System Configuration - Furuno FELCOM 12 Installation Manual

Mobile earth station
Hide thumbs Also See for FELCOM 12:

Advertisement

1. SYSTEM CONFIGURATION

Ship's mains
24 VDC
Ship's mains
100/200 VAC
24 VDC
*: Mandatory for EGC operation as required by IMO Res. A. 664(16).
Antenna Unit
IC-112
Ground wire
Communication Unit
IC-212
AC/DC Power
Supply Unit
PR-300
:
Standard Supply
: Optional
Supply
Figure 1-1 System configuration
Terminal Unit
IB-581
Distress Alert Unit
IC-302
Received Call Unit
IC-303
Terminal Unit
IB-581
EGC Printer
PP-505
I/F Box
OP16-14
Terminal Unit
IB-581
or IBM Compatibile
Personal Computer
External Navigation Device
Keyboard
Printer
*
PP-510
24 VDC
24 VDC
24 VDC
1
