A S S E M B L Y & I N S T A L L A T I O N G U I D E
APPLICATION
GM Silverado/Sierra 1500
BEDXTENDER HD™ shown assembled and installed on truck.
Remove contents from box and check for damage.
Verify all parts against parts list.
Read and understand instructions completely before attempting assembly
and installation.
Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the
following patents:
5,700,047; 6,113,173; 6,402,215; 6,805,392; 7,063,366; 7,393,035; 7,654,598; 7,681,935; 7,841,638
www.amp-research.com
YEAR
2019
1/7
PART #
74831-00A (Silver)
INSTALLATION TIME
1
TOOLS REQUIRED
Phillips screw driver
Torx T-20 driver
Torx T-25 driver
Power drill
1/8" drill bit
21/64" drill bit
Center punch
Supplied templates
Soapy Water
Masking Tape
3-Year Limited Warranty
74831-01A (Black)
1 Hour
SKILL LEVEL
4
2 3
1= Easy
WARRANTY
rev 05.02.19
Advertisement
Related Manuals for AMP Research BedXTender HD 74831-00A
Summary of Contents for AMP Research BedXTender HD 74831-00A
- Page 1 Read and understand instructions completely before attempting assembly and installation. 3-Year Limited Warranty Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents: 5,700,047; 6,113,173; 6,402,215; 6,805,392; 7,063,366; 7,393,035; 7,654,598; 7,681,935; 7,841,638 www.amp-research.com...
- Page 2 A M P R E S E A R C H B E D X - T E N D E R H D ™ PARTS LIST AND HARDWARE IDENTIFICATION Bumper Strap Buckle Assembly Quick Mount PT-Screw Bracket Set Pivot Upright Assembly Bumper Upright Inner Bumper Upright Outer Double Bend Center Tube (With AMP Logo)
- Page 3 A M P R E S E A R C H B E D X T E N D E R H D ™ MOUNTING BRACKET INSTALLATION - CHEVROLET SILVERADO / GMC SIERRA 2019 PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING WITH INSTALLATION Assemble U-Nuts on to bracket plates in the orientation shown.
- Page 4 A M P R E S E A R C H B E D X T E N D E R H D ™ Enlarge hole in D-Pillar with 21/64” drill bit. Fasten the Quick Mount Bracket to the D-Pillar with one M8 Hex Bolt and Bracket Nut Plate Assembly.
- Page 5 A M P R E S E A R C H B E D X T E N D E R H D ™ BED X-TENDER ASSEMBLY Slide the center tube (With Amp logo) into the center Using template measure 7” from each end of the tube of the 3-tube assembly.
- Page 6 A M P R E S E A R C H B E D X - T E N D E R ™ BED X-TENDER ASSEMBLY – CONTINUED Attach plastic upright around the tube juncture, Tighten PT-Screws using a T-25 torx driver, starting in placing rubber bumpers into the two ends of the the middle of each upright, then the outer screws and upright.
- Page 7 A M P R E S E A R C H B E D X - T E N D E R ™ A M P R E S E A R C H B E D X - T E N D E R ™ When the BEDXTENDER is at the furthest rear position, push down on the buckle to insert into tailgate latch.
-
Page 9: Limited Warranty
Congratulations on your purchase of the AMP Research BEDXTENDER HD. Here’s what you need know... BEDXTENDER HD™ OPERATION With the tailgate open, place BEDXTENDER pivot pins into the left and right mounting brackets. Rotate to 45 until it drops into place, then lower onto the open tailgate.
