Warning!
Operation of the
inverter without a
proper ground
connection may
result in an
electrical safety
hazard.
3.4 Rear view: GP-SW3000 and GP-SW2000
d) Battery Terminals
a) Ventilation port:
Do not obstruct, allow at least one inch for airflow.
b) Remote Port:
An optional remote is available from Go-Power Electric Inc.
c) Chassis Ground:
Ground to vehicle chassis using # 8 AWG wire.
d) Battery terminals:
Connect to 12 V battery or other 12 V power source. [+] is positive and
[-] is negative. Reverse polarity connection will blow the internal fuse and may
damage inverter permanently.
3.5 Rear view: GP-SW1000
a. Remote Port
Go Power! GP-SW3000, GP-SW2000, GP-SW1000
a) Ventilation
c) Chassis Ground
b. Ventilation Port
and GP-SW600
Inverter Owner's Manual
b) Remote Port
