Table of Contents

Summary of Contents for Seco Qseven QuadMo747 x2000

Page 1 QuadMo747 x2000 ® Qseven Rel. 2.0 Compliant Module ® with the Intel Atom Cedarview family CPUs ® and Intel NM10 Express Chipset...
Page 2 SECO S.r.l. reserves the right to change precise specifications without prior notice to supply the best product possible. For further information on this module or other SECO products, but also for getting the proper assistance for any and possible issues, please contact us using the dedicated web form available at http://www.seco.com...
Page 3: Table Of Contents
Introduction ..............................................45 Basic configuration ............................................46 Advanced configuration ..........................................47 4.3.1 RAM test execution ..........................................47 QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 4 Inverter Type & polarity ......................................... 52 4.4.18 Local Flat Panel ............................................ 52 4.4.19 Local Flat Panel Type ........................................... 53 QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 5 Appendices ....................................59 Thermal Design ............................................60 Accessories ..............................................63 5.2.1 VGA Adapter module M908 ......................................... 63 QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 6: Rohs Compliance
Information and assistance RMA number request Safety Electrostatic Discharges RoHS compliance Terminology and definitions Reference specifications QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 7: Warranty
All changes or modifications to the equipment not explicitly approved by SECO S.r.l. could impair the equipment s and could void the warranty. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 8: Information And Assistance
SECO Sales Representative: the Sales Rep can help you in determining the exact cause of the problem and search the best solution for it. SECO Help-Desk: contact SECO Technical Assistance. A technician is at your disposal to understand the exact origin of the problem and suggest the correct solution.
Page 9: Safety
The QuadMo747-x2000 module is designed using RoHS compliant components and is manufactured on a lead-free production line. It is therefore fully RoHS compliant. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 10: Terminology And Definitions
Low Voltage Differential Signalling, a standard for transferring data at very high speed using cheap twisted pairs copper cables, usually used for video applications Mbps Megabit per second QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 11 Voltage reference Pin Video Graphics Array, an analog computer display standard, commonly referred also as CRT QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 12: Reference Specifications
USB 2.0 and USB OTG http://www.usb.org/developers/docs/usb_20_070113.zip USB 3.0 http://www.usb.org/developers/docs/usb_30_spec_070113.zip ® Intel Atom Cedarview family http://ark.intel.com/products/codename/37505/Cedarview QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 13: Chapter 1. Introduction
Chapter 2. Introduction Technical Specifications Electrical Specifications Mechanical Specifications Block Diagram QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 14: Introduction
Please refer to following chapter for a complete list of all peripherals integrated and characteristics. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 15: Technical Specifications
2.2 Technical Specifications Up to 8 x USB2.0 Host ports ® Intel Atom D2550 @1.86GHz, 1MB Cache, 10W TDP ® Intel Atom N2800 @1.86GHz, 1MB Cache, 6.5W TDP Ethernet ® Intel Atom N2600 @1.6GHz, 1MB Cache, 3.5W TDP Gigabit Ethernet interface Chipset Audio Intel...
Page 16: Electrical Specifications
_U: unswitched ACPI S3 voltages, i.e. power rails that are active both in ACPI’s S0 (Working) and S3 (Standby) state. Examples: +1.5V_U QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 17: Power Consumption
65,3mA 64,5mA Soft Off (typical) 37,9mA 38mA 37,7mA RTC Power consumption (typical) 2,6μA 2,6μA 2,6μA QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 18: Mechanical Specifications
® the Qseven module. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 19: Block Diagram
SM Bus Power management STMicroelectronics Watch Dog Internal FAN STM32F100R4 connector External FAN interface microcontroller QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 20 Chapter 3. Introduction Connectors description QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 21: Introduction
Card edge golden finger, pin 228 finger, pin 2 finger, pin 1 finger, pin 229 QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 22: Connectors Description
EMI, and so on. Optionally, SECO can provide a dedicated VGA adapter, able to carry out the signals coming out from connector CN1 to a standard DB-15 HD VGA connector. The adapter is also provided with necessary FFC cable, length 20cm. Please check chapter 5.2.1 for further details.
Page 23: Fan Connector
FAN_TACHO_IN: tachometric input from the fan to the embedded microcontroller, +3.3V_S electrical level signal with 10kΩ pull-up resistor. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 24: Qseven ® Connector
PWR_MGMT SATA SATA0_TX+ SATA1_TX+ SATA SATA SATA0_TX- SATA1_TX- SATA SATA SATA_ACT# SATA SATA0_RX+ SATA1_RX+ SATA QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 25 USB_P4+ USB_2_3_OC# USB_0_1_OC# USB_P3- USB_P2- USB_P3+ USB_P2+ N.A. N.C. N.C. N.A. USB_P1- USB_P0- USB_P1+ USB_P0+ QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 26 HDMI HDMI/DP TMDS_TX2- / DP_LANE0- HDMI_CTRL_CLK HDMI HDMI/DP DP_HDMI_HPD# N.C. N.A. PCI-E PCIE_CLK_REF+ PCIE_WAKE# PCI-E QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 27 +5V_A N.A. MFG_NC0 MFG_NC2 N.A. N.A. MFG_NC1 MFG_NC3 N.A. +5V_S +5V_S +5V_S +5V_S +5V_S +5V_S QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 28 RESET Signal. In case you need to supply Reset signal to multiple devices, you have to provide for a buffer on the carrier board. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 29 The customer acknowledges and agrees to the conditions set forth that these schematics are provided only as an example and that he will conduct an independent analysis and exercise judgment in the use of any and all material. SECO declines all and any liability for use of this or any other material in the customers’...
