DIMENSIONS & INSTALLATION
4.1 - Case dimensions
48
45
mm
mm
(1.89")
(1.77")
96
92
mm
mm
(3.78")
(3.62")
TEX-BAR-MAN-15V05 (0903)
120
mm
4
mm (0.16")
155
minimum depth required behind panel
mm (6.10")
120
mm (4.72")
4
mm
(0.16")
155
mm (6.10")
(4.72")
minimum depth required behind panel
Copyright © 2015 Defi ne Instruments
39
mm
(1.54")
Cabling
Allowance
39
mm (1.54")
Cabling
Allowance
