DEMO MANUAL DC2641A
PARTS LIST
ITEM QTY REFERENCE
Additional Demo Board Circuit Components
1 0 CIN5 (OPT)
2 0 COUT4 (OPT)
3 0 C1, C5, C8, C16 (OPT)
4 0 D1 (OPT)
5 0 D2 (OPT)
6 0 L4 (OPT)
7 0 Q1, Q6, Q7 (OPT)
8 0 Q5 (OPT)
9 0 Q12, Q13 (OPT)
10 0 R1 (OPT)
11 8 R2, R8, R22, R24, R27,
R28, R29, R35
12 0 R7, R11, R19, R20,
R21, R37, R38, R39,
R40(OPT)
13 0 R33 (OPT)
Additional
1 10 E1-E10
2 3 JP1, JP2, JP5
3 3 JP3, JP6, JP7
4 1 JP4
5 4 J1, J2, J3, J4
6 7 XJP1, XJP2, XJP3,
XJP4, XJP5, XJP6,
XJP7
7 4 MH1, MH2, MH3, MH4
8
PART DESCRIPTION
CAP , OPT 1812
CAP , OPTION 7343
CAP , OPTION 0603
DIODE, OPTION SOD-123
DIODE, OPTION SOD-323
IND., 22µH, PWR, 10%, 30A, 2.05mΩ, 27.9×19.8×15.36mm,
SER2915H Series, AEC-Q200
XSTR, OPTION TO252-3
XSTR, OPTION LFPAK
XSTR, OPT IN_PG_TS
RES, OPTION 0805
RES, 0Ω 1/10W 0603
RES, OPTION 0603
RES, OPTION 1206
TEST POINT, TURRET, 0.094", MTG. HOLE
CONN., HDR, MALE, 1×3, 2mm, THT, STR
CONN., HDR, MALE, 1×2, 2mm, THT, STR
CONN., HDR, MALE, 2×4, 2mm, THT, STR
CONN., BANANA JACK, FEMALE, THT, NON-INSULATED, SWAGE
CONN., SHUNT, FEMALE, 2 POS, 2mm
STANDOFF , NYLON, SNAP-ON, 0.50"
MANUFACTURER/PART NUMBER
OPTION
OPTION
OPTION
OPTION
OPTION
COILCRAFT SER2915H-223KL OPTION
OPTION
OPTION
OPTION
OPTION
VISHAY CRCW06030000Z0EA
OPTION
OPTION
MILL-MAX 2501-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 62000311121
WURTH ELEKTRONIK, 62000211121
WURTH ELEKTRONIK, 62000821121
KEYSTONE 575-4
WURTH ELEKTRONIK, 60800213421
WURTH ELEKTRONIK, 702935000
