ﻋﻠﻰ‬ ‫ﻫﺬﺍ ﺍﻟﻤﻨﺘﺞ‬ ‫ﺍﻟﻤﺒﻨﻰ‬ ‫ﺃﻛﺜﺮ ﻣﻦ‬ ‫ﻟﻴﺲ‬ ‫ﻮﻗﺎﺋﻲ‬ ‫ﺍﻟ‬ ‫ﺍﻟﺠﻬﺎﺯ‬ ‫ﺗﻘﻴﻴﻢ‬ ‫ﺃﻥ‬ ‫ﺗﺄﻛﺪ ﻣﻦ‬ 20A, 250V Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie.
Page 39 Chapter 4: Warning Statements for AC Systems Warnung Das System muss von allen Quellen der Energie und vom Netzanschlusskabel getrennt sein, das von den Spg.Versorgungsteilmodulen entfernt wird, bevor es auf den Chassisinnenraum zurückgreift, um Systemsbestandteile anzubringen oder zu entfernen. ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema.
Page 40: Equipment Installation
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Equipment Installation Warning! Only trained and qualiﬁ ed personnel should be allowed to install, replace, or service this equipment. 警告只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。警告只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualiﬁ ziertem Personal gestattet werden.
Page 41: Restricted Area
Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwaliﬁ ceerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.
Page 42: Battery Handling
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .('‫כלי אבטחה בלבד )מפתח, מנעול וכד‬ ‫ﻣﺤﻈﻮﺭﺓ‬ ‫ﻣﻨﺎﻁﻖ‬ ‫ﻟﺘﺮﻛﻴﺒﻬﺎ ﻓﻲ‬ ‫ﻫﺬﻩ ﺍﻟﻮﺣﺪﺓ‬ ‫ﺗﺨﺼﻴﺺ‬ ‫ﺗﻢ‬ ،‫ﺃﺩﺍﺓ ﺧﺎﺻﺔ‬ ‫ﻣﻦ ﺧﻼﻝ ﺍﺳﺘﺨﺪﺍﻡ‬...
Page 43 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.
Page 44: Redundant Power Supplies
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 警告此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。警告此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.
Page 45: Backplane Voltage
Chapter 4: Warning Statements for AC Systems ‫ﺍﻣﺪﺍﺩ ﺍﻟﻄﺎﻗﺔ‬ ‫ﺑﻮﺣﺪﺍﺕ‬ ‫ﻋﺪﺓ ﺍﺗﺼﺎﻻﺕ‬ ‫ﺠﻬﺎﺯ‬ ‫ﺍﻟ‬ ‫ﻳﻜﻮﻥ ﻟﻬﺬﺍ‬ ‫ﻗﺪ‬ ‫ﺍﻟﻜﻬﺮﺑﺎء‬ ‫ﻋﻦ‬ ‫ﻮﺣﺪﺓ‬ ‫ﺍﻟ‬ ‫ﻟﻌﺰﻝ‬ ‫ﻛﺎﻓﺔ ﺍﻻﺗﺼﺎﻻﺕ‬ ‫ﻳﺠﺐ ﺇﺯﺍﻟﺔ‬ Waarschuwing Deze eenheid kan meer dan één stroomtoevoeraansluiting bevatten. Alle aansluitingen dienen verwijderd te worden om het apparaat stroomloos te maken. Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is...
Page 46: Comply With Local And National Electrical Codes
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Attention Lorsque le système est en fonctionnement, des tensions électriques circulent sur le fond de panier. Prendre des précautions lors de la maintenance. ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬...
Page 47: Product Disposal
Chapter 4: Warning Statements for AC Systems ¡Advertencia! La instalacion del equipo debe cumplir con las normas de electricidad locales y nacionales.Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬...
Page 48: Hot Swap Fan Warning
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Warnung Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen. ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement.
Page 49 Chapter 4: Warning Statements for AC Systems 当您从机架移除风扇装置，风扇可能仍在转动。小心不要将手指、螺丝起子和其他物品太靠近风扇警告當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.
