INPUT SETUP & CALIBRATION
Setup menu display note:
If you are using a single display (PRO-CTR100), the menu title or text prompt will
scroll across the display, and toggle with the currently selected option. If you are
using a dual display (PRO-CTR200), the menu title or text prompt will scroll across the
bottom row, and the currently selected option will appear in the top row.
8.1 - Enter CAL PIN number
A
Enter the calibration mode by pressing the
_ _ _ ENTER CAL PIN NUMBER scrolls across the display, and 0 appears. Use the
and
buttons to enter your security code (factory default 1). Then press
. If the correct PIN is entered, setup is started at 8.2.
If an incorrect PIN number is entered, _ _ _ INCORRECT PIN NUMBER – ACCESS
DENIED scrolls across the display, and it returns to normal operating mode.
You will have the opportunity to change your PIN number at the end of this section
(8.8). If you have forgotten your PIN number, see Section 11.
8.2 - Counter setup
There are 3 counter inputs available on the input module:
›
Count A input (drives the primary counter)
›
Count B input
›
Count C input
When the primary counter mode is set to AB IND (A & B independent) the A input
drives the primary counter and the B input drives the secondary counter. In other
count modes, the A and B inputs are both used to drive the primary counter, so the
B counter options are not available. IT IS THEREFORE ADVISABLE TO SET UP THE
PRIMARY COUNT MODE FIRST.
PRO-CTR-MAN-16V03 (0128)
button.
