SERVICE MANUAL
MAC Encore Performance
Revision A, 12-20-2017

Advertisement

Table of Contents
loading

Summary of Contents for Martin MAC Encore Performance

  • Page 1 SERVICE MANUAL MAC Encore Performance Revision A, 12-20-2017...
  • Page 2: Table Of Contents

    Replacing the multimodule ....................................26 Separating the multimodule ....................................27 Separating the CMYC module from the multimodule ............................27 Position of the color filters ....................................28 Replacing the animation wheel .................................... 29 Replacing the framing blade ....................................30 MAC Encore Performance - Revision A, 12-20-2017 2 of 46...
  • Page 3 Adressing driver PCBA CAN bus ID ..............................40 Maintenance ................................42 Cleaning the product ....................................42 Lubricating of the guide rails for the zoom/focus module and the CMY module ................43 Conditions ......................................43 Maintenance schedule ..................................44 MAC Encore Performance - Revision A, 12-20-2017 3 of 46...
  • Page 4: General Information

    Small flatheaded screwdriver. • Marker and tape. Important! Take the necessary precautions to prevent static electricity from damaging the product during modification or repair. Figure 3: ESD mat and wristband MAC Encore Performance - Revision A, 12-20-2017 4 of 46...
  • Page 5: Spare Parts

    Service manual Spare parts For an overview of the spare parts and spare part numbers of MAC Encore Performance, refer to martin.com Log in with your user login details. Search for “MAC Encore Performance CLD” or “MAC Encore Performance WRM”.
  • Page 6: Troubleshooting

    SLER • The safety loop is broken. • Safety loop error • Check if the connectors are properly connected. • PSU, DC-DC or LED driver board are too hot. MAC Encore Performance - Revision A, 12-20-2017 6 of 46...
  • Page 7: Wiring Diagrams

    Service manual Wiring diagrams Figure 5: Wiring diagram, MAC Encore Performance MAC Encore Performance - Revision A, 12-20-2017 7 of 46 7 of 46...
  • Page 8 Service manual Figure 6: Wiring diagram, MAC Encore Performance MAC Encore Performance - Revision A, 12-20-2017 8 of 46 8 of 46...
  • Page 9 Service manual Figure 7: Wiring diagram, MAC Encore Performance MAC Encore Performance - Revision A, 12-20-2017 9 of 46 9 of 46...
  • Page 10: Repair And Maintenance

    Torx10 screws (4) on each side of the base and pull up the cover. Follow the procedure in reverse order. Figure 10: Removing the voltage insulation cover MAC Encore Performance - Revision A, 12-20-2017 10 of 46...
  • Page 11 I/O ZF PWR EFCT/BD CAN bus Zoom focus module I/O EFCT I/O FRAM CAN bus Framing module I/O EFCT CAN bus Effect and CMYC module/IBD and CMYC module Figure 13: Connections MAC Encore Performance - Revision A, 12-20-2017 11 of 46...
  • Page 12 Safety loop Temp. sensor 24V Power BOTTOM VIEW Label P/N 33120127-B 33120127-B MAC Quantum Base PCB connections label Material: PE 100 White S-692 Size: 118 x 125 mm Figure 16: Connections MAC Encore Performance - Revision A, 12-20-2017 12 of 46...
  • Page 13: Replacing The Main Pcba

    Remove the air filter. See “Replacing the air filter” on page 14. Remove the four Torx25 screws (1). Disconnect the connectors. Replace the PFC PCBA. Follow the procedure in reverse order. Figure 19: Replacing the PFC PCBA MAC Encore Performance - Revision A, 12-20-2017 13 of 46...
  • Page 14: Replacing The Dc-Dc Pcba

    Pull away the filter assembly (1) from the fixture. Gently pull off the filter retainer to access the air filter. Replace the air filter. Follow the procedure in reverse order. Figure 22: Replacing the air filter MAC Encore Performance - Revision A, 12-20-2017 14 of 46...
  • Page 15: Yoke

    Follow the procedure in reverse order. NOTE! Make sure that no wires are stuck between the yoke covers. Figure 24: How not to fasten yoke covers Figure 25: How not to fasten yoke covers MAC Encore Performance - Revision A, 12-20-2017 15 of 46...
  • Page 16: Replacing The Pan Belt

