Parts List - Linear Technology DC2641A Demo Manual

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 CIN1
2 5 CIN3, CIN4, CIN8, C14,
C15
3 3 CIN2, CIN6, CIN7
4 1 COUT1
5 2 COUT2, COUT3
6 3 C2, C4, C13
7 1 C3
8 1 C6
9 1 C7
10 1 C9
11 1 C10
12 1 C11
13 1 C12
14 1 L1
15 1 L2
16 2 Q2, Q3
17 1 Q4
18 1 RS1
19 1 R6
20 1 R9
21 1 R12
22 2 R13, R14
23 1 R15
24 3 R16, R17, R23
25 1 R18
26 1 R25
27 1 R26
28 2 R30, R36
29 1 R31
30 1 R32
31 1 R34
32 1 U1
33 1 U2
PART DESCRIPTION
CAP ., 100µF, ELECT, 200V, 20%, 16×20mm, THT, NRB-XS Series
CAP ., 2.2µF, X7R, 100V, 10%, 1812
CAP , 1µF, X7R, 10V, 10%, 0805
CAP , 22µF, X7R, 16V, 10%, 1210
CAP ., 150µF, TANT, 16V, 20%, 7343, D-CASE
CAP , 0.1µF, X7R, 25V, 10%, 0603
CAP , 1000pF, X7R, 50V, 10%, 0603
CAP , 4700pF, X7R, 50V, 10%, 0603
CAP , 1µF, X7R, 16V, 20%, 0603
CAP , 10pF, X7R, 50V, 10%, 0603
CAP ., 100pF, C0G, 50V, 5%, 0603
CAP , 0.1µF, X7R, 100V, 10%, 1206
CAP , 4.7µF, X5R, 16V, 20%, 0603
IND., 33µH, PWR, 15%, 12A, 11.4mΩ, 2013
IND., 470µH, PWR, 10%, 0.72A, 886mΩ, 10.0×10.2×4.8mm,
MSS1048T Series, AEC-Q200
XSTR., PWR MOSFET, N-CH, 120V, 44A, PG-TDSON-8, SuperSO8
XSTR., PWR MOSFET, N-CH, 120V, 98A, PG-TDSON-8, SuperSO8
RES, 0.006Ω, 1%, 2W, 2512, HIGH PWR, SENSE, AEC-Q200
RES., 301kΩ, 1%, 1/10W, 0603
RES., 10MΩ, 5%, 1/8W, 0805, AEC-Q200
RES., 2.2Ω, 5%, 1/8W, 0805, AEC-Q200
RES., 10kΩ, 5%, 1/10W, 0603, AEC-Q200
RES., 140kΩ, 1%, 1/10W, 0603, AEC-Q200
RES., 100kΩ, 1%, 1/10W, 0603
RES., 49.9kΩ, 1%, 1/10W, 0603
RES., 30.1kΩ, 1%, 1/10W, 0603, AEC-Q200
RES., 80.6kΩ, 1%, 1/10W, 0603
RES., 10Ω, 1%, 1/10W, 0603
RES., 2MΩ, 1%, 1/10W, 0603, AEC-Q200
RES., 267kΩ, 1%, 1/10W, 0603
RES., 196kΩ, 1%, 1/10W 0603
IC, HIGH VOLTAGE DC/DC BUCK REG., QFN-24 (4mm×5mm)
IC, SYNCHRONOUS STEP DOWN REGULATOR, 150V, 100mA,
MSOP-16
DEMO MANUAL DC2641A
MANUFACTURER/PART NUMBER
NIC NRB-XS101M200V16x20TBF
TDK, C4532X7R2A225K230KA
AVX 0805ZC105KAT2A
TDK, C3225X7R1C226K250AC
AVX TPSD157M016R0125
AVX, 06033C104KAT2A
AVX 06035C102KAT2A
AVX 06035C472KAT2A
TDK, C1608X7R1C105M080AC
AVX 06035C100KAT2A
AVX 06035A101JAT2A
AVX 12061C104KAT2A
TDK C1608X5R1C475M080AC
WURTH ELEKTRONIK 7443633300
COILCRAFT MSS1048T-474KLB
INFINEON BSC190N12NS3 G
INFINEON BSC077N12NS3 G
VISHAY WSL25126L000FEA18
VISHAY CRCW0603301KFKEA
VISHAY CRCW080510M0JNEA
VISHAY CRCW08052R20JNEA
VISHAY CRCW060310K0JNEA
VISHAY CRCW0603140KFKEA
VISHAY CRCW0603100KFKEA
VISHAY CRCW060349K9FKEA
VISHAY CRCW060330K1FKEA
VISHAY CRCW060380K6FKEA
VISHAY CRCW060310R0FKEA
VISHAY CRCW06032M00FKEA
VISHAY CRCW0603267KFKEA
VISHAY CRCW0603196KFKEA
LINEAR TECH. LTC7801UFD#PBF
LINEAR TECH LTC3639EMSE#PBF
