A S S E M B L Y & I N S T A L L A T I O N G U I D E
APPLICATION
GM Truck (Full-size Trucks)
BEDXTENDER HD™ shown assembled and installed on truck.
Remove contents from box and check for damage.
Verify all parts against parts list.
Read and understand instructions completely before attempting assembly
and installation.
Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the
following patents:
5,700,047; 6,113,173; 6,402,215; 6,805,392; 7,063,366; 7,393,035; 7,654,598; 7,681,935; 7,841,638
www.amp-research.com
PART #
74805-00A (Silver)
1/8
74805-01A(Black)
INSTALLATION TIME
1 Hour
SKILL LEVEL
2 3
1
1= Easy
TOOLS REQUIRED
Phillips screw driver
Torx T-25 driver
Power drill
1/8" drill bit
21/64" drill bit
Center punch
Supplied templates
Soapy Water
WARRANTY
3-Year Limited Warranty
rev 08.13.12
4
Advertisement
Table of Contents
Related Manuals for AMP Research BEDXTENDER HD 74805-00A
Summary of Contents for AMP Research BEDXTENDER HD 74805-00A
- Page 1 Read and understand instructions completely before attempting assembly WARRANTY and installation. 3-Year Limited Warranty Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents: 5,700,047; 6,113,173; 6,402,215; 6,805,392; 7,063,366; 7,393,035; 7,654,598; 7,681,935; 7,841,638 www.amp-research.com...
- Page 2 A M P R E S E A R C H B E D X - T E N D E R H D ™ PARTS LIST AND HARDWARE IDENTIFICATION 74606-01A 20-3654-90 20-0xxxx-13 74608-01A 11-03639-90 Mounting Bracket Bumper Strap Buckle Assembly Quick Mount PT-Screw Bracket Set...
- Page 3 A M P R E S E A R C H B E D X T E N D E R H D ™ A M P R E S E A R C H B E D X T E N D E R H D ™ MOUNTING BRACKET INSTALLATION - CHEVROLET SILVERADO / GMC SIERRA 2007+ PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING WITH INSTALLATION Use the M5 bolts and nuts to...
- Page 4 A M P R E S E A R C H B E D X T E N D E R H D ™ BED X-TENDER ASSEMBLY Slide the center tube (With Amp logo) into the center Using template measure 7” from each end of the tube of the 3-tube assembly.
- Page 5 A M P R E S E A R C H B E D X - T E N D E R ™ BED X-TENDER ASSEMBLY – CONTINUED Attach plastic upright around the tube juncture, plac- Tighten PT-Screws using a T-25 torx driver, starting in ing rubber bumpers into the two ends of the upright.
- Page 6 A M P R E S E A R C H B E D X - T E N D E R ™ A M P R E S E A R C H B E D X - T E N D E R ™ For Toyota applications the supplied Strap Buckle Insert must be used.
- Page 7 Congratulations on your purchase of the AMP Research BEDXTENDER HD. Here’s what you need know... BEDXTENDER HD™ OPERATION With the tailgate open, place BEDXTENDER pivot pins into the left and right mounting brackets. Rotate to 45 until it drops into place, then lower onto the open tailgate.