Page 50: Power Cable And Ac Adapter
ﬁ re. Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certiﬁ ed cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only. 警告...
Page 51 Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certiﬁ és qui ont UL ou CSA indiqué sur le code pour tous les autres appareils électriques que les produits désignés par Supermicro seulement.
Page 52 Elektrisch apparaat en veiligheidsinformatiebladen wet verbiedt het gebruik van UL of CSA gecertiﬁ ceerde kabels die UL of CSA die op de code voor andere elektrische apparaten dan de producten die door Supermicro alleen.
Page 53: Chapter 5 Advanced Motherboard Setup
Chapter 5: Advanced Motherboard Setup Chapter 5 Advanced Motherboard Setup This chapter covers the steps required to install the X9DRT-HIBQF/HIBFF/HF motherboard into the chassis, connect the data and power cables and install add-on cards. All motherboard jumpers and connections are also described. A layout and quick reference chart are included in this chapter for your reference.
Page 54: Connecting Cables
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Connecting Cables Now that the processors are installed, the next step is to connect the cables to the serverboard. Connecting Data Cables The cables used to transfer data from the peripheral devices have been carefully routed in preconﬁ gured systems to prevent them from blocking the ﬂ ow of cooling air that moves through the system from front to back.
Page 55: Rear I/O Ports
Chapter 5: Advanced Motherboard Setup Rear I/O Ports The rear I/O ports are color coded in conformance with the PC 99 speciﬁ cation. See Figure 5-1 below for the colors and locations of the various I/O ports. Figure 5-1. Rear I/O Ports Back Panel I/O Port Locations and Deﬁ...
Page 56: Processor And Heatsink Installation
CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. Note: Refer to the Supermicro website for updates on CPU support. Installing the LGA2011 Processor 1. There are two load levers on the LGA2011 socket. To open the socket cover, ﬁ...
Page 57 Chapter 5: Advanced Motherboard Setup 2. Press the second load lever labeled 'Close 1st' to release the load plate that covers the CPU socket from its locking position. Press down on Load the Lever Pull lever away labeled 'Close 1st' from the socket 3.
Page 58 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL 5. Use your thumb and index ﬁ nger to hold the CPU on its edges. Align the CPU keys, which are semi-circle cutouts, against the socket keys. Socket Keys CPU Keys 6. Once they are aligned, carefully lower the CPU straight down into the socket.
Page 59 Chapter 5: Advanced Motherboard Setup 7. With the CPU inside the socket, inspect the four corners of the CPU to make sure that the CPU is properly installed. 8. Close the load plate with the CPU inside the socket. Lock the lever labeled 'Close 1st' ﬁ...
Page 60: Installing A Passive Cpu Heatsink
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Installing a Passive CPU Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die -- the required amount has already been applied. 2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the Motherboard's and the Heatsink Bracket underneath.
Page 61: Removing The Heatsink
Chapter 5: Advanced Motherboard Setup Removing the Heatsink Caution: We DO NOT recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow the instructions below to uninstall the heatsink to prevent damage done to the CPU or the CPU socket. 1.
Page 62: Installing Memory
SDRAM. Populating two slots at a time with memory modules of the same size and type will result in interleaved (128-bit) memory, which is faster than non-interleaved (64-bit) memory.” Note: Check the Supermicro website (www.supermicro.com) for the latest memory support information. Maximum Memory The X9DRT-HIBQF/HIBFF/HF serverboard supports up to 256 GB of ECC RDIMM memory in eight (8) DIMM slots.
Page 63 Chapter 5: Advanced Motherboard Setup Figure 5-2. Installing DIMM into Slot To Install: Insert Notch Notch module vertically and press down until it snaps into place. Front View Pay attention to the alignment notch at the bottom. Note: Notch should align with To Remove: Use the receptive key point on the slot.
Page 64: Dimm Module Population Conﬁ Guration
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL DIMM Module Population Conﬁ guration For memory to work properly, follow the tables below for memory installation: UDIMM Support on the E5-2600 Series Processor Platform DIMMs Populated UDIMM Type POR Speeds Ranks per DIMM per DDR Channel (Unb.
