ADM-PCIE-8K5-FH User Manual
Complete Pinout Table
ad-ug-1342_v1_0.pdf
Pin
Signal Name
Number
N23 DDR4_0_DQ27
R22 DDR4_0_DQ28
P21 DDR4_0_DQ29
A18 DDR4_0_DQ3
R21 DDR4_0_DQ30
P20 DDR4_0_DQ31
E20 DDR4_0_DQ32
F18 DDR4_0_DQ33
F20 DDR4_0_DQ34
E18 DDR4_0_DQ35
F19 DDR4_0_DQ36
G20 DDR4_0_DQ37
H18 DDR4_0_DQ38
H17 DDR4_0_DQ39
A20 DDR4_0_DQ4
G22 DDR4_0_DQ40
E23 DDR4_0_DQ41
G21 DDR4_0_DQ42
F23 DDR4_0_DQ43
H24 DDR4_0_DQ44
E22 DDR4_0_DQ45
H23 DDR4_0_DQ46
E21 DDR4_0_DQ47
J23 DDR4_0_DQ48
K22 DDR4_0_DQ49
D18 DDR4_0_DQ5
K23 DDR4_0_DQ50
L24 DDR4_0_DQ51
J24 DDR4_0_DQ52
L20 DDR4_0_DQ53
L23 DDR4_0_DQ54
K20 DDR4_0_DQ55
P16 DDR4_0_DQ56
R18 DDR4_0_DQ57
R17 DDR4_0_DQ58
Table 14 : Complete Pinout Table (continued on next page)
Bank Voltage
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
1.2