Page 30 GBE_CTREF is not available on Qseven card edge connector. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 31 On the carrier board, these signals can be carried out directly to the SATA connector. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 32 The schematics in the following page show an example of implementation on the Carrier Board. In there, all USB ports are carried out to standard USB 2.0 Type A receptacles. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 33 OUT2 Dual_USB connector VCC_USB0 BLM18PG121SN1 IP4221CZ6-S USB_P0- USB_P1- CC-47uF/10V CC-100nF USB_P0+ USB_P1+ CC-100nF DLW21HN900SQ2 DLW21HN900SQ2 QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 34 All these signals have to be connected, on the Carrier Board, to an HD Audio Codec. Please refer to the chosen Codec’s Reference Design Guide for correct implementation of audio section on the carrier board. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 35 LVDS_DID_CLK: DisplayID DDC Clock line for LVDS flat Panel detection. Bidirectional signal, electrical level +3.3V_S with a 2k2Ω pull-up resistor. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 36 Please refer to the following schematics as an example of implementation of HDMI connection + voltage level shifters on the carrier board. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 37 2N7002 IP4221CZ6-S R-1K HDMI_CTRL_DAT BLM18PG121SN1 +5V_HDMI HDMI_HPD# WHDM-19D5L1BF3U4W +5V_S SN74LVC1G14DBVR SL04 BLM18PG121SN1 R-20K CC-1uF CC-100nF QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 38 Please refer to the following schematics as an example of implementation of multimode DisplayPort connection on the carrier board, which will allow the use of external adapters for the conversion to HDMI/DVI. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 39 OE4# +3.3V_S DP_HDMI_HPD# R-100K SN74LVC1G14DBVR WDPE-20F5L1BU CC-100nF +3.3V_S 2N7002 nanoSMDC075F BLM18PG121SN1 CC-100nF CC-100nF 2N7002 R-1M QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 40 SPI_CS0#: SPI Chip select, active low output signal (+3.3V_S electrical level with a 10kΩ pull-up resistor). QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 41 SMB_DAT: SM Bus control data line for System Management. Bidirectional signal, electrical level +3.3V_A with a 2k2Ω pull-up resistor. It is managed by Intel QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 42 It is not possible at all to use these pins to trace the software (for debug purposes). QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 43: Boot Strap Signals
LPC_CLK: pin 189 of golden card edge connector. Signal at +3.3V_S voltage level with a 10kΩ pull-down resistor. This is a PLL strap used to set the main clock frequencies of the board. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 44 Chapter 4. Introduction Basic configuration Advanced configuration Chipset Configuration Power Management Recovery Settings IRQ Mapping QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 45: Introduction
The last two items allow exiting from setup respectively updating or not updating the C-MOS RAM. It is important to remember that setup data are stored not only in a CMOS, but also in an internal Flash. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 46: Basic Configuration
Date and Time fields can be modified choosing the right field with arrow keys, selecting it with Enter or Tab and modifying the value with PgUp, PgDn, + and -. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 47: Advanced Configuration
This option allows you to define the NUMLOCK state at Boot, delineating working mode of numeric keypad. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 48: Com1 Console Redirection
Please remember that SATA Channel 1 can be carried out on golden card edge connector, or used for embedded SATA disk, depending on factory configuration purchased. Use these menu items to set properly the boot order. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 49: Boot Video First From
This option allows you to enable or disable the assertion of external watchdog signal WDOUT when the time-out occurs. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 50: Chipset Configuration
O.S. and to change again this option in BIOS setup menu. Please also check par. 4.6.1. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 51: Maximum Udma Mode
These options allow choosing which IRQ has to be assigned to PCI INTA#/INTB# / INTC# / INTD# lines (possibilities are IRQ 3, 4, 5, 6, 7, 10, 11, 12, 14, 15 or NO). QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 52: Internal Audio
4.4.18 Local Flat Panel This option allows enabling or disabling the Local Flat Panel (LFP) LVDS interface. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 53: Local Flat Panel Type
This option allows activating or deactivating Spread Spectrum on PCI Express clock. Activation is possible by setting directly the spread spectrum at -0.5%, -0.4%, -0.3%, ±0.15%, ±0.2%or ±0.25%. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 54: Power Management
Using this option, it is possible to enable or disable USB ports 0 and 1, that are USB1.1 controlled by a single UHCI controller, for waking up the system from S3 (Suspend-To-RAM) state. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 55: Lid_Btn# Configuration
Please consider that if LID_BTN# signal is set fixed to “Open” or “Closed” (see par. 4.5.8) then this menu item will be ineffective. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 57: Irq Mapping
Available only in case SATA controller is set to work in AHCI mode, not in IDE Legacy mode QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 58: Int# Devices Assignment
* When SATA is set to work in IDE Legacy mode, and not in AHCI mode, then it will use IRQ14 and IRQ15, that will not be free anymore (see also par. 4.7.1). QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 60: Thermal Design
Ordering Code Description Q978-DISS-1 QuadMo747-x2000 Heat Spreader Q978-DISS-2 QuadMo747-x2000 Heatsink Q978-DISS-3 QuadMo747-x2000 Active Heatsink with FAN QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 63: Accessories
The Adapter module is equipped directly with a 20cm long FFC cable for its connection to QuadMo747-x2000 board’s connector CN1. DB-15 HD CRT connector is VESA VGA DDC2 compliant. QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
Page 64 SECO Srl - Via Calamandrei 91 52100 Arezzo - ITALY Ph: +39 0575 26979 - Fax: +39 0575 350210 www.seco.com QuadMo747-x2000 QuadMo747-x2000 User Manual - Rev. First Edition: 1.0 - Last Edition: 2.0 - Author: S.B. - Reviewed by G.G. Copyright © 2014 SECO S.r.l.