Page 65: Adding Pci Expansion Cards
Chapter 5: Advanced Motherboard Setup Adding PCI Expansion Cards The 6027TR-H70QRF/H70FRF/H70RF includes one preinstalled riser cards designed speciﬁ cally for use in the SC827HQ-R1620B 2U rackmount chassis. These riser cards support one low-proﬁ le PCI Express x16 cards to ﬁ t inside the chassis for each node.
Page 66: Motherboard Details
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Motherboard Details Figure 5-3. X9DRT-HIBQF/HIBFF/HF Motherboard Layout (not drawn to scale) COM1 LEB2 JBR1 LEB1 LEM1 JRK1 RAID KEY JPME1 JPME2 JNMI1 JRST1 Controller InfiniBand Controller JPB1 JPL1 JSD1 JPG1 C602 Chipset BATTERY BIOS JBT1 CPU1...
Page 67 Notes: 1. For the latest CPU/Memory updates, please refer to our website at http:// www.supermicro.com/products/motherboard/ for details. 2. Use only the correct type of onboard CMOS battery as speciﬁ ed by the manufacturer. Do not install the onboard battery upside down to avoid possible explosion.
Page 68 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Connector Description COM1 Backplane COM Port1 Inﬁ niBand Connector (X9DRT-HIBQF and X9DRT-HIBFF only) I-SATA 0/1 Intel PCH SATA Connectors 0/1 JBAT1 Onboard Battery (See the warning on P. 1-6.) SMC Proprietary Slot for Power, FP Control & I-SATA Connections...
Page 69: Connector Deﬁ Nitions
Chapter 5: Advanced Motherboard Setup Connector Deﬁ nitions LAN1/2 (Ethernet Ports) LAN Ports (LAN1/2) Pin Deﬁ nition Two Gigabit Ethernet ports (designated Pin# Deﬁ nition Pin# Deﬁ nition LAN1 and LAN2) are located beside P2V5SB SGND the COM port. Additionally, there is a dedicated LAN for IPMI on top of the TD0+ Act LED...
Page 70 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Serial Ports Serial Port Pin Deﬁ nitions (COM1/COM2) The COM1 serial port is located Pin # Deﬁ nition Pin # Deﬁ nition beside the VGA port. Refer to the motherboard layout for the location of the COM2 header. See the table on the right for pin deﬁ...
Page 71 Chapter 5: Advanced Motherboard Setup Unit Identiﬁ er Switches UID Switch Two Unit Identiﬁ er (UID) Switches and Pin# Deﬁ nition two LED Indicators are located on the Ground motherboard. The Front Panel UID Ground Switch is located at Pin 16 on JF2. Button In The Rear UID Switch is located at SW1 Ground...
Page 72 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL System Reset System Reset (JRST1) Pin Deﬁ nition A System Reset header is located at Pin Setting Deﬁ nition JRST1 on the motherboard. Connect Pin 1 Signal a cable to this header for system reset. Refer to the layout below for...
Page 73: Jumper Settings
Chapter 5: Advanced Motherboard Setup Jumper Settings Connector Pins Explanation of Jumpers To modify the operation of the Jumper motherboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two Setting pins to change the function of the connector.
Page 74 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Watch Dog Enable/Disable Watch Dog (JWD1) Jumper Settings Watch Dog (JWD1) is a system monitor Jumper Setting Deﬁ nition that can reboot the system when a Pins 1-2 Reset (default) software application hangs. Close Pins 1-2 to reset the system if an application Pins 2-3 hangs.
Page 75: 5-10 Onboard Indicators
Chapter 5: Advanced Motherboard Setup I2C Bus to PCI-Exp. Slots I2C to PCI-E (JI2C1/JI2C2) Jumper Settings Jumpers JI C1 and JI C2 allow you Jumper Setting Deﬁ nition to connect the System Management Enabled Bus (I C) to PCI-Express slots. The default setting is Open to disable the Disabled (Default) connection.
