  • Page 1 UPER ® SUPERSERVER 6027TR-DTRF 6027TR-DTFRF 6027TR-DTQRF User's Manual Revision 1.0...
  • Page 2 This product, including software and documentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.
  • Page 3 Preface Preface About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 6027TR-DTQRF/DTFRF/DTRF. Installation and maintainance should be performed by experienced technicians only. The SuperServer 6027TR-DTQRF/DTFRF/DTRF is a high-end server based on the SC827HD-R1K28B 2U rackmount chassis and the dual processor X9DRT-HIBQF/HIBFF/HF serverboard.
  • Page 4 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Chapter 4: System Safety You should thoroughly familiarize yourself with this chapter for a general overview of safety precautions that should be followed when installing and servicing the SuperServer 6027TR-DTQRF/DTFRF/DTRF. Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X9DRT-HIBQF/HIBFF/HF serverboard, including the locations and functions of connections, headers and jumpers.
  • Page 5 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Notes...

  • Page 6: Table Of Contents

    Mounting Rails ....................1-5 Advanced Power Management (for -F Models Only) ........1-5 Intel® Intelligent Power Node Manager (NM) ..........1-5 Manageability Engine (ME) ................1-5 Contacting Supermicro ..................1-7 2U Twin: System Notes ................... 1-8 Nodes ......................1-8 System Power ....................1-8 SATA Backplane/Drives ...................
  • Page 7 Table of Contents Rack Mounting Considerations ............... 2-3 Ambient Operating Temperature ..............2-3 Reduced Airfl ow ..................2-3 Mechanical Loading ................... 2-3 Circuit Overloading ..................2-3 Reliable Ground ..................2-3 Installing the System into a Rack ..............2-4 Separating the Sections of the Rack Rails ............. 2-4 Installing the Inner Rail Extension ..............
  • Page 8 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Connecting Data Cables ................. 5-2 Rear I/O Ports ....................5-3 Processor and Heatsink Installation..............5-4 Installing a Passive CPU Heatsink ..............5-8 Removing the Heatsink ................... 5-9 Installing Memory ..................5-10 Memory Support .................... 5-10 Maximum Memory ..................5-10 DIMM Module Population Confi...
  • Page 9 Table of Contents Permanent and Optional Standoffs ..............6-11 Node Installation/Removal ................6-13 6-10 Installing and Replacing the Adapter Card ........... 6-15 Expansion Card/Expansion Slot Setup ............6-16 Installing the Riser Card onto the Riser Card Bracket ......... 6-17 Installing Expander and Riser Cards onto the Motherboard ......6-18 6-11 Installing and Removing Hard Drives ............
  • Page 10 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Notes...

  • Page 11: Chapter 1 Introduction

    Twelve (12) hot-swap 3.5" HDD trays (MCP-220-00075-0B) Four (4) 21-cm SATA cables (CBL-0473L) • Two (2) Riser cards (RSC-R2UT-3E8R-O-P) • One (1) Rails set (MCP-290-00053-0N) Note: a complete list of safety warnings is provided on the Supermicro web site at http://www.supermicro.com/about/policies/safety_information.cfm...

  • Page 12: Serverboard Features

    512 MB, 1 GB, 2 GB, 4 GB, 8 GB, 16 GB or 32 GB sizes at 1.35V or 1.5V voltages. See Chapter 5 for details. Note: Check the Supermicro website (www.supermicro.com) for the latest memory support information. Serial ATA...

  • Page 13: Onboard Controllers/Ports

    (additional one internal USB headers are included on the serverboard), an IPMI dedicated LAN port and two Ethernet ports. Note: For IPMI Confi guration Instructions, please refer to the Embedded BMC Confi guration User's Guide available @ http://www.supermicro.com/support/ manuals/. Graphics Controller The X9DRT-HIBQF/HIBFF/HF features an integrated Matrox G200eW Video Controller.

  • Page 14: Server Chassis Features

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Server Chassis Features The following is a general outline of the main features of the SC827 server chassis. System Power Each SC827 chassis model includes a high-effi ciency 80-plus Platinum certifi ed power supply, rated at 1280 Watts plus one redundant backup power supply. In the unlikely event your power supply fails, replacement is simple and can be accomplished without tools.

  • Page 15: Cooling System

    Chapter 1: Introduction Cooling System The SC827 chassis accepts four system fans powered from either backpane or the serverboards. If not powered from the backpane, the SC827HD-R1K28B model chassis powers four fans from four motherboards, so that when one of the motherboard drawers is removed, the other motherboards will continue running all fans.
  • Page 16 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Figure 1-1. Intel C602 Chipset: System Block Diagram Note: This is a general block diagram and may not exactly repre- sent the features on your motherboard. See the previous pages for the actual specifi cations of your motherboard. This block diagram is intended for your reference only.