    Figure 26: Cutting the cable ties Pull out the connectors. Figure 27: Pulling out the connectors Remove the ground wire (2). Move the cables to the center. Figure 28: Removing the ground wire MAC Encore Performance - Revision A, 12-20-2017 16 of 46...
  • Page 17 10. Push the locknut outwards to loosen the pan belt (6). 11. Tighten the locknut to hold it in that position. 12. Replace the pan belt. Figure 31: Replacing the pan belt MAC Encore Performance - Revision A, 12-20-2017 17 of 46...
  • Page 18: Replacing The Tilt Sensor Pcba

    Remove the tilt sensor PCBA. See “Replacing the tilt sensor PCBA” on page 18. Loosen the locknut (1). Push the belt tensioner to the left (2). Figure 34: Loosening the locknut MAC Encore Performance - Revision A, 12-20-2017 18 of 46...
  • Page 19: Position Of The Pan/Tilt Sensors

    15. Loosen the tilt and pan belts. Remove the screws (1). Remove the PCBA (2). Follow the procedure in reverse order. Figure 37: Replacing the pan motor MAC Encore Performance - Revision A, 12-20-2017 19 of 46...
  • Page 20: Replacing The Tilt Motor

    15 minutes until the PSUs have been discharged. Remove the two Torx25 screws (1). Remove the front side covers. Follow the procedure in reverse order. Figure 40: Removing the front side covers MAC Encore Performance - Revision A, 12-20-2017 20 of 46...
  • Page 21: Replacing The Zoom Belt

    Gently pull down both axles (4) through the zoom and focus assemblies, as far as possible. NOTE! Use gloves to avoid lubricant on your fingers. Figure 43: Pulling down the axles MAC Encore Performance - Revision A, 12-20-2017 21 of 46...
  • Page 22: Replacing The Focus Belt

    26. Remove the zoom lens assembly. See “Removing the front side covers” on page 20 Lock the head with the lens pointing downwards. Figure 46: Head pointing downwards MAC Encore Performance - Revision A, 12-20-2017 22 of 46...
  • Page 23 12. Pull the cable and connector (6) through the hole. 13. Pull off the focus belt (7) from the top pulley (8). Figure 49: Releasing the cable guide MAC Encore Performance - Revision A, 12-20-2017 23 of 46...
  • Page 24: Replacing The Frost Filter Arm

    Remove the multimodule. See “Replacing the multimodule” on page 26. Remove the zoom lens assembly. See “Removing the front side covers” on page 20 Remove the frost spring (1). Figure 52: Removing the frost spring MAC Encore Performance - Revision A, 12-20-2017 24 of 46...
  • Page 25: Position Of The Zoom/Focus Sensors

    The sensors are magnetic sensors with LEDs. The LED is green if the sensor is powered and the LED is orange if the sensor is activated by a magnet. Figure 55: Position of zoom/focus sensors MAC Encore Performance - Revision A, 12-20-2017 25 of 46...
  • Page 26: Multimodule

    Disconnect the CAN BUS and the DC power to the distribution board (3). Figure 57: Disconnecting CAN BUS and DC power Replace the multimodule (4). Follow the procedure in reverse order. Figure 58: Replacing the multimodule MAC Encore Performance - Revision A, 12-20-2017 26 of 46...
  • Page 27: Separating The Multimodule

    Open the module so that the cyan and magenta color filters are on one side and the yellow and CTC color filters are on the other side. Figure 61: Removing six screws MAC Encore Performance - Revision A, 12-20-2017 27 of 46...
  • Page 28: Position Of The Color Filters

    10. Follow the procedure in reverse order. Figure 63: Removing the two connectors Position of the color filters As standard, MAC Encore Performance is supplied with the following color filters installed: • Slot 1 - Blue 101 - P/N 5076512 •...
  • Page 29: Replacing The Animation Wheel

    Figure 66: Placing the framing module Replace the animation wheel (5). NOTE! Make sure that the indexing marks (6) are aligned. Follow the procedure reverse order. Figure 67: Aligning the indexing marks MAC Encore Performance - Revision A, 12-20-2017 29 of 46...
  • Page 30: Replacing The Framing Blade

    Place the framing module (2) next to the gobo and effect module (3). Figure 69: Placing the framing module Remove the two Torx10 screws (4). Figure 70: Removing the Torx10 screws MAC Encore Performance - Revision A, 12-20-2017 30 of 46...
  • Page 31: Rear End

