2.2 - Front panel
/
The SP LED's are used to indicate active setpoints.
SPX
This button is used to access the Input Setup & Calibration menu (Section 8).
This button is typically used to save your settings and advance to the next step
in the setup process. A custom function can also be programmed (see 8.5B).
This button is typically used to scroll through options or increase values in the
setup menu. Pressing this button from the main display will allow you to view/
reset the Peak value, and view the Rate and Primary Counter values (see 2.3).
This button is typically used to scroll through options or decrease values in the
setup menu. Pressing this button from the main display will allow you to view/
reset the Valley value, and view the B and C Counter values (see 2.3).
This button is used to access the Setpoint Setup menu (Section 9) and the
Setpoint Direct Access menu (Section 10).
2.3 - Up and down button shortcuts
Pressing the
and
access to a number of values held in the controller's memory. These variables will ap-
pear in the order shown in the table below, and will cycle continuously at each press
of the
or
button. Press
Up and down button shortcuts
PEAK
Maximum measured rate value since the instrument was turned on/reset
PRMCNT
Current value of primary counter
RATE
Current rate value
VALLEY
Minimum measured rate value since the instrument was turned on/reset
B CNT
Current value of B counter
C CNT
Current value of C counter
PEAK and VALLEY may be reset to zero by pressing the
same time while the variable is being displayed.