  • Page 17: Contacting Supermicro

    Chapter 1: Introduction Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 18: Twin: System Notes

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual 2U Twin: System Notes As a 2U Twin confi guration, the SuperServer 6027TR-DTQRF/DTFRF/DTRF is a unique server system. With two system boards incorporated into a single chassis acting as two separate nodes, there are several points you should keep in mind. Nodes Each of the two serverboards act as a separate node in the system.

  • Page 19: Chapter 2 Server Installation

    Chapter 2: Server Installation Chapter 2 Server Installation Overview This chapter provides a quick setup checklist to get your SuperServer 6027TR-DTQRF/DTFRF/DTRF up and running. Following these steps in the order given should enable you to have the system operational within a minimum amount of time.

  • Page 20: Choosing A Setup Location

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Choosing a Setup Location • Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches) and approximately 30 inches of clearance in the back of the rack to allow for suffi cient airfl ow and ease in servicing. •...

  • Page 21: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating temperature of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient temperature (Tmra).

  • Page 22: Installing The System Into A Rack

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Installing the System into a Rack This section provides information on installing the SC827 chassis into a rack unit with the quick-release rails provided. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly. You should also refer to the installation instructions that came with the rack unit you are using.

  • Page 23: Installing The Inner Rail Extension

    Chapter 2: Server Installation Figure 2-2: Installing the Inner Rail Extensions Installing the Inner Rail Extension The SC827 chassis includes a set of inner rails in two sections: inner rails and inner rail extensions. The inner rails are pre-attached to the chassis, and do not interfere with normal use of the chassis if you decide not to use a server rack.

  • Page 24: Outer Rack Rails

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Outer Rack Rails Outer rails attach to the rack and hold the chassis in place. The outer rails for the SC827 chassis extend between 30 inches and 33 inches. Installing the Outer Rails to the Rack 1.

  • Page 25: Checking The Serverboard Setup

    Chapter 2: Server Installation Checking the Serverboard Setup After you install the SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF in the rack, you will need to open the unit to make sure the serverboard is properly installed and all the connections have been made. Accessing the inside of the System Before operating the server for the fi...

  • Page 26: Checking The Drive Bay Setup

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Figure 2-5. Accessing the Inside of the System Remove two screws Check Ventilation Openings Checking the Drive Bay Setup Next, you should check to make sure the peripheral drives and the SATA drives have been properly installed and all connections have been made. Checking the Drives 1.

  • Page 27: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel and on the drive carriers to keep you constantly informed of the overall status of the system. SC827 models include two front panels on the handles of the chassis which control each of the systems. This chapter explains the meanings of all LED indicators and the appropriate response you may need to take.

  • Page 28: Control Panel Button

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Control Panel Button • Power: The main power button on each of the two control panels is used to apply or remove power from the power supply to each of the four systems in the chassis. Turning off system power with this button removes the main power, but keeps standby power supplied to the system.

  • Page 29: Drive Carrier Leds

    Chapter 3: System Interface Drive Carrier LEDs The server chassis uses SATA drives. SATA Drives Each SATA drive carrier has two LEDs. • Blue: Each Serial ATA drive carrier has a green LED. When illuminated, this green LED (on the front of the SATA drive carrier) indicates drive activity. A connection to the SATA backplane enables this LED to blink on and off when that particular drive is being accessed.
  • Page 30 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Notes...

  • Page 31: Chapter 4 Standardized Warning Statements For Ac Systems

    The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance. Only certifi ed technicians should attempt to install or confi gure components.
  • Page 32 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befi nden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 33 Warning Statements for AC Systems ‫ﺟﺴﺪﻳﺔ‬ ‫ﺍﺻﺎﺑﺔ‬ ‫ﺗﺘﺴﺒﺐ ﻓﻲ‬ ‫ﺣﺎﻟﺔ ﻳﻤﻜﻦ ﺃﻥ‬ ‫ﺍﻧﻚ ﻓﻲ‬ ‫ﺧﻄﺮ‬ ‫ﻳﻌﻨﻲ‬ ‫ﻫﺬﺍ ﺍﻟﺮﻣﺰ‬ !‫ﺗﺤﺬﻳﺮ‬ ‫ﺍﻟﺪﻭﺍﺋﺮ‬ ‫ﺑﺎﻟﻤﺨﺎﻁﺮ ﺍﻟﻨﺎﺟﻤﺔ ﻋﻦ‬ ‫ﻦ ﻋﻠﻰ ﻋﻠﻢ‬ ، ‫ﻛ‬ ‫ﻣﻌﺪﺍﺕ‬ ‫ﺗﻌﻤﻞ ﻋﻠﻰ ﺃﻱ‬ ‫ﻗﺒﻞ ﺃﻥ‬ ‫ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬ ‫ﺣﻮﺍﺩﺙ‬ ‫ﺃﻱ‬ ‫ﻭﻗﻮﻉ‬ ‫ﻤﻨﻊ‬ ‫ﻟ‬ ‫ﺍﻟﻮﻗﺎﺋﻴﺔ‬...

