REFCLK100M
3.2.4 QSFP28
The QSFP28 cages are located in MGT tiles 129 and 128 and use a 161.1328125MHz default reference clock.
Note that this clock frequency can be changed to any arbitrary clock frequency up to 400MHz by re-programing
the Si5338 reprogrammable clock oscillator via system monitor. This can be done using the Alpha Data API or
over USB with the appropriate Alpha Data Software tools.
GTY_CLK_0B
GTY_CLK_0C
The QSFP28 cages are also located such that they can be clocked from a Si5328 jitter attenuator clock
multiplier. If jitter attenuation is required please see the reference documentation for the Si5328. https://
www.silabs.com/Support%20Documents/TechnicalDocs/Si5328.pdf
The Si5328 is configured with a 114.285MHz oscilator on XA and XB, SDA is at FPGA pin L29 (1.8V), SCL is at
FPGA pin L30 (1.8V) with external pull-ups included.
The Si5328 input clock comes from FPGA pins M29 and M30, and includes 100 Ohm AC coupled termination on
the 1.8V FPGA bank.
SI5328_REFCLK_OUT0
SI5328_REFCLK_OUT1
3.2.5 FireFly
The two FireFly sites are located in MGT tile 125 and 126 and use a 161.1328125MHz default reference clock.
Note that this clock frequency can be changed to any arbitrary clock frequency up to 400MHz by re-programing
the Si5338 reprogrammable clock oscillator via system monitor. This can be done using the Alpha Data API or
over USB with the appropriate Alpha Data Software tools.
GTY_CLK_1B
GTY_CLK_1C
3.2.6 DDR4 SDRAM Reference Clocks
The two banks of DDR4 SDRAM memory each require a separate reference clock, as per Xilinx UltraScale MIG
design guidelines. The reference clocks for these interfaces are detailed below:
Both clocks are 300MHz by default.
Functional Description
ad-ug-1308_v1_9.pdf
Signal
IO_L24P_T3U_N10_EMCCLK_65
Signal
Target FPGA Input
MGTREFCLK0_129
MGTREFCLK0_128
Table 8 : QSFP28 Reference Clocks
Signal
Target FPGA Input
MGTREFCLK1_129
MGTREFCLK1_128
Table 9 : QSFP28 Jitter Attenuated Reference Clocks
Signal
Target FPGA Input
MGTREFCLK0_126
MGTREFCLK0_125
Table 10 : FireFly Reference Clocks
Target FPGA Input
Table 7 : EMCCLK
I/O Standard
I/O Standard
I/O Standard
I/O Standard
LVCMOS18
"P" pin
LVDS
N33
LVDS
U33
"P" pin
LVDS
L33
LVDS
R33
"P" pin
LVDS
AE33
LVDS
AJ33
pin
AJ28
"N" pin
N34
U34
"N" pin
L34
R34
"N" pin
AE34
AJ34
