6.6

System Tab

To access the screen below, press the SW1 button (white) on the main board inside the door
(see section 3.6) and select the System tab.
6.6.1
1
2
3
4
5
6
1. This drop-down menu is used to set the language of the system.
If the language is changed, the recipes' names will be reset to default values.
2. This checkbox is used to allow any user to switch language directly from the selection screen.
3. This field is used to set the quantity of coffee drinks to brew before showing the "Waste Bin
Full" alert. To disable this alert, set the value to zero (0).
4. This field is used to set the water temperature in the tank, in Fahrenheit.
5. This field is used to set the minimum temperature of the water in the tank, in Fahrenheit. If the
water temperature drops below this setting, the coffee brewer will display an error message until
the temperature rises above this minimum. To disable this feature, set the value to zero (0).
6. This drop-down menu is used to set the color theme of the user interface.
7. This field is used to set the quantity of drinks to be ordered before a customer gets one for
free. To disable this function, set the value to zero (0). It is not recommended to use this
feature if the machine is equipped with an optional printer.
8. This field is used to set the quantity of drinks to be ordered before showing the "Rinse
Required Soon" alert. To disable this alert, set the value to zero (0).
9. This button is used to reset the System 1 and System 2 sub tabs back to factory settings.
This action does not affect the recipes.
10. This button resets all recipes back to factory settings (Information and Liquids & Ingr. sub tabs).
11. This button is used to save any parameters changes. Any unsaved changes will be lost.
ENCORE LITE Rev. 3 05/2018
800-561-6162
System 1 Sub Tab
7
8
9
10
11
