3.4 DDR4 SDRAM

Two banks of DDR4 SDRAM memory are soldered down to the board. While the factory default is 8GB/per bank,
16GB/bank is also supported through a build variant. Please see
interface is 72-bit wide data (64 data + 8 ECC). Maximum signaling rate is 2400 MT/s for 16GB total and
1688MT/s with 32GB total.
Memory solutions are available from the Xilinx Memory Interface Generator (MIG) and must use Vivado 2016.1
or later. An example project with traffic generator is available with purchase of the ADM-PCIE-8K5 SDK.
However, all the information required to generate a complete MIG IP core is available within this user guide.

3.4.1 MIG IP setup requirements rev2 + newer PCBs

8GB per bank, rev2 and newer PCB
Vivado 2016.3 IP Catalog: DDR4 SDRAM (MIG)
Memory Device Interface Speed (ps): 937
Reference Input Clock speed (ps): 3332
Custom Parts Data File: Checked, use 'adm-pcie-'8k5_custom_parts_2400.csv' downloaded from
www.alpha-data.com/8k5
Configuration: Components
Memory Part: CUSTOM_DBI_MT40A1G8PM-083E
Data Mask and DBI: NO DM DBI WR RD
IO locations found in appendix
Page 10
ADM-PCIE-8K5-FH User Manual
Order Code
for all order options. The memory
Functional Description
ad-ug-1342_v1_0.pdf
