INSTALLATION AND OPERATION MANUAL
FIGURE 3 – CWFE1COAX
CAT5e/6
FIGURE 4 – CWFE1COAX
FRONT PANEL
TECH SUPPORT: 1.888.678.9427
REAR PANEL
NOTE: Remove Electrical Connector for Rack Mount Units
CWFE(1,2)COAX[M]
COAX (75Ω)
BLACK
BLACK WITH WHITE STRIPE
INS_CWFE(1,2)COAX[M]_REV–
11/18/10
PAGE 3
