DEMO MANUAL DC1605B

Quick start proceDure

The following procedure describes how to set up a DC1605B
demo system.
1. Download and install the LTpowerPlay GUI:
com/ltpowerplay
2. Remove the board from the ESD protective bag and
place it on a level surface. Connect the DC1613 I
SMBus/PMBus controller to the DC1605B board using
the 12-pin ribbon cable.
Figure 4. Connecting DC1605B Board and the DC1613 USB to I
8
3. Plug the USB-to-I
USB port on your PC. The board should power up with
+5V and +3.3V
www.linear.
and CMP LEDs will illuminate blue.
2
C/
2
C/SMBus/PMBus Controller into a
LEDs illuminated green. The GPIO
OUT
2
C/SMBus/PMBus Controller
dc1605bf
