A S S E M B L Y & I N S T A L L A T I O N G U I D E
APPLICATION
RAM DT
BEDXTENDER HD™ shown assembled and installed on truck.
Remove contents from box and check for damage.
Verify all parts against parts list.
Read and understand instructions completely before attempting assembly
and installation.
Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the
following patents:
5,700,047; 6,113,173; 6,402,215; 6,805,392; 7,063,366; 7,393,035; 7,654,598; 7,681,935; 7,841,638
www.amp-research.com
YEAR
2019
1/6
PART #
74840-00A (Silver)
INSTALLATION TIME
SKILL LEVEL
1
TOOLS REQUIRED
Phillips screw driver
Torx T-25 driver
Power drill
5/32" drill bit
Center punch
Supplied templates
Soapy Water
WARRANTY
3-Year Limited Warranty
74840-01A(Black)
1 Hour
4
2 3
1= Easy
rev 05.14.19
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AMP Research BedXTender HD Max 74840-00A
Summary of Contents for AMP Research BedXTender HD Max 74840-00A
- Page 1 3-Year Limited Warranty Read and understand instructions completely before attempting assembly and installation. Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents: 5,700,047; 6,113,173; 6,402,215; 6,805,392; 7,063,366; 7,393,035; 7,654,598; 7,681,935; 7,841,638 www.amp-research.com...
- Page 2 A M P R E S E A R C H B E D X T E N D E R H D ™ PARTS LIST AND HARDWARE IDENTIFICATION Strap Buckle Assembly Quick Mount Bumper Phillips head PT-Screw Bracket Set screw (included in 74608-01A) Pivot Upright Assembly...
- Page 3 A M P R E S E A R C H B E D X T E N D E R H D ™ UNIVERSAL MOUNTING BRACKET INSTALLATION Following instructions Use center punch to firmly mark drill locations as on the supplied drill indicated on templates.
- Page 4 A M P R E S E A R C H B E D X T E N D E R H D ™ BED X-TENDER ASSEMBLY Measure 7” from each end of the three center Slide 3 center tubes into the open ends of the bent tubes and mark with tape.
- Page 5 A M P R E S E A R C H B E D X T E N D E R H D ™ BED X-TENDER ASSEMBLY – CONTINUED Tighten PT-Screws using a T-25 torx driver, starting Attach plastic upright around the tube juncture, in the middle of each upright, then the outer screws placing rubber bumpers into the two ends of the and lastly the remaining two to evenly tighten.
- Page 6 A M P R E S E A R C H B E D X T E N D E R H D ™ A M P R E S E A R C H B E D X - T E N D E R ™ When the BEDXTENDER is at the furthest rear position, push down on the buckle to insert into tailgate latch.
- Page 7 Congratulations on your purchase of the AMP Research BEDXTENDER HD. Here’s what you need know... BEDXTENDER HD™ OPERATION With the tailgate open, place BEDXTENDER pivot pins into the left and right mounting brackets. Rotate to 45 until it drops into place, then lower onto the open tailgate.