  • Page 34: Installation Instructions

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 35: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、...

  • Page 36: Power Disconnection Warning

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지 않도록 해야 합니다. Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A.
  • Page 37 Chapter 4: Warning Statements for AC Systems ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema. Attention Le système doit être débranché...

  • Page 38: Equipment Installation

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Equipment Installation Warning! Only trained and qualifi ed personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifi...

  • Page 39: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalifi ceerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 40: Battery Handling

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .('‫כלי אבטחה בלבד )מפתח, מנעול וכד‬ ‫ﻣﺤﻈﻮﺭﺓ‬ ‫ﻣﻨﺎﻁﻖ‬ ‫ﻟﺘﺮﻛﻴﺒﻬﺎ ﻓﻲ‬ ‫ﻫﺬﻩ ﺍﻟﻮﺣﺪﺓ‬ ‫ﺗﺨﺼﻴﺺ‬ ‫ﺗﻢ‬ ،‫ﺃﺩﺍﺓ ﺧﺎﺻﺔ‬ ‫ﻣﻦ ﺧﻼﻝ ﺍﺳﺘﺨﺪﺍﻡ‬ ‫ﻓﻘﻂ‬...
  • Page 41 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 42: Redundant Power Supplies

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 43: Backplane Voltage

    Chapter 4: Warning Statements for AC Systems ‫ﺍﻣﺪﺍﺩ ﺍﻟﻄﺎﻗﺔ‬ ‫ﺑﻮﺣﺪﺍﺕ‬ ‫ﻋﺪﺓ ﺍﺗﺼﺎﻻﺕ‬ ‫ﺠﻬﺎﺯ‬ ‫ﺍﻟ‬ ‫ﻳﻜﻮﻥ ﻟﻬﺬﺍ‬ ‫ﻗﺪ‬ ‫ﺍﻟﻜﻬﺮﺑﺎء‬ ‫ﻋﻦ‬ ‫ﻮﺣﺪﺓ‬ ‫ﺍﻟ‬ ‫ﻟﻌﺰﻝ‬ ‫ﻛﺎﻓﺔ ﺍﻻﺗﺼﺎﻻﺕ‬ ‫ﻳﺠﺐ ﺇﺯﺍﻟﺔ‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 44: Comply With Local And National Electrical Codes

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬ ‫ﺍﻟﻠﻮﺣﺔ‬ ‫ﺃﻭﺍﻟﻄﺎﻗﺔ ﺍﻟﻤﻮﺟﻮﺩﺓ ﻋﻠﻰ‬ ‫ﺍﻟﺘﻴﺎﺭ ﺍﻟﻜﻬﺮﺑﺎﺋﻲ‬ ‫ﻣﻦ‬ ‫ﺧﻄﺮ‬ ‫ﻫﻨﺎﻙ‬ ‫ﻫﺬﺍ ﺍﻟﺠﻬﺎﺯ‬ ‫ﺧﺪﻣﺔ‬ ‫ﻛﻦ ﺣﺬﺭﺍ ﻋﻨﺪ‬ ‫ﻳﻌﻤﻞ‬ ‫ﺍﻟﻨﻈﺎﻡ‬ ‫ﻋﻨﺪﻣﺎ ﻳﻜﻮﻥ‬ 경고! 시스템이...

  • Page 45: Product Disposal

    Chapter 4: Warning Statements for AC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬ ‫ﺍﻟﻤﺘﻌﻠﻘﺔ‬ ‫ﺍﻟﻤﺤﻠﻴﺔ ﻭﺍﻟﻮﻁﻨﻴﺔ‬ ‫ﻘﻮﺍﻧﻴﻦ‬ ‫ﻳﺠﺐ ﺃﻥ ﻳﻤﺘﺜﻞ ﻟﻠ‬ ‫ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬...

  • Page 46: Hot Swap Fan Warning

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent.
  • Page 47 Chapter 4: Warning Statements for AC Systems 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 48: Power Cable And Ac Adapter

    fi re. Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certifi ed cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only. 電源コードとACアダプター...
  • Page 49 Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifi és qui ont UL ou CSA indiqué sur le code pour tous les autres appareils électriques que les produits désignés par Supermicro seulement.
  • Page 50 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Notes 4-20...

  • Page 51: Chapter 5 Advanced Motherboard Setup

    Chapter 5: Advanced Motherboard Setup Chapter 5 Advanced Motherboard Setup This chapter covers the steps required to install the X9DRT-HIBQF/HIBFF/HF motherboard into the chassis, connect the data and power cables and install add-on cards. All motherboard jumpers and connections are also described. A layout and quick reference chart are included in this chapter for your reference.

  • Page 52: Connecting Cables

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Connecting Cables Now that the processors are installed, the next step is to connect the cables to the serverboard. These include the data cables for the hard disk drives and the power cables. Connecting Data Cables The cables used to transfer data from the peripheral devices have been carefully routed in preconfi...

