DIMENSIONS & INSTALLATION
5.1 - Case dimensions
96 92
mm mm
(3.78") (3.62")
48 45
mm mm
(1.89") (1.77")
Copyright © 2016 Defi ne Instruments
120
mm (4.72")
4
mm (0.16")
155
mm (6.10")
120
mm
4
mm (0.16")
155 minimum depth required behind panel
mm (6.10")
minimum depth required behind panel
(4.72")
39
mm (1.54")
Cabling
Allowance
39
mm (1.54")
Cabling
Allowance