Page 76 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL BMC Heartbeat LED BMC Heartbeat LED (LEM1) Status A BMC Heartbeat LED is located at Color/State Deﬁ nition LEM1 on the motherboard. When Green: Blinking BMC:Normal LEM1 is blinking, BMC functions normally. See the table at right for more information.
Page 77: 5-11 Pci-Express And Serial Ata Connections
Chapter 5: Advanced Motherboard Setup Onboard Power LED Onboard PWR LED Indicator (LE1) LED Settings An Onboard Power LED is located LED Color Status at LE1 on the motherboard. When System Off (PWR cable not this LED is on, the system is on. Be connected) sure to turn off the system and unplug Green...
Page 78: 5-12 Installing Software
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL 5-12 Installing Software The Supermicro ftp site contains drivers and utilities for your system at ftp://ftp. supermicro.com. Some of these must be installed, such as the chipset driver. After accessing the ftp site, go into the CDR_Images directory and locate the ISO ﬁ...
Page 79 Chapter 5: Advanced Motherboard Setup Note: Click the icons showing a hand writing on paper to view the readme ﬁ les for each item. Click the computer icons to the right of these items to install each item (from top to the bottom) one at a time. After installing each item, you must re-boot the system before moving on to the next item on the list.
Page 80: Superdoctor Iii
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Figure 5-6. Supero Doctor III Interface Display Screen (Remote Control) Note: The SuperDoctor III program and User’s Manual can be downloaded from the Supermicro web site at http://www.supermicro.com/products/accessories/software/ SuperDoctorIII.cfm. For Linux, we recommend that you use the SuperoDoctor II...
Page 81: 5-13 Serverboard Battery
Chapter 5: Advanced Motherboard Setup 5-13 Serverboard Battery Caution: There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarites (see Figure 5-7). This battery must be replaced only with the same or an equivalent type recommended by the manufacturer (CR2032).
Page 82 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Notes...
Page 83: Chapter 6 Advanced Chassis Setup
Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform maintenance on the SC827HQ-R1620B chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the step that follows.
Page 84: Control Panel
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Figure 6-1. Front and Rear Chassis Views Control Panel Control Panel Control Panel SAS/SATA Drives (12) Control Panel Ethernet Ports IPMI LAN Port COM1 Port VGA Port USB Ports Inﬁ niband Port (Only for 6027TR-H70QRF and...
Page 85: Chassis Cover
Chapter 6: Advanced Chassis Setup Chassis Cover Before operating the SC827 chassis for the ﬁ rst time, it is important to remove the protective ﬁ lm covering the top of the chassis, in order to allow for proper ventilation and cooling. Removing the Chassis Cover and Protective Film (Figure 6-2) 1.
Page 86: Air Shrouds
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Air Shrouds Air shrouds concentrate airﬂ ow to maximize fan efﬁ ciency. The SC827 chassis air shroud does not require screws to set up. The SC827 chassis requires four identical air shrouds, one in each motherboard drawer. Air shrouds vary depending upon the motherboard used.
Page 87: Checking The Airﬂ Ow
Chapter 6: Advanced Chassis Setup Checking the Airﬂ ow Checking Airﬂ ow 1. Make sure there are no objects to obstruct airﬂ ow in and out of the server. In addition, if you are using a front bezel, make sure the bezel's ﬁ lter is replaced periodically.
Page 88 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Changing a System Fan 1. If necessary, open the chassis while the power is running to determine which fan has failed. (Never run the server for an extended period of time with the chassis cover open.) 2.
Page 89 Chapter 6: Advanced Chassis Setup Figure 6-5. Replacing a System Fan in the Fan Housing...
Page 90: Removing And Installing The Backplane
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Removing and Installing the Backplane The SC827 chassis backplane is located behind the hard drives and in front of the front system fans. In order to change jumper settings on the backplane, it may be necessary to remove the backplane from the chassis.