  • Page 53: Rear I/O Ports

    Chapter 5: Advanced Motherboard Setup Rear I/O Ports The rear I/O ports are color coded in conformance with the PC 99 specifi cation. See Figure 5-1 below for the colors and locations of the various I/O ports. Figure 5-1. Rear I/O Ports Back Panel I/O Port Locations and Defi...

  • Page 54: Processor And Heatsink Installation

    CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. Refer to the Supermicro website for updates on CPU support. Installing the LGA2011 Processor 1. There are two load levers on the LGA2011 socket. To open the socket cover, fi...
  • Page 55 Chapter 5: Advanced Motherboard Setup 2. Press the second load lever labeled 'Close 1st' to release the load plate that covers the CPU socket from its locking position. Press down on Load the Pull lever away Lever labeled 'Close 1st' from the socket 3.
  • Page 56 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual 5. Use your thumb and index fi nger to hold the CPU on its edges. Align the CPU keys, which are semi-circle cutouts, against the socket keys. Socket Keys CPU Keys 6. Once they are aligned, carefully lower the CPU straight down into the socket. (Do not drop the CPU on the socket.
  • Page 57 Chapter 5: Advanced Motherboard Setup 7. With the CPU inside the socket, inspect the four corners of the CPU to make sure that the CPU is properly installed. 8. Close the load plate with the CPU inside the socket. Lock the lever labeled 'Close 1st' fi...

  • Page 58: Installing A Passive Cpu Heatsink

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Installing a Passive CPU Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die -- the required amount has already been applied. 2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the Motherboard's and the Heatsink Bracket underneath.

  • Page 59: Removing The Heatsink

    Chapter 5: Advanced Motherboard Setup Removing the Heatsink Caution: We DO NOT recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow the instructions below to uninstall the heatsink to prevent damage done to the CPU or the CPU socket. 1.

  • Page 60: Installing Memory

    SDRAM. Populating two slots at a time with memory modules of the same size and type will result in interleaved (128-bit) memory, which is faster than non-interleaved (64-bit) memory.” Note: Check the Supermicro website (www.supermicro.com) for the latest memory support information. Maximum Memory The X9DRT-HIBQF/HIBFF/HF serverboard supports up to 256 GB of ECC RDIMM memory in eight (8) DIMM slots.
  • Page 61 Chapter 5: Advanced Motherboard Setup Figure 5-2. Installing DIMM into Slot To Install: Insert Notch Notch module vertically and press down until it snaps into place. Front View Pay attention to the alignment notch at the bottom. Note: Notch should align with To Remove: Use the receptive key point on the slot.

  • Page 62: Dimm Module Population Confi Guration

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual DIMM Module Population Confi guration For memory to work properly, follow the tables below for memory installation: UDIMM Support on the E5-2600 Series Processor Platform DIMMs Populated UDIMM Type POR Speeds Ranks per DIMM per DDR Channel (Unb.

  • Page 63: Adding Pci Expansion Cards

    Chapter 5: Advanced Motherboard Setup Adding PCI Expansion Cards The 6027TR-DTQRF/DTFRF/DTRF includes two preinstalled riser cards designed specifi cally for use in the SC827HD-R1K28B 1U rackmount chassis. These riser cards support two full height and one low-profi le PCI Express x8 cards to fi t inside the chassis.

  • Page 64: Motherboard Details

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Motherboard Details Figure 5-3. X9DRT-HIBQF/HIBFF/HF Motherboard Layout (not drawn to scale) COM1 LEB2 JBR1 LEB1 LEM1 JRK1 RAID KEY JPME1 JPME2 JNMI1 JRST1 Controller InfiniBand Controller JPB1 JPL1 JSD1 JPG1 C602 Chipset BATTERY BIOS JBT1 CPU1 CPU2 5-14...
  • Page 65 1. For the latest CPU/Memory updates, please refer to our website at http:// www.supermicro.com/products/motherboard/ for details. 2. Use only the correct type of onboard CMOS battery as specifi ed by the manufacturer. Do not install the onboard battery upside down to avoid possible explosion.
  • Page 66 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Connector Description COM1 Backplane COM Port1 Infi niBand Connector (X9DRT-HIBQF and X9DRT-HIBFF only) I-SATA 0/1 Intel PCH SATA Connectors 0/1 JBAT1 Onboard Battery (See the warning on P. 1-6.) SMC Proprietary Slot for Power, FP Control & I-SATA Connections JNMI1 NMI (Non-Maskable Interrupt) Header JIPMB1...

