DEMO MANUAL DC1605B
parts list
ITEM QTY REFERENCE
Required Circuit Components
1
1
U1
Additional Demo Board Circuit Components
2
16
C1, C2, C3, C4, C5, C6, C8, C9, C10, C11,
C12, C13, C14, C19, C27, C34
3
8
C7, C15, C16, C17, C18, C26, C28, C33
4
3
C20, C21, C25
5
1
C22
6
2
C23, C24
7
3
LED1-LED3, LED6-LED11
8
2
LED4, LED5
9
9
Q1-Q9
10
6
R1-R6
11
10
R7, R10, R25, R27, R48, R67, R70, R73,
R76
12
12
R8, R11, R26, R28, R30, R46, R58, R59,
R68, R71, R74, R77
13
14
R9, R12, R13, R14, R41, R42, R44, R55,
R56, R57, R69, R72, R75, R78
14
2
R15, R16
15
5
R17, R18, R61, R63, R65
16
3
R19, R20, R21
17
6
R22, R23, R24, R62, R64, R66
18
0
R31, R32, R33, R49, R51, R53
(OPTIONAL)
19
8
R34, R35, R36, R37, R38, R50, R52, R54 RES 0Ω 0.1W 1% 0603 SMD
20
2
R39, R40
21
1
R43
22
1
R45
23
1
R47
24
1
R60
25
1
U2
26
1
U3
27
1
U4
28
1
U5
29
1
U6
30
1
U7
31
1
U8
Hardware: For Demo Board Only
32
1
J1
33
1
J2
34
6
JP1-JP6, JP9
35
1
JP7, JP8
36
1
JP10
37
4
MH1-MH4
38
2
SW1, SW2
39
19
TP1-TP19
40
1
TP20
16
PART DESCRIPTION
IC PROG HEX VOLT SUPERVISOR EEPROM SSOP-24 LINEAR: LTC2936CGN#PBF
CAP CER 10nF 25V 10% X7R 0603
CAP CER 100nF 16V 10% X7R 0603
CAP CER 1µF 16V 10% X7R 0603
CAP CER 22µF 25V 10% X5R 1210
CAP CER 10µF 16V 10% X5R 0805
LED-DUAL-COLOR BLUE-RED SS SMD
LED GREEN SS TYPE BRIGHT SMD
DUAL N-CHANNEL FET2N7002DWA
RES ARRAY 10k/20k 0.1W 0.1% 25ppm 0606 SMD
RES 3k 0.1W 5% 0603 SMD
RES 1k 0.1W 5% 0603 SMD
RES 10k 0.1W 1% 0603 SMD
RES 402k 0.1W 1% 0603 SMD
RES 200k 0.1W 1% 0603 SMD
RES 604k 0.1W 1% 0603 SMD
RES 100k 0.1W 1% 0603 SMD
RES 0Ω 0.1W 1% 0603 SMD
0Ω RESISTOR ARRAY, 4 RES, 1206
RES 49.9k 0.1W 1% 0603 SMD
RES 249 Ω 0.1W 1% 0603 SMD
RES 9.31k 0.1W 1% 0603 SMD
RES 1.50k 0.1W 1% 0603 SMD
IC ADC 24-BIT DELTA SIGMA 16-CH WITH I
IC OP AMP DUAL MICROPOWER
2
IC DAC 12-BIT OCTAL WITH I
C
IC VREF SERIES PRECISION REFERENCE
FIXED 5V 100mA MICROPOWER LDO
2
2K-BIT I
C SERIAL EEPROM
DUAL 4A IDEAL DIODES WITH ADJ CURR LMT
CONN HEADER 12POS 2mm STR DL PCB
CONN PWR JACK 2.1mm × 5.5mm HIGH CUR
2mm PIN HEADER 1×3
2mm PIN HEADER 1×4
0.100" PIN HEADER 1×6
SPACER STACKING #4 SCREW NYLON
BLK SWITCH TACTILE SPST-NO 0.05A 12V
TERM SOLDER TURRET .219"H .109"L
TERM SOLDER TURRET .156"H .084"L
MANUFACTURER/PART NUMBER
MURATA: GRM188R71E103KA01D
MURATA: GRM188R71C104KA01D
MURATA: GRM188R71C105KA12D
MURATA: GRM32ER61E226KE15L
MURATA: GRM21BR61C106KE15L
KINGBRIGHT: APHB1608QBDSURKC
PANASONIC-SSG: LNJ326W83RA
DIODES INC.: 2N7002DWA-7
VISHAY: ACASN1002S2002AT
VISHAY: CRCW06033K0OJNEA
VISHAY: CRCW06031K0OJNEA
VISHAY: CRCW060310K0FKEA
VISHAY: CRCW0603402KFKEA
VISHAY: CRCW0603200KFKEA
VISHAY: CRCW0603604KFKEA
VISHAY: CRCW0603100KFKEA
VISHAY: CRCW060366K5FKEA
PANASONIC: EXB-38VR000V
VISHAY: CRCW060349K9FKEA
VISHAY: CRCW0603249RFKEA
VISHAY: CRCW06039K31FKEA
VISHAY: CRCW06031K50JNEA
2
C
LINEAR: LTC2499CUHF#PBF
LINEAR: LTC6078CMS8
LINEAR: LTC2637CMS-HMX12
LINEAR: LT6654AMPS6-4.096
LINEAR: LT1761ES5-5#PBF
MICROCHIP: 24AA02T-I/OT
LINEAR: LTC4415IMSE#PBF
FCI: 98414-G06-12ULF
CUI INC.: PJ-002AH
SULLINS: NRPN031PAEN-RC
SULLINS: NRPN041PAEN-RC
SULLINS: PRPC006SAAN-RC
KEYSTONE: 8831
C&K: PTS635SL25SMTR LFS
MILL MAX:: 2501-2-00-80-00-00-07-0
MILL MAX: 2308-2-00-80-00-00-07-0
dc1605bf
