A S S E M B L Y & I N S T A L L A T I O N G U I D E
APPLICATION
GM Silverado/Sierra
BEDXTENDER HD™ shown assembled and installed on truck.
Remove contents from box and check for damage.
Verify all parts against parts list.
Read and understand instructions completely before attempting assembly
and installation.
Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the
following patents:
5,700,047; 6,113,173; 6,402,215; 6,805,392; 7,063,366; 7,393,035; 7,654,598; 7,681,935; 7,841,638
www.amp-research.com
YEAR
2019
1/7
PART #
74841-00A (Silver)
INSTALLATION TIME
SKILL LEVEL
1
TOOLS REQUIRED
Phillips screw driver
Torx T-20 driver
Torx T-25 driver
Power drill
1/8" drill bit
21/64" drill bit
Center punch
Supplied templates
Soapy Water
Masking Tape
WARRANTY
3-Year Limited Warranty
74841-01A (Black)
1 Hour
4
2 3
1= Easy
rev 05.02.19

Advertisement

loading
Need help?

Need help?

Do you have a question about the BEDXTENDER HD MAX 74841-00A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AMP Research BEDXTENDER HD MAX 74841-00A

  • Page 1 Read and understand instructions completely before attempting assembly 3-Year Limited Warranty and installation. Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents: 5,700,047; 6,113,173; 6,402,215; 6,805,392; 7,063,366; 7,393,035; 7,654,598; 7,681,935; 7,841,638 www.amp-research.com...
  • Page 2 A M P R E S E A R C H B E D X T E N D E R H D ™ PARTS LIST AND HARDWARE IDENTIFICATION Strap Buckle Bumper Quick Mount PT-Screw Assembly Bracket Set M8 U-Nut M8 Bolt (Small/Narrow) (Small/Narrow)
  • Page 3 A M P R E S E A R C H B E D X T E N D E R H D ™ MOUNTING BRACKET INSTALLATION - CHEVROLET SILVERADO / GMC SIERRA 2019 PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING WITH INSTALLATION Assemble U-Nuts on to bracket plates in the orientation shown.
  • Page 4 A M P R E S E A R C H B E D X T E N D E R H D ™ Enlarge hole in D-Pillar with 21/64” drill bit. Fasten the Quick Mount Bracket to the D-Pillar with one M8 Hex Bolt and Bracket Nut Plate Assembly.
  • Page 5: Reference Point

    A M P R E S E A R C H B E D X T E N D E R H D ™ BED X-TENDER ASSEMBLY Measure 7” from each end of the three center Slide 3 center tubes into the open ends of the bent tubes and mark with tape.
  • Page 6 A M P R E S E A R C H B E D X T E N D E R H D ™ BED X-TENDER ASSEMBLY – CONTINUED Tighten PT-Screws using a T-25 torx driver, starting Attach plastic upright around the tube juncture, in the middle of each upright, then the outer screws placing rubber bumpers into the two ends of the and lastly the remaining two to evenly tighten.
  • Page 7 A M P R E S E A R C H B E D X T E N D E R H D ™ NOTE: Ensure that buckles are properly inserted into latches by pulling on the straps after both buckles have been inserted.
  • Page 9: Limited Warranty

    Congratulations on your purchase of the AMP Research BEDXTENDER HD. Here’s what you need know... BEDXTENDER HD™ OPERATION With the tailgate open, place BEDXTENDER pivot pins into the left and right mounting brackets. Rotate to 45 until it drops into place, then lower onto the open tailgate.