  • Page 67: Connector Defi Nitions

    Chapter 5: Advanced Motherboard Setup Connector Defi nitions Ethernet LAN Ports LAN Ports (LAN1/2) Pin Defi nition Two Gigabit Ethernet ports (LAN1/2) Pin# Defi nition Pin# Defi nition are located on the I/O backplane on P2V5SB SGND the motherboard. In addition, an IPMI TD0+ Act LED Dedicated LAN is located above USB...
  • Page 68 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Serial Ports Serial Port Pin Defi nitions (COM1/COM2) The COM1 serial port is located beside Pin # Defi nition Pin # Defi nition the VGA port. Refer to the motherboard layout for the location of the COM2 header.
  • Page 69 Chapter 5: Advanced Motherboard Setup Unit Identifi er Switches UID Switch Two Unit Identifi er (UID) Switches and Pin# Defi nition two LED Indicators are located on the Ground motherboard. The Front Panel UID Ground Switch is located at Pin 16 on JF2. The Button In Rear UID Switch is located at SW1 next Ground...
  • Page 70 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual System Reset System Reset (JRST1) Pin Defi nition A System Reset header is located at Pin Setting Defi nition JRST1 on the motherboard. Connect a Pin 1 Signal cable to this header for system reset. Pin 2 Ground DOM Power Connector DOM PWR (JSD1)

  • Page 71: Jumper Settings

    Chapter 5: Advanced Motherboard Setup Jumper Settings Connector Pins Explanation of Jumpers To modify the operation of the motherboard, Jumper jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function Setting of the connector.
  • Page 72 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Watch Dog Enable/Disable Watch Dog (JWD1) Jumper Settings Watch Dog (JWD1) is a system monitor Jumper Setting Defi nition that can reboot the system when a Pins 1-2 Reset (default) software application hangs. Close Pins Pins 2-3 1-2 to reset the system if an application Open Disabled...

  • Page 73: 5-10 Onboard Indicators

    Chapter 5: Advanced Motherboard Setup I2C Bus to PCI-Exp. Slots I2C to PCI-E (JI2C1/JI2C2) Jumper Settings Jumpers JI C1 and JI C2 allow you to Jumper Setting Defi nition connect the System Management Bus Enabled C) to PCI-Express slots. The default Disabled (Default) setting is Open to disable the connection.
  • Page 74 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual BMC Heartbeat LED BMC Heartbeat LED (LEM1) Status A BMC Heartbeat LED is located at Color/State Defi nition LEM1 on the motherboard. When LEM1 Green: Blinking BMC:Normal is blinking, BMC functions normally. See the table at right for more information. Infi...

  • Page 75: 5-11 Pci-Express And Serial Ata Connections

    Chapter 5: Advanced Motherboard Setup 5-11 PCI-Express and Serial ATA Connections PCI-Express 3.0 x16 Slot A PCI-Express 3.0 x16 slot (Slot 1) is located on the motherboard. PCI-Express 3.0 x8 Slots Two PCI-Express 3.0 x8 slots (Slots SXB1/ SXB2) are on the motherboard. Slot SXB1 is used for a rear IO riser card;...

  • Page 76: 5-12 Installing Drivers

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual 5-12 Installing Drivers The CD that came bundled with the system contains drivers, some of which must be installed, such as the chipset driver. After inserting this CD into your CD-ROM drive, the display shown in Figure 5-4 should appear. (If this display does not appear, click on the My Computer icon and then on the icon representing your CD-ROM drive.

  • Page 77: Supero Doctor Iii

    Chapter 5: Advanced Motherboard Setup Supero Doctor III The SuperDoctor® III program is a Web base management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called SD III Client. The SuperDoctor III program included on the CD-ROM that came with your motherboard allows you to monitor the environment and operations of your system.
  • Page 78 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Figure 5-6. Supero Doctor III Interface Display Screen (Remote Control) Note: The SuperDoctor III program and User’s Manual can be downloaded from the Supermicro web site at http://www.supermicro.com/products/accessories/software/ SuperDoctorIII.cfm.For Linux, we recommend that you use the SuperoDoctor II application instead.

  • Page 79: 5-13 Serverboard Battery

    Chapter 5: Advanced Motherboard Setup 5-13 Serverboard Battery Caution: There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarites (see Figure 5-x). This battery must be replaced only with the same or an equivalent type recommended by the manufacturer (CR2032).
  • Page 80 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Notes 5-30...

  • Page 81: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform maintenance on the SC827HD-R1K28B chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the step that follows.

  • Page 82: Control Panel

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Figure 6-1. Chassis Front View Node A Control Panel Node B Control Panel Hard Drives Figure 6-2. Chassis Rear View Dedicated IPMI LAN Power PCI-Express x8 Port Supply Cards LAN Ports COM Port VGA Port USB Ports Infi...

  • Page 83: Chassis Cover

    Chapter 6: Advanced Chassis Setup Chassis Cover Before operating the SC827 chassis for the fi rst time, it is important to remove the protective fi lm covering the top of the chassis, in order to allow for proper ventilation and cooling. Removing the Chassis Cover and Protective Film 1.

  • Page 84: Installing The Air Shrouds

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Installing the Air Shrouds Air Shrouds Air shrouds concentrate airfl ow to maximize fan effi ciency. The SC827HD chassis requires air shrouds for each motherboard node. Air shrouds vary depending upon the motherboard used. See the illustrations below. Installing an Air Shroud 1.

