ADM-PCIE-8K5-FH User Manual
Complete Pinout Table
ad-ug-1342_v1_0.pdf
Pin
Signal Name
Number
AM27 DDR4_1_DQ32
AM24 DDR4_1_DQ33
AN27 DDR4_1_DQ34
AN28 DDR4_1_DQ35
AM26 DDR4_1_DQ36
AN26 DDR4_1_DQ37
AM25 DDR4_1_DQ38
AP28 DDR4_1_DQ39
AW23 DDR4_1_DQ4
H34 DDR4_1_DQ40
G39 DDR4_1_DQ41
F37 DDR4_1_DQ42
G37 DDR4_1_DQ43
H36 DDR4_1_DQ44
H39 DDR4_1_DQ45
G34 DDR4_1_DQ46
G36 DDR4_1_DQ47
J38 DDR4_1_DQ48
J35 DDR4_1_DQ49
AU22 DDR4_1_DQ5
K37 DDR4_1_DQ50
K35 DDR4_1_DQ51
J39 DDR4_1_DQ52
J34 DDR4_1_DQ53
L37 DDR4_1_DQ54
L35 DDR4_1_DQ55
E35 DDR4_1_DQ56
B34 DDR4_1_DQ57
B36 DDR4_1_DQ58
D34 DDR4_1_DQ59
AW21 DDR4_1_DQ6
D35 DDR4_1_DQ60
A34 DDR4_1_DQ61
C36 DDR4_1_DQ62
C34 DDR4_1_DQ63
Table 14 : Complete Pinout Table (continued on next page)
Bank Voltage
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