    Figure 72: Removing rear end plastic cover Remove the two Torx20 screws (3) on each side. Remove the two rear end covers (4). Follow the procedure in reverse order. Figure 73: Removing rear end cover MAC Encore Performance - Revision A, 12-20-2017 31 of 46...
  • Page 32: Replacing The Fan Assemblies

    (1) with a marker and some tape to keep the LED engine adjusted. Remove the fan assemblies. Follow the procedure in “Replacing the fan assemblies” on page 32. Figure 76: Marking adjustment point MAC Encore Performance - Revision A, 12-20-2017 32 of 46...
  • Page 33 Remove the four Torx25 screws that hold the entire rear end assembly (2). Figure 78: Removing connectors and screws Disconnect the two white connectors (3). Figure 79: Disconnecting the two connectors MAC Encore Performance - Revision A, 12-20-2017 33 of 46...
  • Page 34 Gently tilt back the LED assembly. Figure 80: Tilting back the LED assembly Disconnect the five connectors (4). Figure 81: Disconnecting the five connectors Remove the LED assembly. Figure 82: Removing the LED assembly MAC Encore Performance - Revision A, 12-20-2017 34 of 46...
  • Page 35 Figure 83: Disconnecting the black connectors Remove the four Torx25 screws (6). Figure 84: Removing the four Torx 25 screws 10. Remove the six Torx10 screws (7). Figure 85: Removing the six Torx10 screws MAC Encore Performance - Revision A, 12-20-2017 35 of 46...
  • Page 36: Replacing The Reflector

    Figure 87: Removing the screws Replace the reflector. NOTE! Make sure that the arrow points towards the side with index 3. Follow the procedure in reverse order. Figure 88: Replacing the reflector MAC Encore Performance - Revision A, 12-20-2017 36 of 46...
  • Page 37: Replacing The Led Engine

    Figure 90: Replacing the LED engine Replacing the driver board Follow step 1-8 in the procedure in “Replacing the lens” on page 32. Disconnect the four connectors (1). Figure 91: Removing four connectors MAC Encore Performance - Revision A, 12-20-2017 37 of 46...
  • Page 38 Service manual Disconnect the connector for the fan (2). Remove the ten Torx10 screws (3). Replace the driver board. Follow the procedure in reverse order. Figure 92: Removing screws and connector MAC Encore Performance - Revision A, 12-20-2017 38 of 46...
  • Page 39: Updating Firmware

    When the update is finished, the fixture will reset and be ready for use. Updating firmware via DMX Find the MAC Encore Performance firmware that you want to upload. Turn the fixture on and wait until it has reset. Press DMX upload in the firmware uploader.
  • Page 40: Adressing Driver Pcba Can Bus Id

    Scroll down to the service menu. Hold the center button until the progress bar on the display is full. When you are asked if you are a Martin® certified technician, click YES by pressing the UP button. Then press the center button to confirm.
  • Page 41 Service manual Location of CAN Bus LED on: Effect module CMY module Zoom/Focus module LED driver MAC Encore Performance - Revision A, 12-20-2017 41 of 46...
  • Page 42: Maintenance

    Use care when cleaning optical components: the coated surfaces are fragile and easily scratched. Inspect Replace Clean Lubricate Adjust Update Martin by Harman ® Figure 94: Legend, maintenance schedule MAC Encore Performance - Revision A, 12-20-2017 42 of 46...
  • Page 43: Lubricating Of The Guide Rails For The Zoom/Focus Module And The Cmy Module

    Lubricate Maximum: +40° C (104° F). Adjust Daily “lamp-on” hours: 8 hours. Update Martin by Harman ® Voltage and frequency: 120-240 V nominal, 50/60 Hz. Figure 95: Legend, maintenance schedule MAC Encore Performance - Revision A, 12-20-2017 43 of 46...
  • Page 44: Maintenance Schedule

    Service manual Maintenance schedule MAC Encore Performance - Revision A, 12-20-2017 44 of 46 44 of 46...
  • Page 45 Service manual MAC Encore Performance - Revision A, 12-20-2017 45 of 46 45 of 46...
  • Page 46 Harman Professional Denmark ApS registered in the United States and/or other countries. Features, specifications, and appearance are subject to change without notice. Harman Professional Denmark ApS • Olof Palmes Allé 18 • 8200 Aarhus N • Denmark • www.martin.com MAC Encore Performance - Revision A, 12-20-2017 46 of 46...