  • Page 85: Checking The Airfl Ow

    Chapter 6: Advanced Chassis Setup Checking the Airfl ow Checking Airfl ow 1. Make sure there are no objects to obstruct airfl ow in and out of the server. In addition, if you are using a front bezel, make sure the bezel's fi lter is replaced periodically.
  • Page 86 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Changing a System Fan 1. If necessary, open the chassis while the power is running to determine which fan has failed. (Never run the server for an extended period of time with the chassis cover open.) 2.
  • Page 87 Chapter 6: Advanced Chassis Setup Figure 6-5. Replacing a System Fan in the Fan Housing...

  • Page 88: Removing And Installing The Backplane

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Removing and Installing the Backplane The SC827HD chassis backplane is located behind the hard drives and in front of the front system fans. If it is necessary to remove the backplane, follow the instructions below. Removing the Backplane Removing the Backplane from the Chassis 1.
  • Page 89 Chapter 6: Advanced Chassis Setup 7. Loosen the three screws in the spring bar, located on the fl oor of the chassis, indicated by the arrows below (Figure 6-7). Figure 6-7: Loosening the Spring Bar Screws in the Floor of the Chassis 8.

  • Page 90: Installing The Backplane

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Installing the Backplane Installing the Backplane into the Chassis (Figure 6-9) 1. Ensure that all of the hard drive trays have been removed from the bays in the front of the chassis and that the spring bar has been loosened as directed in the previous section.

  • Page 91: Installing The Motherboard

    Figure 6-10. I/O Shield Placement I/O Shields Compatible Motherboards Most Supermicro Twin series motherboards are compatible with the SC827HD chassis. For the most up-to-date information on compatible motherboards and other parts, visit the Supermicro Web site at www.supermicro.com. Hot-swappable motherboards feature different adapter cards, depending upon the motherboard.
  • Page 92 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Installing the Motherboard (Figure 6-11) 1. Review the documentation that came with your motherboard. Become familiar with component placement, requirements, precautions, and cable connections. 2. Pull the motherboard node drawer out of the back of the chassis. 3.

  • Page 93: Node Installation/Removal

    Chapter 6: Advanced Chassis Setup Node Installation/Removal As with any server system, power must be removed from the serverboard when upgrading or installing memory or processors. In the 2U Twin server, the serverboards (nodes) are capable of being hot-swapped from the chassis, allowing one to be powered down for servicing while the other continues operating.
  • Page 94 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Figure 6-12. Removing a System Node 6-14...

  • Page 95: 6-10 Installing And Replacing The Adapter Card

    Chapter 6: Advanced Chassis Setup 6-10 Installing and Replacing the Adapter Card Adapter cards (Figure 6-13) provide hot-swappable functionality to the chassis. Removing the Adapter Card 1. Remove the motherboard drawer from the chassis. 2. Disconnect the wiring, connecting the adapter card to the motherboard if any is present.

  • Page 96: Expansion Card/Expansion Slot Setup

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Note: The above illustration above represents a typical motherboard in the node drawer and its attached components. It is not meant to represent the specifi c motherboard found in your server. Expansion Card/Expansion Slot Setup The SC827HD chassis supports two full height and one low-profi le PCI slots for each node, for a total of six slots in the chassis (Figure 6-14).

  • Page 97: Installing The Riser Card Onto The Riser Card Bracket

    Chapter 6: Advanced Chassis Setup Installing the Riser Card onto the Riser Card Bracket Installing the Riser Card onto the Riser Card Bracket (Figure 6-15) 1. Disconnect the power supply and lay the chassis on a fl at surface. 2. Pull the motherboard node drawer from the chassis. 3.

  • Page 98: Installing Expander And Riser Cards Onto The Motherboard

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Installing Expander and Riser Cards onto the Motherboard Installing Expander and Riser Cards (Figure 6-16) 1. Disconnect the chassis from any power source. 2. Attach the riser card to the riser card bracket as described in the previous section.

  • Page 99: 6-11 Installing And Removing Hard Drives

    Chapter 6: Advanced Chassis Setup 6-11 Installing and Removing Hard Drives The SC827HD chassis contains two individual motherboards in separate node drawers. Each motherboard node controls a set of six hard drives. Note that if a motherboard node drawer is pulled out of the chassis, the hard drives associated with that node will power down as well.
  • Page 100 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Removing Hard Drive Carriers From the Chassis (Figure 6-18) 1. Press the release button on the drive carrier. This extends the drive bay handle. 2. Use the handle to pull the drive out of the chassis. Figure 6-18: Removing a Hard Drive Carrier 6-20...
  • Page 101 These carriers also help promote proper airfl ow for the drive bays. Caution! Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro Web site at http://www.supermicro.com/products/nfo/files/ storage/SAS-CompList.pdf...

