6.4

Password Pop-Up

This pop-up window will appear when pressing the
Recipes, System or Audit tabs. The user needs to type
in his password using the alphanumeric keyboard, then
press on ENTER. Depending on the password entered,
the user will gain access to different tabs.
6.5

Recipes Tab

To access the screen below, press the SW1 button (white) on the main board inside the brewer's
door (see section 3.6) and select the Recipes tab.
6.5.1
Coffee names and labels can be edited with
38
SERVICE & INSTALLATION MANUAL for Cafection's Encore Lite

Customization Sub Tab

The customization sub tab allows to edit blends names or labels. For each blend, it is
possible to display only one option (name or label) on the selection screen. Default blends'
names are Coffee 1, Coffee 2 and Coffee 3.
1. Use the "Label"
button to select
a tag for the
associated blend.
Use the "Name"
button to edit the
blend's name using
the text box.
2. Select the product
associated with
canister 1 (Milk or
Vanilla) and use the
checkbox to allow the user to add milk to its drinks on the selection screen.
3. This button is used to save any changes to the customization settings.
Any unsaved changes will be lost.
Labels list
www.cafection.com
Sophia - Global Management System
1
2
Blend name or label
Recipe name
800-561-6162
.
3
Milk
option
enabled
