2 PCB Information

2.1 Physical Specifications

The ADM-PCIE-8K5-FH complies with PCI Express CEM revision 3.0.

2.2 Chassis Requirements

2.2.1 PCI Express

The ADM-PCIE-8K5-FH is capable of PCIe Gen 1/2/3 with 1/2/4/8 lanes, using the Xilinx Integrated Block for PCI
Express.

2.2.2 Mechanical Requirements

An 8-lane or 16-lane physical PCIe slot is required for mechanical compatibility.
Each ADM-PCIE-8K5-FH is shipped with a full height PCIe card bracket installed by default.

2.2.3 Power Requirements

The PCIe Specification permits a standard full-height, half-length PCIe card to dissipate a maximum 75 W of
power, drawn from the PCIe slot. Power estimation requires the use of the Xilinx XPE spreadsheet and/or a
power estimator tool available from Alpha Data. Please contact support@alpha-data.com to obtain this tool.
The power available to the rails calculated using XPE are as follows:
Voltage
0.95
1.8
3.3
1.2
1.8
1.0
1.2
Page 2
Description
Total Dy
Total Dx (Inc. SFP+ Cages)
Total Dz
Weight
Table 1 : Mechanical Dimensions
Source Name
VCC_INT + VCCINT_IO + VCC_BRAM
VCCAUX + VCCAUX_IO VCCO_1.8V
VCCO_3.3V
VCCO_1.2V
MGTVCCAUX
MGTAVCC
MGTAVTT
Table 2 : Available Power By Rail
ADM-PCIE-8K5-FH User Manual
Measure
111 mm
173 mm
17.5 mm
250g
Current Capability
ad-ug-1342_v1_0.pdf
36A
3A
2A
20A
1A
5A
2A
PCB Information
