Martin MAC Encore Performance Service Manual page 12

Service manual
MAC Encore Performance - Revision A, 12-20-2017
Performance
MDLP8-2 Circular
Blade 1a
Blade 1b
Blade 2a
Blade 2b
cƒ¶"¤fl?'fl¥?b
l¢·•"fl?o·–§ƒ¶¶"–fl¢›?'Nr
QOPU????????????TOWPUWR'
M1
M2
M3
M4
Figure 14: Connections
Label: MAC Opera Performance
Material: PE 100 White S-692
Size: 110 x 75 mm
Performance/Wash
Constant Current Driver
and Pixel board
D1 LED 3-4
S
D2 LED 1-2
S
D3 CAN bus in
CAN bus in
D4
D5 4xFan rear end right
D6 4xFan rear end left
D7
Fan
D8 Temperature pixel board
D9 LED 5-6
S
D10 100VDC
D11 24VDC
D12 Fan
Figure 15: Connections
A1 A2 A3 A4 A5 A6 A7
FRONT VIEW
BACK VIEW
A11
DISPLAY
B3 B4
B1 B2
BOTTOM VIEW
C2
C1
BOTTOM VIEW
33120127-B
MAC Quantum Base PCB connections label
Material: PE 100 White S-692
Size: 118 x 125 mm
Figure 16: Connections
Blade 3a
Blade 3b
Blade 4a
Blade 4b
CAN bus
24VDC
PWR
M8
M7
I/O
M6
M5
5085646_A
D1
D9
D2
D8
D7
D6
D5
D3
D4 D12
Safety loop
D8
4xLEDS
2xLEDS
MAINBOARD
A1 DMX
A2 Pan hall sensors
A3 Tilt dual hall sensor
A8 A9 A10
A4 CAN bus
A5 Temp. sensors
A6 Tilt ABS sensor
A7 Pan ABS sensor
A8 Pan motor
BATTERY
A9 Tilt motor
A10 24V Power
A11 Fans
PFC 900W
B6
B1 Line (brown)
B2 Neutral (blue)
B5
B3 Safety loop
B4 Temp. sensor
B5 400VDC
B6 DCDC enable
DCDC 900W
C4
C3
C1 400VDC
C2 DCDC enable
C5
C3 Not used
C4 100V Power
C5 Safety loop
C6 Temp. sensor
C7
24V Power
C6
C7
Label P/N 33120127-B