  • Page 102: 6-12 Power Supply

    Replacement units can be ordered directly from Supermicro (See the contact information in the Preface of this manual). Power Supply Replacement Changing the Power Supply (Figure 6-20) 1.
  • Page 103 Chapter 6: Advanced Chassis Setup Figure 6-20: Changing the Power Supply Release Tab 6-23...
  • Page 104 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Notes 6-24...

  • Page 105: Chapter 7 Bios

    When an option is selected in the left frame, it is highlighted in white. Often a text message will accompany it. (Note: the AMI BIOS has default text messages built in. Supermicro retains the option to include, omit, or change any of these text messages.) The AMI BIOS Setup Utility uses a key-based navigation system called "hot keys".

  • Page 106: Starting The Setup Utility

    Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update. If you have to update the BIOS, do not shut down or reset the system while the BIOS is updating.
  • Page 107 Chapter 7: BIOS Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Enabled, the ROM BIOS of the host adaptors will "capture" Interrupt 19 at bootup and allow the drives that are attached to these host adaptors to function as bootable disks.
  • Page 108 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual CPU Confi guration This submenu displays the information of the CPU as detected by the BIOS. It also allows the user to confi guration CPU settings. Socket 1 CPU Information/Socket 2 CPU Information This submenu displays the following information regarding the CPU installed in Socket 1 and (or) Socket 2 as detected by the BIOS.
  • Page 109 Chapter 7: BIOS Active Processor Cores Set to Enabled to use a processor's second core and above. (Please refer to Intel's website for more information.) The options are All, 1, 2, 4, and 6. Limit CPUID Maximum Use this feature to set the maximum CPU ID value. Select Enabled to boot a legacy operating system that cannot support processors with extended CPUID functions.
  • Page 110 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Intel® Virtualization Technology (Available when supported by the CPU) Select Enabled to support Intel Virtualization Technology, which will allow one platform to run multiple operating systems and applications in independent partitions, creating multiple "virtual" systems in one physical computer. The options are Enabled and Disabled.
  • Page 111 Chapter 7: BIOS Chipset Confi guration North Bridge This feature allows the user to confi gure the following North Bridge settings. Integrated IO Confi guration Intel VT-d Select Enabled to enable Intel Virtualization Technology support for Direct I/O VT-d by reporting the I/O device assignments to the VMM (Virtual Working Memory) through the DMAR ACPI Tables.
  • Page 112 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Port 1B Link Speed Select GEN1 to enable PCI-Exp Generation 1 support for Port 1B. Select GEN2 to enable PCI-Exp Generation 2 support for Port 1B. Select GEN3 to enable PCI- Exp Generation 3 support for Port 1B. The options are GEN1, GEN2, and GEN3. IOU2-PCIe Port If this feature allows the user to set the bus speed between the IOU2 and the PCI-Exp port.
  • Page 113 Chapter 7: BIOS IOU3-PCIe Port If this feature allows the user to set the bus speed between the IOU3 and the PCI-Exp port. The options are x4x4x4x4, x4x4x8, x8x4x4, x8x8, and x16. Port 3A Link Speed Select GEN1 to enable PCI-Exp Generation 1 support for Port 3A. Select GEN2 to enable PCI-Exp Generation 2 support for Port 3A.
  • Page 114 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual DIMM Confi guration This item displays the following information of a DIMM module specifi ed by the user. CPU Socket 1 DIMM Information This item displays the memory type/speed of a memory module specifi ed. • P1-DIMMA1 •...
  • Page 115 Chapter 7: BIOS Rank Interleaving This feature allows the user to select a rank memory interleaving method. The options are Auto, 1 Way, 2 Way, 4, Way, and 8 Way. Patrol Scrub Patrol Scrubbing is a process that allows the CPU to correct correctable memory errors detected on a memory module and send the correction to the requestor (the original source).
  • Page 116 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual South Bridge Confi guration This feature allows the user to confi gure the settings for the Intel PCH chip. PCH Information This feature displays the following PCH information. Name: This item displays the name of the PCH chip. Stepping: This item displays the status of the PCH stepping.
  • Page 117 Chapter 7: BIOS SATA Confi guration When this submenu is selected, the AMI BIOS automatically detects the presence of IDE or SATA devices and displays the following items. SATA Port0~SATA Port5: The AMI BIOS displays the status of each SATA port as detected by the BIOS.
  • Page 118 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Port 0~5 Hot Plug Select Enabled to enable hot-plug support for a particular port, which will allow the user to change a hardware component or device without shutting down the system. The options are Enabled and Disabled. Staggered Spin Up Select Enabled to enable Staggered Spin-up support to prevent excessive power consumption caused by multiple HDDs spinning-up simultaneously.
  • Page 119 Chapter 7: BIOS PCIe/PCI/PnP Confi guration PCI ROM Priority Use this feature to select the Option ROM to boot the system when there are multiple Option ROMs available in the system. The options are EFI Compatible ROM and Legacy ROM. PCI Latency Timer Use this feature to set the latency Timer of each PCI device installed on a PCI bus.
  • Page 120 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Caution: Enabling ASPM support may cause some PCI-E devices to fail! SXB1 PCI-E 3.0 x16 Option ROM Select Enabled to enable CPU1 SXB1 PCI-E 3.0 x16 Option ROM to boot the system via a device installed on this slot. The options are Disabled and Enabled. SXB3 PCI-E 3.0 x16 Option ROM Select Enabled to enable CPU2 SXB3 PCI-E 3.0 x16 Option ROM to boot the system via a device installed on this slot.
  • Page 121 Chapter 7: BIOS Super IO Confi guration Super IO Chip: This item displays the name of the super IO chip used in the system. COM1 Confi guration Serial Port Select Enabled to enable a serial port specifi ed. The options are Enabled and Disabled.
  • Page 122 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Console Redirection Settings This feature allows the user to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user. Serial Port for Out-of-Band Management/Windows Emergency Management Services (EMS) The submenu allows the user to confi...
  • Page 123 Chapter 7: BIOS Parity A parity bit can be sent along with regular data bits to detect data transmission errors. Select Even if the parity bit is set to 0, and the number of 1's in data bits is even. Select Odd if the parity bit is set to 0, and the number of 1's in data bits is odd.
  • Page 124 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual High Precision Event Timer Select Enabled to activate the High Precision Event Timer (HPET) that produces periodic interrupts at a much higher frequency than a Real-time Clock (RTC) does in synchronizing multimedia streams, providing smooth playback, reducing the dependency on other timestamp calculation devices, such as an x86 RDTSC Instruction embedded in the CPU.

