here. (Enter this value with reference to your decimal point position - the controller will auto-
matically calculate the correct scale factor for you.)
F _ _ _ RESET AT POWER UP scrolls across the display, and the current setting
appears. Use the
at power up), ZERO (count value will be set to zero at power up), or LD VAL
(count value will be set to a user defi ned load value at power up - see 8.2G).
Then press
G _ _ _ LOAD VALUE scrolls across the display, and the load value appears. (This
value will loaded into the selected counter at power up when LD VAL is selected
in 8.2F.) Use the
then press
This value is also used for the C input reset functions RSOFAB (see 6.9) and RSOFST (see 6.10).
H _ _ _ COUNTER SETUP scrolls across the display, and SKIP appears. You are
now back at 8.2A. To set up another input channel, follow the instructions from
8.2A–H again. If you do not wish to set up another input channel, press
to skip to 8.3.
8.3 - Rate display setup
A _ _ _ RATE DISPLAY SETUP scrolls across the display, and SKIP appears. Press
to skip to 8.4, or the
The rate value is taken from the primary count input (signal A).
B _ _ _ DECIMAL POINT POSITION scrolls across the display, and the current
selection appears. Use the
0.1234 or 0.12345, and then press
C _ _ _ ROUNDING scrolls across the display, and the currently selected rounding
setting appears. Using the
Then press
Rounding is quoted in display counts and is not infl uenced by decimal point position. For exam-
ple, if your input signal is 5.3, the display will show: 5.3 (for rounding=None), 5.4 (for round-
ing=2), 5.5 (for rounding=5) or 5.0 (for rounding=10).
