Setpoint Setup - Define Instruments PRO-CTR200 Manual

26
8.8 - Edit CAL PIN number
A _ _ _ EDIT CAL PIN NUMBER scrolls across the display, and SKIP appears. Press
to skip and return to the operational display, or the
to ENTER and change your PIN number.
B _ _ _ ENTER NEW CAL PIN NUMBER scrolls across the display, and the current
PIN (default 1) appears. Using the
number. Then press
9

SETPOINT SETUP

The soft ware in your controller will allow you to confi gure 1 batch setpoint (SP 1)
and 3 standard setpoints (SP 2–4). SP 5 may be used as an LED indicator, if desired.
SP 6 is reserved.
Setpoints with no corresponding relay output hardware may be used as simple LED
indicators, if desired. In this case, features requiring relay output functionality will
continue to appear in the setup menu, but will be ignored by the controller.
9.1 - Enter SP PIN number
A Enter setpoint setup mode by pressing and holding the
_ _ _ ENTER SP PIN NUMBER scrolls across the display, and 0 appears. Use the
and buttons to enter your security code (factory default 1). Then press
. If the correct PIN is entered, setup is started at 9.2.
If an incorrect PIN number is entered, _ _ _ INCORRECT PIN NUMBER – ACCESS
DENIED scrolls across the display, and it returns to normal operating mode.
You will have the opportunity to change your PIN number at the end of this section
(9.3). If you have forgotten your PIN number, see Section 11.
PRO-CTR-MAN-16V03 (0128)
and
to exit to the operational display.
button and then
buttons, enter your new CAL PIN
button for 3 seconds.
Copyright © 2016 Defi ne Instruments