  • Page 125: Event Logs

    Chapter 7: BIOS Port Confi guration Information This section displays the following LAN Port settings. • UEFI Drive • Adapter PBA • Chip Type • PCI Device ID • PCI Bus: Device: Function • Link Status • Factory MAC Address •...
  • Page 126 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Erasing Settings Erase Event Log Select Enabled to erase the SMBIOS (System Management BIOS) Event Log, which is completed before a event logging is initialized upon system reboot. The options are No, Yes Next Reset, and Yes Every Reset. When Log is Full Select Erase Immediately to immediately erase SMBIOS error event logs that exceed the limit when the SMBIOS event log is full.

  • Page 127: Ipmi

    Chapter 7: BIOS IPMI Use this feature to confi gure Intelligent Platform Management Interface (IPMI) settings. IPMI Firmware Revision This item indicates the IPMI fi rmware revision used in your system. IPMI Status This item indicates the status of the IPMI fi rmware installed in your system. System Event Log Enabling/Disabling Options SEL Components...
  • Page 128 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual BMC Network Confi guration LAN Channel 1: This feature allows the user to confi gure the settings for LAN1 Port. Update IPMI LAN Confi guration This feature allows the user to decide if the BIOS should confi gure the IPMI setting at next system boot.

  • Page 129: Boot

    Chapter 7: BIOS Boot This submenu allows the user to confi gure the following boot settings for the system. CSM Support Select Enabled to enable UEFI Compatibility Support Module (CSM) to provide compatibility support to a traditional legacy BIOS which will allow an OS that requires CSM support to boot from a traditional option ROM.

  • Page 130: Security

    SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Security This menu allows the user to confi gure the following security settings for the system. Administrator Password Use this feature to set the Administrator Password which is required to enter the BIOS setup utility. The length of the password should be from 3-character to 8-character long.
  • Page 131 Chapter 7: BIOS Discard Changes Select this feature and press <Enter> to discard all the changes and return to the BIOS setup. When the dialog box appears, asking you if you want to load previous values, click Yes to load the values previous saved, or click No to keep the changes you've made so far.
  • Page 132 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Notes 7-28...

  • Page 133: Appendix A Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 134 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Notes...

  • Page 135: Appendix B System Specifi Cations

    512 MB, 1 GB, 2 GB, 4 GB, 8 GB, 16 GB or 32 GB size sizes of 1.5V or 1.35V voltages. Note: refer to Section 5-6 for details on installation. Note: Check the Supermicro website (www.supermicro.com) for the latest memory support information. SATA Drive Bays...
  • Page 136 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual Chassis SC827HD-R1K28B (2U rackmount) Dimensions: (WxHxD) 17.25 x 3.47 x 28.5 in. (438 x 88 x 724 mm) Weight Gross (Bare Bone): 85 lbs. (38.6 kg.) System Cooling The SuperServer 6027TR-DTQRF/DTFRF/DTRF has four (4) 8-cm PWM system cooling fans System Input Requirements AC Input Voltage: 85-264V AC auto-range...
  • Page 137 Appendix B: System Specifi cations Notes...
  • Page 138 SUPERSERVER 6027TR-DTQRF/DTFRF/DTRF User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in signifi...

This manual is also suitable for:

Supero superserver 6027tr-dtfrfSupero superserver 6027tr-dtqrf

Table of Contents
