J _ _ _ BREAK DELAY scrolls across the display, and the current break delay value
for the selected setpoint appears. This is the time delay between setpoint de-
activation, and when the relay turns off . Adjust this value in 0.1 second incre-
ments using the

Please skip to 9.2L now.
K _ _ _ ON TIME scrolls across the display, and the current selection appears. This
defi nes the time that a 'Timed' relay (see 9.2F) remains energised. Adjust this
value in 0.1 second increments using the
L _ _ _ STARTUP INHIBIT scrolls across the display, and the current selection
appears. Use the
select NO or YES. Then press
This option can be used with setpoints which may
be active initially at power up. Setting STARTUP
INHIBIT to YES will cause a relay to remain off (de-
energised) at power up until it has fi rst reached its
inactive state. It will then function normally.
M _ _ _ RESET ACTION scrolls across the display, and the current selection ap-
pears. This parameter specifi es the action to be executed when the 'Reset Edge'
(9.2O) occurs. Use the
mary counter), RST B (reset B counter), RST C (reset C counter), RST BT (reset
batch), RSTBTC (reset batch count) or UNLTCH (unlatch all setpoints). Then
press to accept.

If you selected NONE, then the step that you proceed to now will depend
on which setpoint you are editing (your selection in 9.2A):

SP 1 = Skip to 9.2O now.

SP2–4 = Skip to 9.2Q now.

If you selected RS PRM, RST B, RST C or RSTBTC, continue to 9.2N now.

If you selected RST BT or UNLTCH, skip to 9.2O now.
See 7.1 for more information on the batching feature.
N _ _ _ RESET VALUE scrolls across the display, and the current reset value ap-
pears. Use the
into the destination register selected in 'Reset Action' (9.2M) when the selected
'Reset Edge' (9.2O) occurs. Then press
Copyright © 2016 Defi ne Instruments
and buttons, and then press
and buttons to
.
and buttons to select: NONE, RS PRM (reset pri-
and buttons to adjust the value which will be loaded
.
and buttons, and then press
Startup
inhibit
POWER UP
to accept.
PRO-CTR-MAN-16V03 (0128)
29
.
(Energised below)
TIME