Page 91 Chapter 6: Advanced Chassis Setup 7. Remove the side screw from the side of the chassis (Figure 6-7). Figure 6-7. Loosening the Spring Bar Screws in the Floor of the Chassis 8. Gently ease the backplane up and out of the chassis (Figure 6-8). Figure 6-8.
Page 92: Installing The Backplane
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Installing the Backplane Installing the Backplane into the Chassis (Figure 6-9) 1. Ensure that all of the hard drive trays have been removed from the bays in the front of the chassis and that the spring bar has been loosened as directed in the previous section.
Page 93: Installing The Motherboard
Chapter 6: Advanced Chassis Setup Installing the Motherboard I/O Shield The I/O shield (Figure 6-10) holds the motherboard ports in place. The I/O shield does not require installation. Figure 6-10. I/O Shield Placement I/O Shields Permanent and Optional Standoffs Standoffs prevent short circuits by securing space between the motherboard and the chassis surface.
Page 94 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL 4. Lay the ﬁ rst motherboard in the drawer aligning the standoffs with the motherboard. 5. Secure the motherboard to the drawer using the rounded, Phillips head screws included for this purpose. 6. Repeat steps 3 - 5 for the remaining drawers.
Page 95: Adapter Card Replacement
Chapter 6: Advanced Chassis Setup Adapter Card Replacement Each motherboard drawer comes equipped with an adapter card which plugs into the backplane. In the unlikely event that the adapter card needs to be replaced, installation requires only a Phillips head screwdriver. Figure 6-12.
Page 96: Add-On Card/Expansion Slot Setup
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Add-on Card/Expansion Slot Setup The SC827 chassis includes I/O slots for add-on cards and expansion cards. Each side supports one low proﬁ le/half length add-on card for a total of four per chassis, one per drawer.
Page 97: 6-10 Drive Bay Installation/Removal
SAS/SATA drives. Proceed to the next step for instructions. You must use standard 1" high, SAS/SATA drives in the system. Note: Refer to Supermicro's web site for setup guidelines: <http://www.supermicro. com/support/manuals/>. The SC827 chassis contains four individual motherboards in separate node drawers (Figure 6-14).
Page 98 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Removing Hard Drive Trays from the Chassis (Figure 6-15) 1. Press the release button on the drive tray. This extends the drive bay handle. 2. Use the handle to pull the drive out of the chassis.
Page 99 Chapter 6: Advanced Chassis Setup The drives are mounted in drive carriers to simplify their installation and removal from the chassis (Figure 6-16). These carriers also help promote proper airﬂ ow for the drive bays. Figure 6-16. Chassis Drive Tray Dummy Drive Drive Tray Installing a Drive into the Hard Drive Tray...
Page 100 Figure 6-18. Installing the Hard Drive SAS/SATA Hard Drive Drive Tray Warning: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro Web site at http://www.supermicro.com/products/nfo/ﬁ les/ storage/SAS-CompList.pdf...
Page 101: 6-11 Power Supply
Replacement units can be ordered directly from Supermicro (See the contact information in the Preface of this manual). Changing the Power Supply (Figure 6-19) 1.
Page 102 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Figure 6-19. Changing the Power Supply Release Tab 6-20...
Page 103: Chapter 7 Bios
When an option is selected in the left frame, it is highlighted in white. Often a text message will accompany it. (Note: the AMI BIOS has default text messages built in. Supermicro retains the option to include, omit, or change any of these text messages.) The AMI BIOS Setup Utility uses a key-based navigation system called "hot keys".
Page 104: Starting The Setup Utility
Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update. If you have to update the BIOS, do not shut down or reset the system while the BIOS is updating.
Page 105 Chapter 7: BIOS Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Enabled, the ROM BIOS of the host adaptors will "capture" Interrupt 19 at bootup and allow the drives that are attached to these host adaptors to function as bootable disks.
Page 106 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL CPU Conﬁ guration This submenu displays the information of the CPU as detected by the BIOS. It also allows the user to conﬁ guration CPU settings. Socket 1 CPU Information/Socket 2 CPU Information This submenu displays the following information regarding the CPU installed in Socket 1 and (or) Socket 2 as detected by the BIOS.
