3.2 Module Specifications

Size
Program storage
Battery backup for program, data, and
time-of-day clockl
Backplane current consumption:
IC200CPUE05
Floating point
Boolean execution speed
Realtime clock accuracy (for timer
functions)
Time of day clock accuracy
Embedded communications
Configurable memory
Ethernet Interface Specifications
Number of SRTP server connections
Ethernet data rate
Physical interface
WinLoader support
Number of Ethernet Global Data
configuration-based exchanges
EGD Exchange limits
Time Synchronization
Selective Consumption of EGD
Load EGD configuration from PLC to
programmer
Remote Station Manager over UDP
Local Station Manager (RS-232)
Configurable Advanced User Parameters
† CPUE05 requires a power supply with expanded 3.3V.
CPU Module Datasheet: CPUE05
For public disclosure
4.95" (126mm) x 5.04" (128mm)
System flash, battery-backed RAM
Super capacitor provides power to memory for 1 hour
Over 1 hour, backup battery protects memory contents up to 6 months.
Backup battery has shelf life of 5 years when not in use.
no serial port converter or EZ
Program Store device
with serial port converter or EZ
Program Store device
yes
0.5ms/K (typical)
100ppm (0.01%) or +/- 9sec/day
23ppm (0.0023%) or +/- 2sec/day @ 30C.
100 ppm (0.01%) or +/- 9sec/day @ full temperature range
RS-232, RS-485, Ethernet interface
128K bytes maximum
8
10Mbps
10BaseT RJ45 Shielded
via CPU port
32
100 data ranges and 1400 bytes of data per exchange; 1200 total data ranges
across all exchanges.
NTP - client only (Supported IC200CPUE05-HK or before)
yes
yes
yes
via CPU port
yes
5V output: 100mA
3.3V output:
820mA
5V output: 200mA
GFK-1503E User Manual 41
†
