CONTROL THROWS.

1) We highly recommend setting up the
AT-6 TEXAN using the control throws listed
at right. We have listed control throws for both
Low Rate (initial test flying/sport flying) and
High Rate (aerobatic flying).
www.seagullmodels.com
trim tabs on the transmitter in neutral, center
the control surfaces by making adjustments
to the clevises or adjustable servo connectors.
The servo arms should be centered also.
9.8cm.
control surfaces are centered, use a ruler and
check the amount of the control throw in each
surface. The control throws should be
measured at the widest point of each sur-
face!
able control horn out from the control surface,
you will decrease the amount of throw of that
control surface. Moving the adjustable con-
trol horn toward the control surface will in-
crease the amount of throw.
INITIAL FLYING
AEROBATIC FLYING
2) Turn on the radio system, and with the
3) When the elevator, rudder and aileron
4) By moving the position of the adjust-
