A S S E M B L Y & I N S T A L L A T I O N G U I D E
APPLICATION
Ford Ranger
BEDXTENDER HD™ shown assembled and installed on truck.
Remove contents from box and check for damage.
Verify all parts against parts list.
Read and understand instructions completely before attempting assembly
and installation.
Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the
following patents:
5,700,047; 6,113,173; 6,402,215; 6,805,392; 7,063,366; 7,393,035; 7,654,598; 7,681,935; 7,841,638
www.amp-research.com
PART #
74842-01A (Black)
1/6
INSTALLATION TIME
1 Hour
SKILL LEVEL
2 3
1
1= Easy
TOOLS REQUIRED
Phillips screw driver
Torx T-25 driver
Supplied templates
Soapy Water
WARRANTY
3-Year Limited Warranty
rev 03.19.19
4
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AMP Research BedXTender HD MAX 74842-01A
Summary of Contents for AMP Research BedXTender HD MAX 74842-01A
- Page 1 3-Year Limited Warranty Read and understand instructions completely before attempting assembly and installation. Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents: 5,700,047; 6,113,173; 6,402,215; 6,805,392; 7,063,366; 7,393,035; 7,654,598; 7,681,935; 7,841,638 www.amp-research.com...
- Page 2 A M P R E S E A R C H B E D X T E N D E R H D ™ PARTS LIST AND HARDWARE IDENTIFICATION Quick Mount M6 Bolt Plastic Washer M6 Nut Bracket Set Pivot Upright Assembly Bumper Upright Outer Bumper Upright Inner Strap Buckle...
- Page 3 A M P R E S E A R C H B E D X T E N D E R H D ™ Driver side, Bracket and hardware orientation Passenger side, Bracket and hardware orientation Install Pivot Brackets to upper two threaded holes on D-Pillar.
- Page 4 A M P R E S E A R C H B E D X T E N D E R H D ™ BED X-TENDER ASSEMBLY Measure 7” from each end of the three center Slide 3 center tubes into the open ends of the bent tubes and mark with tape.
- Page 5 A M P R E S E A R C H B E D X T E N D E R H D ™ BED X-TENDER ASSEMBLY – CONTINUED Tighten PT-Screws using a T-25 torx driver, starting Attach plastic upright around the tube juncture, in the middle of each upright, then the outer screws placing rubber bumpers into the two ends of the upright.
- Page 6 A M P R E S E A R C H B E D X T E N D E R H D ™ A M P R E S E A R C H B E D X - T E N D E R ™ When the BEDXTENDER is at the furthest rear position, push down on the buckle to insert into tailgate latch.
-
Page 7: Limited Warranty
Congratulations on your purchase of the AMP Research BEDXTENDER HD. Here’s what you need know... BEDXTENDER HD™ OPERATION With the tailgate open, place BEDXTENDER pivot pins into the left and right mounting brackets. Rotate to 45 until it drops into place, then lower onto the open tailgate.
