5. INSTALLATION OF GPS BOARD
ASSEMBLY (OPTION)
A GPS receiver board can be installed in the
Communication Unit IC-212. There are two
kind of GPS board assemblies: OP16-16-1 and
OP16-16-2. The former is fitted at factory; the
latter in the field. Here, installation of the latter
is explained.
Table 5-1 Contents of GPS board
assembly OP16-16-2
N a m e T y p e
G P S p b c G N - 4 7 N N C
a s s . y
N E - 1 *
1
G N - 7 7 7 0 1 *
C b a e l S F . L 2 2 - L P
2
a s s . y W H A ( 0 4 ) 0
C b a e l 5 0 1 5 6 0 - 0 7 - 0
a s s . y
P H R 8 - L - 0 5
3
6 1 S 3 0 6 9 3 *
4 c S e r w M 3 6 x
*1) Both are equivalent
*2) For GN-74 NNCC-N-E
*3) For GN-7707
1. Unfasten twelve screws to remove top and
bottom covers on the communication unit.
2. Fix the GPS pcb assy. to the bottom of the
unit with M3x6 screws.
3. Fix the cable assy. 51065-0700-PHR-8-L50
between J2 of the GPS pcb assy. and J8 of
the CPU pcb as follows.
GPS pcb
NOTE 1
J2
J1
Cable
assembly
S.FL2-2LPO.
7DWHA (400)
Figure 5-1 Communication unit, bottom view
(bottom cover removed)
C o d e N . o Q y t
- C
0 4 0 4 - 2 4 8 - 0 2
1
0 0 0 1 - 1 4 4 - 8 0
0 7 . D -
0 0 0 1 - 0 4 3 - 6 4 1
0 0 0 1 - 6 3 6 - 6 0
2 *
1
0 0 0 1 - 2 4 4 - 1 5
0 0 0 8 - 1 8 4 - 3 0 2
Front side
CPU pcb
J9
Cable
assembly
51065-
J8
0700-PHR
-8-L50
J1 J2 J3J4 J5 J6 J7
Mini clamp
Rear side
4. Fix the cable assy. S.FL2-2LP0.7DWHA
(400) between J1 of the GPS pcb and J4 of
the RFCONV pcb and secure it with three
mini-clamps. Refer to Figures 5-1 and 5-2.
RFCONV
pcb
J4
NOTE1
Figure 5-2 Communication unit, top view
(top cover removed)
Insert connectors vertically.
NOTE1:
Cable assembly
Front side
11
