8.5 - User programmable input functions
This section allows you to assign a custom function to the front panel
the rear user input pins (see 3.6). The following functions are available:
User programmable input functions
NONE
No action
RS PRM
Reset primary counter to load value
(8.2G)
RST B
Reset B counter to load value (8.2G)
RST C
Reset C counter to load value (8.2G)
RST BT
Reset batch value to zero
RSTBTC
Reset batch counter value to zero
* When a setpoint is confi gured for latching mode it will activate as normal and remain activated
until it is unlatched, either by setpoint logic or manually (as specifi ed in this section). Refer to section
9.2F to confi gure setpoint latching.
A
_ _ _ USER PROGRAMMABLE INPUT FUNCTIONS scrolls across the display,
and SKIP appears. Press
ENTER input functions setup.
B
_ _ _ PROGRAM BUTTON scrolls across the display, and the current function
appears. This specifi es the operation to be executed when the
pressed (for more than 2 seconds) from the main display. Referring to the table
above, use the
C
_ _ _ USER INPUT 1 scrolls across the display, and the current function appears.
This specifi es the operation to be executed when the User 1 pin is activated
from the rear of the unit (see 3.6). Referring to the table above, use the
buttons to select a function, and then press
D
_ _ _ USER INPUT 2 scrolls across the display, and the current function appears.
This specifi es the operation to be executed when the User 2 pin is activated
from the rear of the unit (see 3.6). Referring to the table above, use the
buttons to select a function, and then press
Copyright © 2016 Defi ne Instruments
to skip to 8.6, or the
and
buttons to select a function, and then press
UNLTCH
Unlatch all setpoints*
UNLT 1
Unlatch SP 1*
UNLT 2
Unlatch SP 2*
UNLT 3
Unlatch SP 3*
UNLT 4
Unlatch SP 4*
button and then
.
.
PRO-CTR-MAN-16V03 (0128)
23
button, or
to
button is
.
and
and