Page 107 Chapter 7: BIOS Active Processor Cores Set to Enabled to use a processor's second core and above. (Please refer to Intel's website for more information.) The options are All, 1, 2, 4, and 6. Limit CPUID Maximum Use this feature to set the maximum CPU ID value. Select Enabled to boot a legacy operating system that cannot support processors with extended CPUID functions.
Page 108 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Intel® Virtualization Technology (Available when supported by the CPU) Select Enabled to support Intel Virtualization Technology, which will allow one platform to run multiple operating systems and applications in independent partitions, creating multiple "virtual" systems in one physical computer. The options are Enabled and Disabled.
Page 109: North Bridge
Chapter 7: BIOS Chipset Conﬁ guration North Bridge This feature allows the user to conﬁ gure the following North Bridge settings. Integrated IO Conﬁ guration Intel VT-d Select Enabled to enable Intel Virtualization Technology support for Direct I/O VT-d by reporting the I/O device assignments to the VMM (Virtual Working Memory) through the DMAR ACPI Tables.
Page 110 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Port 1B Link Speed Select GEN1 to enable PCI-Exp Generation 1 support for Port 1B. Select GEN2 to enable PCI-Exp Generation 2 support for Port 1B. Select GEN3 to enable PCI- Exp Generation 3 support for Port 1B. The options are GEN1, GEN2, and GEN3.
Page 111 Chapter 7: BIOS IOU3-PCIe Port This feature allows the user to set the bus speed between the IOU3 and the PCI-Exp port. The options are x4x4x4x4, x4x4x8, x8x4x4, x8x8, and x16. Port 3A Link Speed Select GEN1 to enable PCI-Exp Generation 1 support for Port 3A. Select GEN2 to enable PCI-Exp Generation 2 support for Port 3A.
Page 112 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL DIMM Conﬁ guration This item displays the following information of a DIMM module speciﬁ ed by the user. CPU Socket 1 DIMM Information This item displays the memory type/speed of a memory module speciﬁ ed. •...
Page 113 Chapter 7: BIOS Rank Interleaving This feature allows the user to select a rank memory interleaving method. The options are Auto, 1 Way, 2 Way, 4, Way, and 8 Way. Patrol Scrub Patrol Scrubbing is a process that allows the CPU to correct correctable memory errors detected on a memory module and send the correction to the requestor (the original source).
Page 114 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL South Bridge Conﬁ guration This feature allows the user to conﬁ gure the settings for the Intel PCH chip. PCH Information This feature displays the following PCH information. Name: This item displays the name of the PCH chip.
Page 115 Chapter 7: BIOS SATA Conﬁ guration When this submenu is selected, the AMI BIOS automatically detects the presence of IDE or SATA devices and displays the following items. SATA Port0~SATA Port5: The AMI BIOS displays the status of each SATA port as detected by the BIOS.
Page 116 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Staggered Spin Up Select Enabled to enable Staggered Spin-up support to prevent excessive power consumption caused by multiple HDDs spinning-up simultaneously. The options are Enabled and Disabled. RAID Mode The following items are displayed when RAID Mode is selected: PCH RAID CodeBase Select Intel or LSI to specify the code base to be used for RAID support.
Page 117 Chapter 7: BIOS Above 4G Decoding (Available if the system supports 64-bit PCI decoding) Select Enabled to decode a PCI device that supports 64-bit in the space above 4G Address. The options are Enabled and Disabled. PERR# Generation Select Enabled to allow a PCI device to generate a PERR number for a PCI Bus Signal Error Event.
Page 118 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Load Onboard LAN1 Option ROM/Load Onboard LAN2 Option ROM Select Enabled to enable Onboard LAN1 Option ROM or Onboard LAN2 Option ROM to boot the system via a device installed on the onboard LAN port as speciﬁ...
