POWERNAIL
®
CO.
Models 15FS Pneumatic PowerStapler™
OPERATION AND MAINTENANCE MANUAL
MANUAL DE OPERACION Y DE MANTENIMIENTO
MANUEL D'INSTRUCTIONS ET D'ENTRETIEN
WARNING
Read this manual before you use this PowerStapler®. Follow all safety warnings and
instructions. If you are uncertain about the operation of the stapler, call us directly
at 1-800-323-1653 for assistance or contact the closest Powernail Dealer for help.
Please retain this information for future reference.
rev. 2016.06.08
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Powernail 15FS
Summary of Contents for Powernail 15FS
- Page 1 Read this manual before you use this PowerStapler®. Follow all safety warnings and instructions. If you are uncertain about the operation of the stapler, call us directly at 1-800-323-1653 for assistance or contact the closest Powernail Dealer for help. Please retain this information for future reference.
-
Page 2: Table Of Contents
INTRODUCTION The PowerStapler ® Model 15FS Mallet Actuated Pneumatic Stapler is designed to bring Powernail quality to a pneumatic stapler. For those looking for ease of use in a pneumatic tool, the PowerStapler Model 15FS provides several distinct advantages. The Model 15FS can staple 3/4” flooring down to 1/2” tongue and groove hardwood flooring through the use of easy-to-change, no-mar adapter plates. -
Page 3: Safety Instructions
Powerstapler. Powernail staples are available in various lengths. Contact your Powernail Dealer for PowerStaples. Use only Powernail replacement parts in the repair or maintenance of this stapler. Parts or repair services are available from the manufacturer or from agents authorised by the manufacturer. -
Page 4: Operating Instructions
MALLET TO ACTIVATE THE STAPLER, use the rubber capped end only. TO LOAD MODEL 15FS: Before each use, check all screws to be sure Pull back the spring loaded pusher lever until it they are tight. Shock and vibration can loosen locks. -
Page 5: Replacement
OPERATING INSTRUCTIONS, continued Drive Blade Assembly Replacement: To Clear a Staple Jam: Remove Rubber cap from plunger head. Loosen the two screws with a 4mm allen wrench on the gate plate. Remove large compression spring. Slide the gate plate down & remove which Remove four screws from metal cap using will allow you to inspect &... - Page 6 MODELS 15FS PARTS LIST For this parts list and other Powernailer schematics, please visit the Powernail Parts Store at http://www.powernail.com Item Sold Separate or PART NO. DESCRIPTION Req’d Assembly # 09-15FS-101 Rubber Cap 09-15FS-102 Spring Seat 09-15FS-103 Compression Spring (Rubber Cap)
-
Page 7: Schematic
DESCRIPTION REQ’D 09-445-29737 5/8” Adapter Pad 09-445-29738 3/4” Adapter Pad 09-445-29757A 6 Oz. Air Tool Oil DRIVE BLADE ASSEMBLY: 09-15FS-120A Whole assembly is necessary, individual parts not sold separately. For Step-by-Step Videos and Instructions, Visit our Web Site at: www.Powernail.com... - Page 8 STAPLER SAFETY DECALS Warning! • Read and understand the tool labels and manuals before operating. • Operators and others in work area MUST wear EYE and EAR protection. • Use safety glasses with side shields. • NEVER point tool at yourself or others in the work area. • Only connect air to an unloaded tool and always keep tool pointed in a safe direction.
- Page 9 PowerStapler 15FS Trouble Shooting Chart PROBLEM POSSIBLE CAUSE SOLUTION 1. Zero of Low air pressure Check air supply for 80 psi minimum to 110 psi maximum 2. Lack of lubrication Manually lubricate through male air inlet fitting Driving blade does 3.
-
Page 10: Depth Chart
POWERSTAPLE DEPTH CHART ® This chart will assist you in determining the proper length of PowerStaple use for various thicknesses of flooring. Approximate vertical penetration of the PowerStaple under the hardwood floor is shown for each application. This is only a guide. Results should be tested in the field before proceeding. 33/32"... -
Page 11: Accessory Products
The TOOL BAG holds all Powernailer® configurations including the FLEX and POWER ROLLER models. The Powernail TOOL BAG is built tough with a double wall of padded industrial nylon to protect your tools. Corners are reinforced with leather for durability. - Page 12 POWERNAIL COMPANY, INC. 1300 Rose Road, Lake Zurich, IL 60047 US Phone: 1-800-323-1653 or 847-847-3000 www.powernail.com...