Page 119: Serial Port Console Redirection
Chapter 7: BIOS Serial Port Console Redirection COM 1 This submenu allows the user to conﬁ gure the following Console Redirection settings for a COM Port speciﬁ ed by the user. Console Redirection Select Enabled to use a COM Port selected by the user for Console Redirection. The options are Enabled and Disabled.
Page 120 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Bits Per second Use this feature to set the transmission speed for a serial port used in Console Redirection. Make sure that the same speed is used in the host computer and the client computer. A lower transmission speed may be required for long and busy lines.
Page 121 Chapter 7: BIOS RTID This feature indicates the total number of RTIDs for local and remote boots. The options are Optimal and Alternate. High Precision Event Timer Select Enabled to activate the High Precision Event Timer (HPET) that produces periodic interrupts at a much higher frequency than a Real-time Clock (RTC) does in synchronizing multimedia streams, providing smooth playback, reducing the dependency on other timestamp calculation devices, such as an x86 RDTSC Instruction embedded in the CPU.
Page 122: Event Logs
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Blink LEDs (Range 0~15 seconds) This item displays the blinking range of the NIC LED indicators. Port Conﬁ guration Information This section displays the following LAN Port settings. • UEFI Drive • Adapter PBA • Chip Type •...
Page 123 Chapter 7: BIOS Erasing Settings Erase Event Log Select Enabled to erase the SMBIOS (System Management BIOS) Event Log, which is completed before a event logging is initialized upon system reboot. The options are No, Yes Next Reset, and Yes Every Reset. When Log is Full Select Erase Immediately to immediately erase SMBIOS error event logs that exceed the limit when the SMBIOS event log is full.
Page 124: Ipmi
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL IPMI Use this feature to conﬁ gure Intelligent Platform Management Interface (IPMI) settings. IPMI Firmware Revision This item indicates the IPMI ﬁ rmware revision used in your system. IPMI Status This item indicates the status of the IPMI ﬁ rmware installed in your system.
Page 125 Chapter 7: BIOS  BMC Network Conﬁ guration LAN Channel 1: This feature allows the user to conﬁ gure the settings for LAN1 Port. Update IPMI LAN Conﬁ guration This feature allows the user to decide if the BIOS should conﬁ gure the IPMI setting at next system boot.
Page 126: Boot
SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Boot This submenu allows the user to conﬁ gure the following boot settings for the system. CSM Support Select Enabled to enable UEFI Compatibility Support Module (CSM) to provide compatibility support to a traditional legacy BIOS which will allow an OS that requires CSM support to boot from a traditional option ROM.
Page 127: Security
Chapter 7: BIOS Security This menu allows the user to conﬁ gure the following security settings for the system. Administrator Password Use this feature to set the Administrator Password which is required to enter the BIOS setup utility. The length of the password should be from 3-character to 8-character long.
Page 128 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Discard Changes Select this feature and press <Enter> to discard all the changes and return to the BIOS setup. When the dialog box appears, asking you if you want to load previous values, click Yes to load the values previous saved, or click No to keep the changes you've made so far.
Page 129: Appendix A Bios Error Beep Codes
Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
Page 130 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Notes...
Page 131: Appendix B System Speciﬁ Cations
512 MB, 1 GB, 2 GB, 4 GB, 8 GB, 16 GB or 32 GB size sizes of 1.5V or 1.35V voltages. Note: refer to Section 5-6 for details on installation. Note: Check the Supermicro website (www.supermicro.com) for the latest memory support information. SAS/SATA Drive Bays...
Page 132 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL Chassis SC827HQ-R1620B (2U rackmount) Dimensions: (WxHxD) 17.25 x 3.47 x 28.5 in. (438 x 88 x 724 mm) Weight Gross (Bare Bone): 85 lbs. (38.6 kg.) System Cooling The system has four (4) 8-cm PWM system cooling fans...
Page 133 Appendix B: System Speciﬁ cations Notes...
Page 134 SUPERSERVER 6027TR-H70QRF/H70FRF/H70RF USER'S MANUAL (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in signiﬁ...
